Hanover HANFU14FAW Instruction Manual

Upright freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Manual
UPRIGHT FREEZER
Model: HANFU14FAW
1

Advertisement

Table of Contents
loading

Related Manuals for Hanover HANFU14FAW

Summary of Contents for Hanover HANFU14FAW

  • Page 1 Instruction Manual UPRIGHT FREEZER Model: HANFU14FAW...
  • Page 2 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

  • Page 3: Proper Use Of Freezer

    PROPER USE OF FREEZER Setting Up the Freezer Before using the freezer, remove all packaging, including bottom cushion, foam pads, and rubber belts packed in the freezer Clean the outside and inside of the freezer with a rag and warm water (a little detergent can be added into the warm water, if necessary).

  • Page 4: Install The Door Handle

    To prevent damage to the power cord and any consequent incidents, the power cord should not be covered by the freezer or other objects. Before switching on the fridge, please check carefully whether the voltage range of the freezer is the same as that of the power supply.
  • Page 5 INSTALL THE DECORATIVE KICK PLATE Setting Up the Freezer Open the door, take out the decorative kick plate, and remove the three setscrews from the bag with the Instructions. For installation method, see the below diagram.

  • Page 7: Parts List

    PARTS LIST Note: Figure in the user manual are only for reference. The actual product may differ slightly. 1) Lamp Switch 2) Lamp Cover 3) Temperature Sensor Gap 4) Steel Wire Freezer Shelf 5) Outlet Airflow Gap 6) Inlet Airflow Gap 7) Steel Wire Drawer 8) Door Tray 9) Steel Wire Door Tray...

  • Page 8: Safety Precaution

    SAFETY PRECAUTION Please always follow the safety hints listed below: The power supply should be a standard tri-prong socket. DO NOT use and extension cord or a ground bypass to plug in this freezer. The unit should be operated in the absence of flammable or explosive fumes. It is prohibited to put flammable, acidic, or volatile substances into the freezer.
  • Page 9 POSITIONING The unit should be placed in a well-ventilated and dry environment. Do not put the unit in direct sunlight, and keep it as far as possible from heat sources. The unit should be placed on flat and steady ground. Keep the unit level by adjusting the front leg levelers.

  • Page 10: Operation Check

    Install this appliance in an area where the ambient temperature is between 32⁰ F (0⁰C) and 110⁰F (43⁰C). If the temperature is too high or too low, the cooling ability of the freezer may be affected. There should be enough space around the unit to allow for proper ventilation. No less than 4 inches of clearance from the back of the freezer is required to account for proper heat emission.

  • Page 11: Frozen Food Storage

    After plugging the unit in for the first time, wait 30 minutes, then ensure that cold air is moving through the cabinet. Set the freezer to the desired temperature (Ranging from -8⁰F ~ 7⁰F (-22⁰C ~ -14⁰C) FROZEN FOOD STORAGE The optimum temperature for long-term food preservation in the freezer is 0⁰F.

  • Page 12: Food Storage

    FOOD STORAGE Any hot food must be cooled down to room temperature before it is put into the freezer. Please do not put glass containers filled with liquid into the freezer compartment, as glass may break. It is better to sort the food items before putting them into the freezer. Keep the same types of foods together to help minimize the number of times that the freezer door is opened, and help save energy.

  • Page 13: Introduction Of The Functions

    INTRODUCTION OF THE FUNCTIONS 1) Alarm Lamps a. Hi-Temp (High Temperature Alarm) b. Door Open (Door Ajar for 60 Seconds or More) 2)Buttons c. Quick Freeze Button d. ⁰C or ⁰F Temperature Switch Button e. Alarm Reset Button...
  • Page 14 Lock/Unlock Button g. Temperature Setting/Quick Freeze Time Setting down h. Temperature Setting/Quick Freeze Time Setting up 3) Function Freezer Temperature Setting Press button E or F to set the freezer temperature between -8⁰F ~ 7⁰F (-22⁰C ~ -14⁰C). Press button D to lock the temperature. Temperature change will take effect 10 seconds later. Press button D again to unlock the temperature Quick Freeze Function Setting To enter Quick Freeze mode: Press button A and hold for 3 seconds.

  • Page 15: Maintenance

    MAINTENANCE CLEANING Always unplug the unit before cleaning. The unit should be cleaned frequently, both inside and outside, using warm water and a small amount of neutral detergent or baking soda. Never use boiling water, harsh cleaning agents, acid, alkali, or benzene based cleaners.

  • Page 16: Troubleshooting

    If the unit will be powered off and not used for an extended period of time, unplug it and clean the unit thoroughly. Ensure that the door is propped open slightly and place the unit in a well-ventilated area to avoid any odor or build-up.

  • Page 17: Changing The Light Bulb

    TROUBLESHOOTING THE FOLLOWING PHENOMENA ARE NORMAL The sound of moving water is caused by the refrigerant flowing inside the system piping While the unit runs, heat is emitted from both sides of the cabinet. When the weather is too humid, the edges around the door may have a little moisture build-up. Use a dry cloth to wipe it dry.
  • Page 18 Make sure that the light bulb is AC115V/60Hz/MAX.40W (E 12)
  • Page 19 TROUBLE SHOOTING Light cover Take down the two screws Light base Take Light Light bulb cover down Before changing the light bulb,please unplug the fridge first, then pull down the light cover and change the light bulb according to the picture as shown above. Make sure the light bulb is AC115V/60Hz/ MAX.40W(E 12).
