Arbeia Juno & Arbeia Vulcan
FREESTANDING STOVE RANGE
5 & 8 kW Nominal Outputs
Installation and Operating
Instructions
Please hand these instructions to the stove user when the installation is complete.
Leave the stove ready for operation and instruct the user in the correct use of the
appliance and operation of controls.
Important: – These products must be installed by a suitably
qualified installer.
DEFRA Clean Air Act Exemption
The Arbeia Juno 5kW & Arbeia Vulcan 8kW stoves only have been exempted under the
Clean Air Act 1993 to burn seasoned wood logs in designated smokeless zones in the UK.
This is subject to the correct fitting of the air control plate (the part and fitting instructions are
supplied separately) maintaining the air wash control at a minimum opening at all times.
Instructions for wood burning MUST be followed in order to ensure compliance at all
times.
Cast Tec Ltd
East Side
Tyne Dock
South Shields
NE33 5SP
T: 0191 497 4280
F: 0191 497 4288
Advertisement
Table of Contents
Summary of Contents for Cast Tec Arbeia Juno
- Page 1 DEFRA Clean Air Act Exemption The Arbeia Juno 5kW & Arbeia Vulcan 8kW stoves only have been exempted under the Clean Air Act 1993 to burn seasoned wood logs in designated smokeless zones in the UK. This is subject to the correct fitting of the air control plate (the part and fitting instructions are supplied separately) maintaining the air wash control at a minimum opening at all times.
-
Page 2: Table Of Contents
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Cast Tec Stoves cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation. TABLE OF CONTENTS... -
Page 3: List Of Components
Fig 1 - Multi Tool Details 2. Component Identification and Assembly Fig 2 – Arbeia Juno 5kW & Arbeia Vulcan 8kW Stove Assembly and controls Your stove comes packed in a plywood crate. Carefully remove the straps and lift off the upper crate. Remove any plastic packaging, open the door and remove all the contents. -
Page 4: Installation Instructions
2.4 Fit the flue spigot collar to the top or rear outlet (as required for the installation) using the 4 x M6 set screws and washers supplied. Use 3mm ceramic gasket provided or fire cement to seal. 2.5 Fit the blanking plate to the opening that is not required for use using the 4 x M6 set screws and nuts provided. -
Page 5: Installation Information
Health & Safety at Work act. 3.1.8 Handling Adequate facilities must be available for unloading and site handling. Cast Tec Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. 3.1.9 Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 6: Ventilation
fuel compatible prefabricated block chimney or a twin-walled insulated stainless steel flue to BS 4543 can be used. These chimneys must be fitted in accordance with the manufacturer’s instructions and Building Regulations. 4.2 Ventilation Purpose provided ventilation is not required in England and Wales unless the appliance nominal rated output is greater than 5kW. -
Page 7: Material Clearances
4.5 Material Clearances Safety Distances from Combustible Surfaces: Model Side Rear Juno 5kW 600mm 800mm Vulcan 8kW 750mm 850mm In addition it is strongly recommended that any furniture or other combustible materials are kept at least 900mm clear from the front of the stove. Due to the fact that combustible shelves, timber fireplaces and beams have potentially thousands of possible configurations in conjunction with stoves outset or inserted partially or fully into chambers, it is not possible to give firm guidance on dimensions to... -
Page 8: Technical Data
If the stove is to be used with smokeless fuel exclusively then the solid fuel fitting kit (supplied separately) must be fitted to the stove according to the instructions supplied with it. Upon completion of the installation, allow a suitable period of time for any fire cement and mortar to dry out. -
Page 9: Operating Instructions
Order made and signed by the Secretary of State or Minister in the devolved administrations. The Cast Tec Arbeia Juno 5kW & Arbeia Vulcan 8kW have been recommended as suitable for use in smoke control areas when burning wood logs. This is conditional upon fitting the supplied secondary air control (air wash) limiters and following the wood burning instructions precisely. -
Page 10: Cleaning
This provides a conventional air draught to the bed of the fire. The primary air intakes need to be adjusted to give the best results when burning different fuels. It will usually be closed when burning wood fuel and open when burning coal or smokeless type fuels. Secondary Air (Air Wash) Juno &... -
Page 11: Fuels
and will give reliable service without major cleaning or work on the firebox. The liner boards may require replacement fairly regularly depending upon fuels and the type of usage experienced. Lining boards are not covered by warranty, as they are a wearing consumable part. -
Page 12: Notes On Smokeless Fuel (Ancit) Burning
6.5.3 Operation with door left open Operation with the door open can cause excess smoke and spillage into the room. The appliance must not be operated with the appliance door left open. 6.5.4 Primary Air left open Operation with the primary air controls left open can cause excess smoke. The appliance must not be operated with air controls or door left open. -
Page 13: Shutting Down
NOTE: To eliminate unwanted smoke emission, after loading new logs on to the fire, open the air wash control up fully for 3-5 minutes or until the logs are blackened all over to boost the fire and get flames issuing from the top of the fuel as soon as possible. When flames are well established, reduce the air wash to the running setting required. - Page 14 DO NOT perform modifications to the appliance as this could seriously compromise safety in operation. DO NOT OVERFIRE – it is possible to fire the stove beyond its design capacity, this could damage the stove, so watch for signs of over firing – if any part of the stove starts to glow red, including baffle plate or fuel retainer, the fire is in an over fire situation and the controls should be adjusted accordingly.
-
Page 15: Dimensions
Arbeia Juno Stove Dimensions Arbeia Vulcan Stove Dimensions Juno & Vulcan Issue 01 06/13... -
Page 16: Frequently Asked Questions
4 How do I regulate the heat output? Each stove has various air controls, which will allow you to easily regulate the heat output and refuelling rate. 5 What warranty do I get? Cast Tec will replace, free of charge, any working part that fails (under normal operating conditions) within 12 months of purchase. Consumables such as glass, firebox lining boards or stove rope and adhesives are not guaranteed.
