  • Page 1 Audio System Owners Manual Standard Display Audio Part Number: PT546-00140...
  • Page 3 TABLE OF CONTENTS QUICK GUIDE AUDIO SYSTEM ® Bluetooth HANDS-FREE SYSTEM SETUP SPECIFICATIONS / INDEX...
  • Page 4 Information to User This equipment complies with FCC/IC radiation exposure limits set forth for Alteration or modifications carried out uncontrolled environment without appropriate authorization may meets the FCC radio frequency (RF) invalidate the user’s right to operate Exposure Guidelines in Supplement C the equipment.
  • Page 5 This equipment generates, uses and USE OF CONTROL OR ADJUST- can radiate radio frequency energy MENT PERFORMANCE and, if not installed and used in accor- PROCEDURES OTHER THAN dance with the instructions, may cause THOSE SPECIFIED HEREIN MAY harmful interference to radio communi- RESULT IN HAZARDOUS RADIA- cations.
  • Page 7 Introduction This manual explains the operation of the Display Audio system. Please read this manual carefully to ensure proper use. Keep this manual in your vehicle at all times. The screen shots in this document and the actual screens of the Display Audio system differ depending on whether the functions and/or a contract existed at the time of producing this document.
  • Page 8 SYMBOLS USED IN ILLUSTRATIONS Safety symbol The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”. Arrows indicating operations Indicates the action (pushing, turning, etc.) used to operate switches and other devices.
  • Page 9 IMPORTANT INFORMATION SAFETY INSTRUCTION ABOUT THIS MANUAL To use this system in the safest possible manner, follow all the safety tips shown For safety reasons, this manual indicates below. items requiring particular attention with the following marks. Do not use any feature of this system to the extent it becomes a distraction and prevents safe driving.
  • Page 10 Use caution or temporarily discontinue To ensure the correct audio system use in potentially hazardous situations. operation Do not allow his unit to come into con- Do not use headphones while operating tact with liquids. Electrical shock could a motorized vehicle; the use of head- result.

  • Page 12: Table Of Contents

    TABLE OF CONTENTS QUICK GUIDE SETUP 1. CONTROLS AND FEATURES ..14 1. SETUP OPERATION....... 82 OVERVIEW BUTTONS ......14 QUICK REFERENCE ......82 SYSTEM FUNCTION INDEX ....16 GENERAL SETTINGS......83 TOUCH PANEL SCREEN GUIDANCE SETTINGS ......85 OPERATION........17 DISPLAY SETTINGS......

  • Page 14: Quick Guide

    QUICK GUIDE CONTROLS AND FEATURES 1. OVERVIEW BUTTONS....14 2. SYSTEM FUNCTION INDEX ..16 3. TOUCH PANEL SCREEN OPERATION.........17...

  • Page 15: Controls And Features

    1. CONTROLS AND FEATURES 1. OVERVIEW BUTTONS Name Function Page Touch panel By touching the screen with your finger, you can screen display control the selected functions. Insert a disc into this slot. The CD player turns on Disc slot immediately.
  • Page 16 1. CONTROLS AND FEATURES Name Function Page Press this knob to turn the audio system on and off, “PWR/VOL” knob and turn it to adjust the volume. Talk button Activate the voice recognition mode.

  • Page 17: System Function Index

    1. CONTROLS AND FEATURES 2. SYSTEM FUNCTION INDEX AUDIO SYSTEM SETUP To access the audio system, press the To customize the function settings, press “AUDIO” button. The audio control screen the “SETUP” button. The interface lan- will be displayed. Audio sources: Radio, guage can also be changed from the setup menu.

  • Page 18: Touch Panel Screen Operation

    1. CONTROLS AND FEATURES 3. TOUCH PANEL SCREEN OPERATION This system is operated mainly by the screen buttons. When a screen button is touched, a beep sounds. (To set a beep sound, see page 83.) NOTICE ● To prevent damaging the screen, lightly touch the screen buttons with your fin- ger.

  • Page 19: Audio System

    TURNING THE AUDIO SYSTEM ON OR OFF..........21 CONTROLS USING THE “TUNE/SCROLL” KNOB ..... 21 SWITCHING AUDIO SOURCE....22 SSP (Scion Sound Processing) ..... 22 Sound Controls ........23 DSP CONTROL ........24 3. RADIO OPERATION ..... 25 SWITCHING TO RADIO MODE .... 25 PRESETTING A STATION ....
  • Page 20 AUDIO SYSTEM 6. USB MEMORY OPERATION ..40 CONNECTING A USB MEMORY ..40 SWITCHING TO USB MODE....40 PLAYING A USB MEMORY ....41 7. AUX DEVICE OPERATION... 44 CONNECTING A PORTABLE AUDIO DEVICE..........44 SWITCHING TO AUX MODE....45 PLAYING A PORTABLE AUDIO DEVICE..........

  • Page 21: Audio System Operation

    1. AUDIO SYSTEM OPERATION 1. QUICK REFERENCE To access the audio system, press the “AUDIO” button. The audio system turns on in the last mode used. Name Function Page Audio control A selected audio source is displayed, and it can be ...

  • Page 22: Some Basics

    1. AUDIO SYSTEM OPERATION 2. SOME BASICS This section describes some of the ba- TURNING THE AUDIO sic features of the audio system. Some SYSTEM ON OR OFF information may not pertain to your system. Your audio system works when the en- gine switch is turned to the “ACC”...

  • Page 23: Switching Audio Source

    ● You cannot select dimmed screen but- tons. Connect the audio device before selecting. SSP (Scion Sound Processing) SSP is a modified DSP (Digital Signal Processing) system that provides a The audio system turns on in the last customized sound for your vehicle.

  • Page 24: Sound Controls

    Touch Feel: Reproduces the sound on the stage that musicians hear. Touch “OK”. INFORMATION ● For more details, please visit the SCION website at http://www.scion.com/. Touch the “Sound” tab to display this screen. Sound Controls TONE How good an audio program sounds is largely determined by the mix of the treble and bass levels.

  • Page 25: Dsp Control

    1. AUDIO SYSTEM OPERATION INFORMATION ● The tone of each mode (such as AM, FM and CD player) can be adjusted. DSP CONTROL AUTOMATIC SOUND LEVELIZER (ASL) The system adjusts to the optimum vol- ume and tone quality according to ve- hicle speed compensate...

  • Page 26: Radio Operation

    1. AUDIO SYSTEM OPERATION 3. RADIO OPERATION SWITCHING TO RADIO MODE PRESETTING A STATION Press the “AUDIO” button. Radio mode has a mix preset function, which can store up to 36 stations (6 station per page × 6 page) from any of the AM or FM bands.

  • Page 27: Selecting A Station

    1. AUDIO SYSTEM OPERATION SELECTING A STATION RADIO BROADCAST DATA SYSTEM Tune in the desired station using one of the following methods. This audio system is equipped with Ra- dio Broadcast Data Systems (RBDS). Preset tuning: Touch one of the mix pre- RBDS mode allows text messages to set channels on the left side of the screen be received from radio stations that uti-...

  • Page 28: Traffic Announcement

    1. AUDIO SYSTEM OPERATION Touch “TYPE >” or “< TYPE” to move TRAFFIC ANNOUNCEMENT forward and backward through the pro- gram list. A station that regularly broadcasts traf- fic information is automatically located. Once a program type has been set, “TYPE SEEK”...

  • Page 29: Using Hd Radio™ Technology

    1. AUDIO SYSTEM OPERATION Touch “HD Radio” to turn the indica- USING HD Radio™ tor on. TECHNOLOGY HD Radio™ Technology is the digital evolution of analog AM/FM radio. Your radio product has a special receiver which allows it to receive digital broadcasts (where available)
  • Page 30 1. AUDIO SYSTEM OPERATION To display messages from the station, touch “Additional Information”. MULTICAST On the FM radio frequency most digital stations have “multiple” or supplemen- tal programs on the FM station. Touch “Multicast”. The USB/AUX port is located on the instrument panel, or near the shift knob etc.
  • Page 31 1. AUDIO SYSTEM OPERATION TROUBLESHOOTING GUIDE Experience Cause Action Mismatch of time alignment The radio stations analog a users may hear a short and digital volume is not None, radio broadcast issue. A period of programming re- properly aligned or the sta- user can contact the radio station.

  • Page 32: Cd Player Operation

    1. AUDIO SYSTEM OPERATION 4. CD PLAYER OPERATION The CD player can play audio CDs, CD text and MP3/WMA discs. (a)Audio CD, CD text (See page 32.) (b)MP3/WMA disc (See page 34.) For appropriate discs for this player, see “AUDIO SYSTEM OPERATING HINTS”...

  • Page 33: Switching To Cd Mode

    1. AUDIO SYSTEM OPERATION SWITCHING TO CD MODE PLAYING AN AUDIO CD Press the “AUDIO” button. If a CD-TEXT disc is inserted, the title of the track and disc currently being played will be displayed. : Touch to pause the track. The audio system turns on in the last mode used.
  • Page 34 1. AUDIO SYSTEM OPERATION SELECTING A DESIRED PLAYING REPEAT AND TRACK RANDOM ORDER Select a desired track using one of the following methods. (Repeat mode): Use it to automat- ically repeat the track you are currently lis- tening to. The repeat mode changes as follows each time the screen button is touched.

  • Page 35: Playing A Mp3/Wma Disc

    1. AUDIO SYSTEM OPERATION SELECTING A DESIRED FILE PLAYING A MP3/WMA DISC Select a desired file using one of the following methods. The title of the file and folder currently being played will be displayed. : Touch to pause the file. : Touch to resume playing the file.
  • Page 36 1. AUDIO SYSTEM OPERATION SELECTING A DESIRED PLAYING REPEAT AND FOLDER RANDOM ORDER Touch “Folders” on the screen. The folder list will be displayed. (Repeat mode): Use it to automat- ically repeat the file or folder you are cur- Touch a desired folder from the list. rently listening to.

  • Page 37: Ipod Operation

    1. AUDIO SYSTEM OPERATION 5. iPod OPERATION Connecting an iPod with the USB port CONNECTING AN iPod enables users to enjoy music via the vehicle speakers. Open the cover of the USB/AUX port and connect an iPod. CAUTION ● Do not connect an iPod or operate the device controls while driving.

  • Page 38: Playing An Ipod

    1. AUDIO SYSTEM OPERATION Fast forward and Reverse: Press and Touch “Source” or press “AUDIO” hold the “ ” or “ ” of “SEEK/TRACK” but- button to display the audio source se- ton to fast forward or reverse. When you lection screen.
  • Page 39 1. AUDIO SYSTEM OPERATION SELECTING A DESIRED SONG SELECTING A PLAY MODE Touch “Browse” on the screen. Select a desired song using one of the following methods. Touch a desired play mode tab button, such as playlists, artists, albums, songs, podcasts or audio book. And then select the song on each play “SEEK/TRACK”...
  • Page 40 1. AUDIO SYSTEM OPERATION PLAYING REPEAT AND SHUFFLE (Repeat mode): Use it to automat- ically repeat the song you are currently lis- tening to. The repeat mode changes as follows each time the screen button is touched. :Repeating the song :OFF (Shuffle mode): Use it for auto- matic shuffling of the songs or albums in...

  • Page 41: Usb Memory Operation

    1. AUDIO SYSTEM OPERATION 6. USB MEMORY OPERATION Connecting a USB memory with the CONNECTING A USB USB port enables users to enjoy music MEMORY via the vehicle speakers. Open the cover of the USB/AUX port and connect a USB memory. CAUTION ●...

  • Page 42: Playing A Usb Memory

    1. AUDIO SYSTEM OPERATION Fast forward and Reverse: Press and Touch “Source” or press “AUDIO” hold the “ ” or “ ” of “SEEK/TRACK” but- button to display the audio source se- ton to fast forward or reverse. When you lection screen.
  • Page 43 1. AUDIO SYSTEM OPERATION File list: A desired file can be selected Touch a desired folder from the list. from a list. The file list for the folder will be dis- Touch “Files” on the screen. The list will played. be displayed.
  • Page 44 1. AUDIO SYSTEM OPERATION (Random mode): Use it for auto- matic random selection of the file. The random mode changes as follows each time the screen button is touched. :Playing the files on the fold- er in random order :Playing the files in all the folders in random order :OFF...

  • Page 45: Aux Device Operation

    1. AUDIO SYSTEM OPERATION 7. AUX DEVICE OPERATION Connecting a portable audio device CONNECTING A PORTABLE with the AUX port enables users to en- AUDIO DEVICE joy music via the vehicle speakers. Open the cover of the USB/AUX port and connect a portable audio device. CAUTION ●...

  • Page 46: Switching To Aux Mode

    1. AUDIO SYSTEM OPERATION SWITCHING TO AUX MODE PLAYING A PORTABLE AUDIO DEVICE Press the “AUDIO” button. Only the volume can be adjusted using the audio system controls. The remaining controls need to be operated on the porta- The audio system turns on in the last ble audio device itself.

  • Page 47: Bluetooth ® Audio Operation

    1. AUDIO SYSTEM OPERATION ® 8. Bluetooth AUDIO OPERATION ® The Bluetooth audio system enables INFORMATION users to enjoy music played on a por- ● In the following conditions, the system table player from the vehicle speaker may not function. via wireless communication.

  • Page 48: Switching To Bluetooth ® Audio Mode

    1. AUDIO SYSTEM OPERATION ® SWITCHING TO Bluetooth AUDIO MODE Press the “AUDIO” button. ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Toyota Motor Corporation is under license. Other trademarks and trade names are those of their respective owners.

  • Page 49: Connecting A Bluetooth Audio Player

    1. AUDIO SYSTEM OPERATION Touch “Connect” on the screen. ® CONNECTING A Bluetooth AUDIO PLAYER ® To use the Bluetooth audio system, you need to register your portable au- dio player into the system. Once you have registered it, you can enjoy your music on the vehicle’s audio system.
  • Page 50 1. AUDIO SYSTEM OPERATION When the connection is completed, Touch “Connect” on the screen. this screen is displayed. Touch the portable audio device name Once you have registered it, the system to connect. automatically connects to your portable audio player device every time you start your vehicle.

  • Page 51: Playing A Bluetooth ® Audio Player

    1. AUDIO SYSTEM OPERATION ® This function can be changed to “On” or PLAYING A Bluetooth ® “Off”. See “DETAILED Bluetooth SET- AUDIO PLAYER TINGS” on page 93. *: Bluetooth is a registered trademark of Bluetooth SIG, Inc. The title of the track and album currently being played will be displayed.
  • Page 52 1. AUDIO SYSTEM OPERATION Indicates the amount of battery charge STATUS DISPLAY left. Empty Full INFORMATION ● Depending on the type of portable audio players, remaining battery charge is not displayed. ® Indicates the condition of the Bluetooth ● The amount left does not always corre- connection.
  • Page 53 1. AUDIO SYSTEM OPERATION Track list: A desired track can be selected Touch a desired album from the list. from a list. The track list for the album will be dis- Touch “Tracks” on the screen. The list played. will be displayed. When a desired track is touched, the Touch a desired track.
  • Page 54 1. AUDIO SYSTEM OPERATION (Random mode): Use it for auto- matic random selection of the track. The random mode changes as follows each time the screen button is touched. :Playing the tracks on the album in random order :Playing the tracks on all the albums in random order :OFF...

  • Page 55: Steering Switches

    1. AUDIO SYSTEM OPERATION 9. STEERING SWITCHES Some parts of the audio system can be “ ” “ ” switch adjusted with the switches on the Radio steering wheel. To select a preset station: Press the “ ” switch. or “ ” STEERING SWITCHES (WITH To seek a radio station: Press and hold TWO DIRECTION STEERING...

  • Page 56: Audio System Operating Hints

    1. AUDIO SYSTEM OPERATION 10. AUDIO SYSTEM OPERATING HINTS NOTICE Fading and drifting stations: Generally, ● To avoid damaging the audio system: the effective range of FM is about 25 miles • Be careful not to spill beverages over (40 km). Once outside this range, you may the audio system.

  • Page 57: Ipod

    1. AUDIO SYSTEM OPERATION COMPATIBLE MODELS iPod   The following iPod , iPod nano , iPod    classic , iPod touch and iPhone devic- es can be used with this system. Made for • iPod touch (4th generation) •...

  • Page 58: Usb Memory

    1. AUDIO SYSTEM OPERATION USB MEMORY Audio CDs USB memory that can be used for MP3 and WMA playback. Use only discs marked as shown above. • USB communication formats: USB 2.0 The following products may not be play- FS (12 Mbps) able on your CD player.
  • Page 59 1. AUDIO SYSTEM OPERATION Low quality discs Correct Wrong Handle discs carefully, especially when you are inserting them. Hold them on the Labeled discs edge and do not bend them. Avoid getting fingerprints on them, particularly on the shiny side. Dirt, scratches, warping, pin holes, or other disc damage could cause the CD player to skip or to repeat a section of a...

  • Page 60: Mp3/Wma Files

    1. AUDIO SYSTEM OPERATION works or in other electronic content MP3/WMA FILES distribution systems, such as pay-audio or audio-on-demand applications. An inde- MP3 (MPEG Audio Layer 3) and WMA pendent license for such use is required. (Windows Media™ Audio) are audio com- For details, please visit pression standards.

  • Page 61: Cd-R And Cd-Rw Discs

    1. AUDIO SYSTEM OPERATION WMA files for WMA player: USB memory: Maximum number of folder in device: Ver. 7, 8 CBR  48 kbps to 192 kbps 3000 Ver. 9 CBR  48 kbps to 320 kbps Maximum number of files in one folder: WMA files for USB memory: Ver.

  • Page 62: Terms

    1. AUDIO SYSTEM OPERATION Frequent loading and ejecting of a Dual- ISO 9660 FORMAT Disc may result in scratches on the disc. Serious scratches can lead to playback This is the international standard for the problems on this unit. In some cases, a formatting of CD-ROM folders and files.
  • Page 63 1. AUDIO SYSTEM OPERATION...

  • Page 64: Bluetooth

    ® Bluetooth HANDS-FREE SYSTEM ® Bluetooth HANDS-FREE SYSTEM OPERATION 1. QUICK REFERENCE..... 64 2. HANDS-FREE SYSTEM ....65 USING THE VOLUME SWITCH AND MICROPHONE........66 ABOUT THE PHONEBOOK IN THIS SYSTEM..........67 WHEN YOU RELEASE YOUR CAR..67 PHONE STATUS DISPLAY....68 ®...

  • Page 65: Bluetooth Hands-Free System Operation

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION 1. QUICK REFERENCE This screen can be used to make a phone call. To display the “Phone” screen, press the button. Name Function Page “PWR/VOL” knob Turn this knob to adjust the volume. 77, 78 Talk button Activate the voice recognition mode.

  • Page 66: Hands-Free System

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION 2. HANDS-FREE SYSTEM ® This system supports Bluetooth INFORMATION ® Bluetooth is a wireless data system ● If your cellular phone does not support ® Bluetooth , this system will not function. by which you can call without your ●...

  • Page 67: Using The Volume Switch And Microphone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION USING THE VOLUME SWITCH AND MICROPHONE The actual design and button or ® The Bluetooth word mark and logos are microphone position will differ registered trademarks owned by Bluetooth depending on the vehicle. For details, SIG, Inc.

  • Page 68: About The Phonebook In This System

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION ABOUT THE PHONEBOOK IN INFORMATION THIS SYSTEM ● The other party’s voice will be heard from the front speakers. The audio sys- tem will be muted during phone calls or The following data is stored for every reg- when hands-free voice commands are istered phone.

  • Page 69: Phone Status Display

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION Indicates the receiving area. PHONE STATUS DISPLAY “Rm” is displayed when receiving in Roaming area. The receiving area may not be displayed depending on the phone you have. Indicates the level of reception. Poor Excellent ®...

  • Page 70: Register A Bluetooth ® Phone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION ® 3. REGISTER A Bluetooth PHONE When this screen is displayed, perform ® To use the Bluetooth hands-free device discovery from your system, you need to register your ® Bluetooth phone. phone into the system. Once you have registered it, you can make hands-free calls.

  • Page 71: Selecting And Adding A Bluetooth ® Phone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION When the connection is completed, SELECTING AND ADDING A this screen is displayed. ® Bluetooth PHONE have registered some ® Bluetooth devices, you can change the device connected and add a new device. Touch “Connect Phone”. Once you have registered it, the system ®...

  • Page 72: Call On The Bluetooth ® Phone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION ® 4. CALL ON THE Bluetooth PHONE ® After you register the Bluetooth BY PHONEBOOK phone, call using ® You can make a call using the Bluetooth hands-free system. phonebook data which is transferred from your cellular phone.

  • Page 73: By Speed Dial

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION WHEN THE PHONEBOOK IS BY SPEED DIAL EMPTY You can call using registered phone Touch “Contacts”. numbers which can be selected from a phonebook. (See “SPEED DIALS SETTING” on page 102 for registering the speed dial.) Press the button to display the “Phone”...

  • Page 74: By Call History

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION Touch BY CALL HISTORY You can make a call using the call history which has 4 functions below. All: all the calls (missed, incoming or out- going) Missed: calls which you missed Incoming: calls which you received Outgoing: calls which you made You can make a call using the latest Press the...

  • Page 75: By Voice Recognition

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION Say the command displayed on the BY VOICE RECOGNITION screen. Calls can be made by giving a voice command. This can be operated while driving. Press the talk button. If a desired outcome is not shown, or if no selections are available, perform one of the following to return to the previous screen:...
  • Page 76 ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION Say “Dial” to call the phone number. VOICE COMMAND EXAMPLE: CALL NAME Press the talk button. Say the name, or the name and type of phone, of a registered contact. VOICE COMMAND EXAMPLE: DIAL NUMBER Press the talk button.
  • Page 77 ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION As the system cannot recognize additional numbers, say the complete number with- out stopping. When the system recognizes multiple phone numbers, a phone number candi- date list will be displayed on the screen. If the desired phone number is not displayed on the top of the screen, say the number of the desired phone number from the...

  • Page 78: Receive On The Bluetooth Phone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION ® 5. RECEIVE ON THE Bluetooth PHONE When a call is received, this screen is displayed with a sound. To answer the phone: Touch To refuse to receive the call: Touch To adjust the volume of received call: Touch “-”...

  • Page 79: Talk On The Bluetooth ® Phone

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION ® 6. TALK ON THE Bluetooth PHONE While you are talking on the phone, WHEN YOU TOUCH “0-9” this screen is displayed. You can do Enter a number by touching the num- the operation below on the screen. ber keys.

  • Page 80: Interrupt Call

    ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION INTERRUPT CALL When the call is interrupted by the third party while talking, this screen is displayed. To answer the phone: Touch To refuse to receive the call: Touch Everytime you touch while interrupt call, the other party will be switched.
  • Page 81 ® 1. Bluetooth HANDS-FREE SYSTEM OPERATION...

  • Page 82: Setup

    SETUP SETUP OPERATION 1. QUICK REFERENCE..... 82 2. GENERAL SETTINGS ....83 SCREENS FOR GENERAL SETTINGS........... 83 3. GUIDANCE SETTINGS ....85 SCREEN FOR VOICE GUIDANCE SETTINGS........... 85 4. DISPLAY SETTINGS ..... 86 TURN OFF DISPLAY......86 CHANGING BETWEEN DAY AND NIGHT MODE........

  • Page 83: Setup Operation

    1. SETUP OPERATION 1. QUICK REFERENCE To customize the function settings, press the “SETUP” button. Name Function Page Settings are available for language selection, op- “General” eration sounds, screen animation, etc. “Guidance” Touch to set the voice guidance settings. Settings are available for contrast and brightness “Display”...

  • Page 84: General Settings

    1. SETUP OPERATION 2. GENERAL SETTINGS Settings are available for language se- SCREENS FOR GENERAL lection, operation sounds, screen ani- SETTINGS mation, etc. Press the “SETUP” button. On this screen, the following functions are operational. Function Touch “General”. You can change the language. (See “SELECTING LAN-...
  • Page 85 1. SETUP OPERATION SELECTING A LANGUAGE DELETE PERSONAL DATA Press the “SETUP” button. The desired language can be selected. Touch “General” on the “Setup” Press the “SETUP” button. screen. Touch “General” on the “Setup” Touch “Delete Personal Data”. screen. Touch “Language”. Touch “Delete”.

  • Page 86: Guidance Settings

    1. SETUP OPERATION 3. GUIDANCE SETTINGS Voice recognition guidance SCREEN FOR VOICE ® Bluetooth hands-free systems can be GUIDANCE SETTINGS set. Press the “SETUP” button. On this screen, the following functions can be performed. Function Touch “Guidance”. The voice guidance volume can be adjusted.

  • Page 87: Display Settings

    1. SETUP OPERATION 4. DISPLAY SETTINGS You can adjust the contrast and bright- TURN OFF DISPLAY ness of the screen. You can also turn the display off. Press the “SETUP” button. Press the “SETUP” button. Touch “Display” on the “Setup” screen.

  • Page 88: Changing Between Day And Night Mode

    1. SETUP OPERATION CHANGING BETWEEN DAY ADJUST CONTRAST/ AND NIGHT MODE BRIGHTNESS Press the “SETUP” button. Depending on the position of the head- light switch, the screen changes to day Touch “Display” on the “Setup” or night mode. screen. To display the screen in day mode Touch “General”...

  • Page 89: Bluetooth ® Settings

    1. SETUP OPERATION ® 5. Bluetooth SETTINGS You can confirm and change the REGISTERED DEVICES ® Bluetooth settings. Press the “SETUP” button. Press the “SETUP” button. Touch “Bluetooth*” on the “Setup” screen. Touch “Registered Devices”. This screen is displayed. Touch “Bluetooth*”. *: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
  • Page 90 1. SETUP OPERATION Touch “Add New” to register your When the connection is completed, this screen is displayed. ® Bluetooth device to the system. Once you have registered it, the system When this screen is displayed, perform ® automatically connects to your Bluetooth device discovery from...
  • Page 91 1. SETUP OPERATION ® REMOVING A Bluetooth DISPLAYING DEVICE DETAILS DEVICE Touch “Details” to display a device Touch “Remove” to remove your detail. ® Bluetooth device from the system. Select the device to display. Select the device to remove. This screen is displayed. INFORMATION ®...
  • Page 92 1. SETUP OPERATION Touch “OK”. Name Function “From Vehicle”: Connect the audio sys- name “Device Name” tem to the portable audio player. ® Bluetooth network. “From Audio Player”: Connect the porta- The address peculiar to ble audio player to the audio system. the system.

  • Page 93: Connect Phone

    1. SETUP OPERATION CONNECT PHONE CONNECT AUDIO PLAYER In case you register more than one In case you register more than one ® ® Bluetooth device, you need to choose Bluetooth device, you need to choose a favorite one. a favorite one. ®...

  • Page 94: Detailed Bluetooth Settings

    1. SETUP OPERATION ® Name Function DETAILED Bluetooth SETTINGS It is available to set wheth- “Bluetooth* er registered devices will Press the “SETUP” button. Power” be connected automatical- ly or not. Touch “Bluetooth*” on the “Setup” name screen. “Device ® Bluetooth network.
  • Page 95 1. SETUP OPERATION ® CHANGING THE Bluetooth EDITING THE PASSCODE POWER Touch “Passcode”. Touch “Bluetooth* Power”. Input a passcode and touch “OK”. Touch “On” or “Off”. CHANGING THE DISPLAY Touch “Save”. PHONE STATUS In case that the state of “Bluetooth* Power”...
  • Page 96 1. SETUP OPERATION When you start your vehicle and the Touch “Save”. ® Bluetooth portable audio player When you start your vehicle and the automatically connected, the connection ® Bluetooth phone automatically check is displayed. connected, connection check displayed. You can select the state of “Display Audio Player Status”.

  • Page 97: Phone Settings

    1. SETUP OPERATION 6. PHONE SETTINGS Phone settings can be changed. PHONE SOUND SETTINGS Press the “SETUP” button. Touch “Phone Sound Settings”. Change each setting according to the following procedures. Touch “Phone”. When you complete all settings, touch Touch the items to be set. “Save”.

  • Page 98: Phonebook

    1. SETUP OPERATION RING TONE VOLUME SETTING PHONEBOOK Touch “Ring Tone Volume”. Press the “SETUP” button. Touch “-” or “+” to adjust the ring vol- Touch “Phone”. ume. Touch “Phonebook”. Touch “OK”. Touch the items to be set. RING TONE SELECTING Touch “Ring Tone”.
  • Page 99 1. SETUP OPERATION Touch “Transfer Contacts”. PHONEBOOK SETTINGS Touch “Manage Contacts”. PBAP compatible models This screen is displayed. (See page 99.) Touch the items to be set. Please refer to the following pages for each setting. TRANSFERRING A PHONE NUMBER You can transfer the phone numbers in PBAP incompatible but OPP compatible ®...
  • Page 100 1. SETUP OPERATION ■ ■ AUTOMATIC PHONEBOOK DOWN- UPDATE CONTACTS (PBAP COM- LOAD SETTING (PBAP COMPATI- PATIBLE MODELS) BLE MODELS) You can update contacts. ® The first time when the Bluetooth Touch “Update Contacts”. phone is connected when you start your vehicle, phonebook data is auto- matically transferred to the system.
  • Page 101 1. SETUP OPERATION ■ This screen appears while transferring. To REPLACE OR ADD CONTACTS cancel it, touch “Cancel”. If the transfer- (PBAP INCOMPATIBLE BUT OPP ring is interrupted on the way, when the COMPATIBLE MODEL) phone supports OPP service, the phone- book data transferred until then can be You can also display the “Transfer memorized in the system.
  • Page 102 1. SETUP OPERATION Touch “Options”. DELETING THE PHONEBOOK DATA You can delete the data. When you release your car, delete all your data on the system. For PBAP compatible phone, delete the phonebook data after setting “Au- tomatically Download Contact” to “Off”. Touch “Delete”.
  • Page 103 1. SETUP OPERATION You can also display the “Speed Dials” SPEED DIALS SETTING screen in the following way. Speed dials setting is accessed from From “Speed Dial” screen the “Speed Dials” screen. Press the button. Press the “SETUP” button. Touch “Speed Dials”. Touch “Phone”.
  • Page 104 1. SETUP OPERATION ■ ■ REGISTERING THE SPEED DIAL REGISTERING THE SPEED DIAL FROM CONTACTS FROM CALL HISTORY Touch “New Speed Dial from Call You can register the phone number History”. from phonebook. Up to 18 numbers per phone can be registered. Touch “New Speed...
  • Page 105 1. SETUP OPERATION From “Contact” screen You can also register the speed dial in the following ways. Press the button. From “Speed Dial” screen Touch “Contacts”. Press the button. Select the data from the list. Touch “Speed Dials”. Touch “Options”. Touch “(add new)”.
  • Page 106 1. SETUP OPERATION ■ From “Call History” screen DELETING THE SPEED DIAL Press the button. You can delete the speed dial. Touch “Call History”. Touch “Delete Speed Dials”. Touch the desired phone number. Touch “Add Speed Dial”. Select the data you want to delete or touch “All Delete”.
  • Page 107 1. SETUP OPERATION You can also delete the call history in DELETING CALL HISTORY the following way. You can delete the call history. Press the button. For PBAP compatible phone, delete the phonebook data after setting “Au- Touch “Call History”. tomatically Download Contact”...

  • Page 108: Audio Settings

    1. SETUP OPERATION 7. AUDIO SETTINGS Select the desired setting from “HD HD Radio™ system can be set using the following procedure: Radio/Analog Setting”. Press the “SETUP” button. Screen button Function Touch to receive both ana- “All” log and digital broadcasts. Touch “Audio”.

  • Page 109: System Settings

    1. SETUP OPERATION 8. SYSTEM SETTINGS Touch “Save”. Vehicle type settings can be changed. Press the “SETUP” button. Touch “System”. Touch “Vehicle Setting”. Touch the desired vehicle type to be set.

  • Page 110: Specifications / Index

    SPECIFICATIONS / INDEX...

  • Page 111: Specifications

    SPECIFICATIONS WMA decoding format General ..Ver. 7, 7.1, 8, 9, 10, 11 (2ch audio) Power source ......13.2 V DC (Windows Media Player) (10.5 V to 16.0 V allowable) Grounding system....Negative type Maximum current consumption..18 A AM tuner Frequency range Dimensions (W ×...

  • Page 112: Alphabetical Index

    ALPHABETICAL INDEX ALPHABETICAL INDEX Adjust contrast/brightness......87 Balance .............23 ® AM............. 25 Bluetooth audio ........46 ® AUDIO button........14, 20 Connecting a Bluetooth audio player ..........48 Audio settings ......... 107 ® Playing a Bluetooth audio player..50 Audio system ..........19 ® Switching to Bluetooth audio mode ..47 Audio system operating hints....
  • Page 113 ALPHABETICAL INDEX ALPHABETICAL INDEX Call history ..........73 Day mode ..........87 ® Call on the Bluetooth phone....71 Delete personal data ........ 84 By call history ........73 Dial ............71 By dial............71 Disc slot............ 31 By phonebook........71 Display settings ........86 By speed dial .........72 DSP control ..........
  • Page 114 ALPHABETICAL INDEX Hands-free system........65 MP3............34 About the phonebook in this system ..67 Multicast ............29 Phone status display ......68 Using the volume switch and microphone ........66 Overview buttons ........14 When you release your car ....67 HD radio™ ..........28 HD radio™...
  • Page 115 ALPHABETICAL INDEX ALPHABETICAL INDEX Radio............25 SEEK/TRACK button......14, 20 Presetting a station........25 Selecting a language........ 84 Radio broadcast data system ....26 Setup ............81 Selecting a station .........26 SETUP button ........14, 82 Switching to radio mode ......25 Shuffle mode ..........39 Traffic announcement......27 Sound Controls.........
  • Page 116 ALPHABETICAL INDEX USB memory..........40 Connecting a USB memory....40 Playing a USB memory ......41 Switching to USB mode......40 Volume adjustment ....... 14, 20, 64 WMA ............34...
  • Page 117 <KOKZ13B> <CRB4218-A> UC <CVH-2238ZT>...
