® service of Pocket PC Phone glofiish M810. Information contained in this document is copyrighted by E-TEN Information Systems Co., Ltd. It is intended for use of E-TEN’s authorized service providers and clients. Service technicians may reproduce this document as needed for repair uses only.
6. Charging / Mobile Phone / Bluetooth / WLAN / GPS LED indicator 7. Video conference camera 8. Display, Touch screen ( Applies to M810) 9. Left Soft-Key 10. Right Soft-Key Send button End button 13. Navigation button. Press the 14.
How to entering the program: a. Press POWER and RESET buttons at the same time and release. b. After that, Press CAMERA button immediately after having hardware reset c. Release CAMERA button after the screen shows up M810 Test System ╳ 1.NFlash 2.RAM 3.Keypad...
Page 10
Follow each of the instructions and press BLACK or GREEN hinted button in order. Keypad Pad/Keyboard test *There’re five sub-testing items in this program. Tap up-right corner to exit if passed all pad test Take stylus to draw few lines slowly around the screen rims and center.
5.2 Function Test Under OS Testing Item Procedures Guidelines Phone Live Test phone dial and receive function Check Dial/Answer the phone call’s Test 1. Device over device to testing voice is clear enough 2. Use Headset to answer call 3. Use Bluetooth to answer call USB connection Synchronize PDA with PC Connected USB to check PDA can be communicate with PC’s ActiveSync...
CHAPTER 6. DISASSEMBLY Ref. Illustration Read Sequences P/N: 40011440 Main Unit Stylus, Battery Cover & Battery, SIM Card(if any) 40011430 49005840 A. Pull out the Stylus. B. Remove battery-cover from the unit, push and move downward. C. Remove battery, release latch before take it up. D.
Page 13
Main Unit Antenna Cover P/N: 40012010 A. Use plastic-stick to release middle latch by pulling up the Cover slowly. B. Antenna Cover Middle Latch will be released this time. C. Take cover up, release latches before remove. D. Finish. Caution!! The surface may easily been cut or get injury, keep alert if use any sharp tools. P/N: 40012000 Main Unit Base-D Bracket(unscrew needed)...
Page 14
A. Use T5-screwdriver to release four screws on bracket. B. Use plastic-stick to poke a side from edge of the bracket. C. Slide it slowly to the bottom. D. Restore it to proper position as Picture shown. E. Start separating from the bottom side. F.
Page 15
A. Remove speaker by tweezers. B. Remove vibrator with the same action. C. Remove MIC with the same action. D. Finish. Note. Remove old tape clean, make it ready for new coming part. Main Unit P/N: 67007040 A. Lift M/B a little with plastic-stick. B.
Page 16
A. Lift up cam shield with tweezers. B. Remove camera from the holder. C. Remove EL dome by tweezers. D. Finish. Caution!! Two contact tabs of EL dome may easily break, handle with care when disassembly. P/N: 40011990 Main Unit Keyboard(unscrew needed)...
A. Use T5-screwdriver to release four screws on hinge. B. Use Plastic-Stick to release TOP-B along the edge of Bracket. C. Remove Front Cover connector from the UNIT D. Remove LCM from the UNIT E. Remove VGA CAM F. Finish Caution!! The surface may easily been cut or get injury, keep alert if use any sharp tools.
Page 18
CHAPTER 7. ASSEMBLY Ref. Illustration Read Sequences Front Cover(Top-A) Receiver P/N: 49007210 A. Place receiver to the accurate position. B. Finish. Note. Paste parts with its location accurate, or it can be caused no key functions after assembly. Main Unit Base-C Bracket(screw needed)&...
Page 19
A. Paste EL dome to the accurate position. B. See if it fits the M/B. C. Join camera to its socket-connector. D. Place CAM shield afterwards. E. Finish. Caution!! Two contact tabs of EL dome may easily break, handle with care when assembly. P/N: 49007220 49007230 Base-D Bracket...
Page 20
A. Place speaker to proper position. B. Place vibrator to proper position. C. Place MIC vibrator to proper position. D. Finish. Note. Clean old tape before use new part. P/N: 03040330 Front Cover (Top-A) & Hinge Cover(Top-B) VGA CAM,FPC_LCM,LCM 20090590 &...
Page 21
A. Place FPC connector on Top-B bracket slowly. B. Join FPC and LCM Assy connector. C. Join FPC and VGA CAM connector and place it on the proper position D. Join Front Cover(Top-A) and FPC connector. E. Make sure Top-A & Top-B was assembly in 1-piece unit. F.
Page 22
Main Unit P/N: 67007040 A. Place MB to Base-D Bracket slowly and make sure headset-jack go first. B. Finish. P/N: 44001300*3 Main Unit Base-D Bracket(screw needed) 44001320 *1 A. Cover base-D bracket. ( watch two pogo-pins around the top corner B.
Page 23
A. Place antenna cover on unit. B. Press both side to get closed the case. C. Finish. Caution!! The surface may easily been cut or get injury, keep alert if use any sharp tools. P/N: 49005840 40011430 Main Unit Battery, Battery Cover & Stylus 40011440 A.
CHAPTER 9. SOFTWARE UPGRADE 9.1 System Requirement Microsoft® Windows XP or above Latest version of EUU (End User Upgrade/ EUU_xxx.exe) or Bin file utilities for M810 Latest version of ActiveSync v4.5 or above Tool: mini USB Cable Note: E-ten releases both EUU and Bin file for an authorized Service Center. Distributors and local service agent shall only receive EUU software.
2. Insert the Micro SD card into the device 3. Press the device into DOWNLOAD mode (refer to Chapter 4. The device will be upgrading the file automatically Via EUU ( Distributors ) 1. Open Active Sync 2. Connect with PC 3.
Year 7= 2007 8= 2008 9= 2009 A= 2010 B= 2011 C= 2012 1= Jan 2= Feb 3= Mar 4= Apr 5= May 6= Jun Month 7= Jul 8= Aug 9= Sep A= Oct B= Nov C= Dec 01= 1 02= 2 03= 3 04= 4...
