EarthWise NVPS42108 Operator's Manual

18 volt, cordless convertible 2 in 1 pole saw / chain saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATOR'S MANUAL
18 VOLT, CORDLESS CONVERTIBLE 2 IN 1 POLE SAW / CHAIN SAW
This product is covered by U.S. patents and other international patents
Copyright. All Rights Reserved.
NVPS42108
NVPS42110
This product has been engineered and manufactured to our high standard for dependability,
ease of operation, and operator safety. Properly cared for, it will give you years of rugged,
trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's
manual before using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING, ASSEMBLY, PART, SERVICE
QUESTIONS? CALL 1-800-313-5111 BETWEEN 7:30AM-4:30PM EST FOR ASSISTANCE.
BATTERY MUST BE CHARGED BEFORE FIRST USE.
SAVE THIS MANUAL FOR FUTURE REFERENCE
CONTROLLED
Rev. 2
July. 31, 2012

Advertisement

Table of Contents
loading

Related Manuals for EarthWise NVPS42108

Summary of Contents for EarthWise NVPS42108

  • Page 1 18 VOLT, CORDLESS CONVERTIBLE 2 IN 1 POLE SAW / CHAIN SAW This product is covered by U.S. patents and other international patents Copyright. All Rights Reserved. NVPS42108 NVPS42110 This product has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety.

  • Page 2: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS TO REDUCE RISK OF INJURY: Save these instructions and review frequently prior to use and Before any use, be sure everyone using this tool reads in instructing others. and understands all safety instructions and other information WARNING: When using electric gardening appliances, basic contained in this manual.
  • Page 3 ASSEMBLY UNPACKING This product requires assembly. Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. Inspect the product carefully to make sure no breakage or damage occurred during shipping. Do not discard the packaging material until you have carefully inspected and satisfactorily operated the product.
  • Page 4 INSTALLING/REPLACING THE GUIDE BAR AND CHAIN DANGER: Never start the motor before installing the guide NOTE: Make certain of the direction of chain. bar, chain, chain cover. Without all these parts in place, the 8. Position the chain so there is a loop at the back of the bar. clutch can fly off or explode, exposing the user to possible serious injury.
  • Page 5 INSTALLING/REPLACING THE GUIDE BAR AND CHAIN...
  • Page 6 CHAIN TENSION AND MAINTENANCE Lift file away from the steel on each return stroke. CHAIN TENSION Put a few firm strokes on every tooth. File all left hand cutters in one Stop the engine before setting the chain tension. Make sure the guide bar screw is loosened to finger tight.
  • Page 7 OPERATING Before you start the unit make sure the chain and bar are not WARNING: Do not cut trees near electrical wires or buildings. contacting any object. CAUTION: Failure to lubricate the chain will cause damage to TO TURN THE TOOL ON the bar and chain.

  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS The following precautions should be followed to minimize FELLING A TREE kickback: When bucking and felling operations are being performed by two Always grip the pole and/or handles firmly with both hands or more persons, at the same time, the felling operation should be when unit is running.

  • Page 9: Cutting Instructions

    OPERATING CUTTING INSTRUCTIONS LIMBING As the tree limb starts to fall, stop the saw and immediately retreat along the cleared path. Watch the action in case Limbing is removing branches from a fallen tree. something falls your way. Be alert for overhead limbs or Work slowly, keeping both hands on pole saw with a firm grip.

  • Page 10: Charging The Battery Pack

    CHARGING THE BATTERY PACK The 18 volt battery supplied is sealed, maintenance free and When fully charged, the battery can be safety stored in spill free. temperatures down to –40 degrees F for a period of up to two weeks, before requiring charging. Fully charge battery pack Charge the battery pack only with the charger provided.

  • Page 11: Lubrication System

    - Replace damaged bar and chain with identical replacement parts. CALL US FIRST !! Call us first with questions about operating or maintaining your chain saw at 1.800.313.5111 between 7:30 a.m. – 4:30 p.m. Eastern Standard Time, or send emails to earthwise@reelin.com.

  • Page 12: Product Specifications

    FEATURES PRODUCT SPECIFICATIONS NVPS42108 NVPS42110 Input……………..…………………………. 18V, DC Only Input …………………….…………………. 18V, DC Only Bar Length ……………………………..….8” Oregon Bar Bar Length………………………………..10” Oregon Bar Weight ……………………………………………..8.20 lbs Weight ……………………………………………...8.4 lbs Total Extended Length……………….……...………..9 ft. Total Extended Length ………………………….9 ft. 2 in.

  • Page 13: Warranty

    WARRANTY LIMITED WARRANTY FOR CORDLESS ELECTRIC MODELS This product is manufactured for The Great States Corporation/American Lawn Mower Company. The Great States Corporation/American Lawn Mower Company, Shelbyville, Indiana, has been making lawn mowers for over 100 years and it warrants to the original owner that each new product and service part is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective product or part from the original date of purchase for two (2) years except for the conditions and circumstances listed below.

This manual is also suitable for:

Nvps42110
