EuroKitchen Spagna Vetro SV218E-IM Installation Manual And User's Manual

Spagma vetro 218 series

Advertisement

Quick Links

Installation Guide
and Users Manual
SPAGNA VETRO 218 Series
(SV218E-IM)
IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Island Mount Range Hood
Rev. 2025u.1b

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spagna Vetro SV218E-IM and is the answer not in the manual?

Questions and answers

Summary of Contents for EuroKitchen Spagna Vetro SV218E-IM

  • Page 1 Installation Guide and Users Manual SPAGNA VETRO 218 Series (SV218E-IM) IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Island Mount Range Hood Rev. 2025u.1b...
  • Page 3: Important Safety Notice

    Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction.
  • Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
  • Page 5: Table Of Contents

    Table of Contents INSTALLATION USE AND CARE Tools needed............3 Range hood operations......13-14 Parts supplied...........4 Troubleshooting...........15 Venting requirements........5 Use and care information.......16 Mount heights & clearance......5-6 Specifications..........16 Calculating vent system length.......6 Wiring diagram..........17 Venting methods..........7 MAINTENANCE Ductless conversion.........7 Cleaning, replacing filter & light bulb..18 Charcoal filters &...
  • Page 6: Parts Supplied

    Range Hood (vary with model) Parts supplied: Flappers Air diverter (Optional re-circulating kit) Support Frame Structure Charcoal Filter (Optional re-circulating kit) Upper standard chimney Lower standard chimney Flexible Duct Tube (Optional) Aluminum Filter(s) Description Quantity Hexagonal Wood Screws 4 Pcs Duct Set 1 Set Inner Supporting Frame with Top Plate...
  • Page 7: Venting Requirements

    Venting Requirements Height & Clearance • Vent system must terminate to the outside Support Maximum* ceiling clearance (roof or side wall). 101” at 31” hood mounting Structure height above countertop/stove • DO NOT terminate the vent system in an at- (may vary with different tic or other enclosed area.
  • Page 8: Calculating Vent System Length

    IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct.
  • Page 9: Venting Methods

    Venting Methods • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- tions, see Recirculating (Non-Vented) Kit on page 10. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: •...
  • Page 10: Charcoal Filters & Electrical Requirements

    Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. Remove aluminum filters on hood. Position the charcoal filters onto each side of the motor and turn until it locks. Re-install aluminum filters. Charcoal filters must be replaced after 120 hours of use (or approximately every 2 to 3 months based on the average of 1 to 2 hours of daily cooking time).
  • Page 11: Preparation

    Preparation WARNING Excessive Weight Require three or more person to move and install this range hood. Spinal or other bodi- ly injuries could occur if it is not followed. Advanced Preparations: Read the entire installation guide and users manual thoroughly, understand instructions and warnings. Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13.
  • Page 12: Installation

    Installation Installations (refer to Page 4 for parts): As illustrated in Figure 1A, drill four holes with diam- eter not exceeding 5/8” and depth of 3” to 3-1/2” on the false ceiling. Fasten two hexagonal wood screws at two of these holes opposite from each other, reserve approx- imately 1/8”...
  • Page 13: Installation

    Installation (Continued) WARNING As shown in Figure 4A, 4B and 4C, slide in both upper chim- Excessive Weight ney and lower chimney, pay extra attention to sharp edges Require three or more person to move and on the chimneys and minimize chimney movements to avoid install this range hood.
  • Page 14 Installation (Continued) WARNING Due to excessive weight, two or more person is recommended for this step. Install the hood body onto the support frame and secure Excessive Weight it with sixteen (16) 4mm x 16mm Phillips Head Tapping Require three or more person to move and install this range hood.
  • Page 15: Range Hood Operations

    Range Hood Operations Control Panel Layout and Buttons Configurations: Control Panel La o t and B ttons Config rations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator The range hood is designed to remove smoke, cooking vapors and odors from the cook top area.
  • Page 16: Range Hood Operations

    Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator • Controls: • Adjusting the timer function: •...
  • Page 17: Troubleshooting

    Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected.
  • Page 18: Use And Care Information

    Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing.
  • Page 19: Wiring Diagram

    Wiring Diagram Six Speed with Type GU10 Bulb Six Speed with Type MR16 Bulb Page 17...
  • Page 20: Cleaning, Replacing Filter & Light Bulb

    Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •...
  • Page 21: Coverage & Exceptions

    Warranty must rese sent chas date Pl Plea ease a an h a hase l e les re rece i n invo i in d e der ai ain se serv i c ice d e der warr rran One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects.
  • Page 22: Disclaimer & Contact Information

    Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately.
  • Page 23 Your Notes Page 21...
  • Page 24 Euro-Kitchen, Inc. 2341 Industrial Parkway West Hayward, CA 94545 Ph: 510.266.0099 Fax: 510.266.6630 http://www.euro-kitchen.com...
