Feldo Luxury Sportive W1 Instruction Manual

Instruction Manual
Sportive Line Watch FELDO W1

General Features and Components

Case diameter 45 mm
Stainless steel case black PVD
Japanese Miyota quartz movement
Scratch-resistant sapphire crystal glass
24 mm wide wrist strap
Water Resistant up to 5 bar (50 m)
Weight with bracelet included: 95 g

Specifications

Movement: Miyota 2S60
Size: 21.5mm x 20.0mm x Φ23.7mm
Total thickness: 3.99mm
Hands: 3
Battery life: 10 years
Battery: CR2012 (Lithium)
Type of oscillator: Turning fork type quartz crystal
Oscillation: 32,768 Hz
Accuracy: ±20 s/month worn under normal circumstances

Caring for Your Watch

Even though your watch is water-resistant to 50 m, it is not recommended that you wear it in a hot
shower, sauna or hot tub. For cleaning, please wipe the watch with a thin cloth. Prevent the watch from
heavy vibrations. This specifications might be changed without prior notice.

How to read the time

The watch indicates the actual time via a disc and two hands.
The picture on the left shows the discs and the window. The hour
hand is the big one. Actually it is located at a quarter to ten. The
minute hand is located on the top on the carbon structure. It is a
fixed orange pointer and actually it indicates ~ 45 minutes. The
seconds hand is rotating over the hour disc.
So the actual indicated time is: 09:45:19

Positions of the crown

Pull out crown to the second click position and turn the crown
until the time is set correctly. Push back the crown.
