Summary of Contents for Diy Wake Drill
- Page 1 D iy wake w w.diywake.com A division of Pyramid Manufacturing. 916 Mann Ct. Folsom, Ca. 95630 Phone: (916)337-1324 SPEAKER ASSEMBLY INSTRUCTIONS Tools needed. Drill Drill Bit 5/16” Socket and Socket wrench Phillips Screw driver Wire Connector Crimpers...
- Page 2 D iy wake w w.diywake.com A division of Pyramid Manufacturing. 916 Mann Ct. Folsom, Ca. 95630 Phone: (916)337-1324 Figure 1. Optional Some people think that filling the cans with padding will make the speakers sound better. If you are of this group we recommend using a foam filler like the one in figure one.
- Page 3 D iy wake w w.diywake.com A division of Pyramid Manufacturing. 916 Mann Ct. Folsom, Ca. 95630 Phone: (916)337-1324 Figure 4. 3. If you are installing coaxial’s make sure that you place the crossover on the foam ( figure 4 ) so that the crossover sticks to the foam when it dries.
- Page 4 Phone: (916)337-1324 Figure 8. 7. Mark the speaker mounting holes ( figure 8 ). Figure 9. 8. Using the drill and drill bit dill the mounting holes ( figure 9 ). Figure 10. 9. Connect the speakers to the output leads ( figure 10 ).
- Page 5 D iy wake w w.diywake.com A division of Pyramid Manufacturing. 916 Mann Ct. Folsom, Ca. 95630 Phone: (916)337-1324 Figure 12. 11. Using the phillips screwdriver mount the grill ( figure 12 ). Figure 13. 12. Now you are done.
