Summary of Contents for Xycom 5015SLR
- Page 1 5015SLR Sunlight Readable Flat Panel Industrial Touch Monitor User Manual © © © © 2007 XYCOM AUTOMATION, LLC Printed in the United States of America...
- Page 2 Trademark Information Xycom and Xycom Automation are trademarks of Xycom Automation, L.L.C. Xycom Automation, L.L.C. now is referred to as Pro-face through a D.B.A. The Pro-face name and logo will replace the Xycom name and logo on all documents where possible.
-
Page 3: Table Of Contents
Unpacking the Unit..............................2 ................................2 UICK TARTUP CHAPTER 2 – INSTALLATION.............................3 ..............................3 RODUCT IMENSIONS 5015SLR Dimensions (Black Bezel) ........................3 5015SLR Dimensions (Stainless Steel Bezel) .......................4 Front Panel Controls ..............................5 Rear Panel Controls...............................5 I/O Panel ................................6 .........................7 OCATION AND NCLOSURE ONSIDERATIONS ..............................8... -
Page 4: Chapter 1 - Introduction
Pro-face/Xycom’s 5015SLR sunlight readable, high-resolution flat panel monitor reflects the latest technology. The 5015SLR incorporates an industrialized enclosure, a high bright LCD display with a resistive touch screen containing integrated films that attenuate UV light and allows transmission of visible light. -
Page 5: Unpacking The Unit
5015SLR Flat Panel Industrial Touch Monitor Chapter 1 - Introduction Unpacking the Unit When you remove the 5015SLR from its shipping box, verify that you have the parts listed below. Save the box and inner wrapping in case you need to reship the unit. •... -
Page 6: Chapter 2 - Installation
Chapter 2 – Installation Product Dimensions 5015SLR Dimensions (Black Bezel) Figure 2-1. 5015SLR Dimensions 144812(D) -
Page 7: 5015Slr Dimensions (Stainless Steel Bezel)
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation 5015SLR Dimensions (Stainless Steel Bezel) Figure 2-2. Stainless Steel 5015SLR Dimensions 144812(D) -
Page 8: Front Panel Controls
Front Panel Controls Figure 2-3. 5015SLR Front Panel Controls Rear Panel Controls Figure 2-4. Stainless Steel 5015SLR Rear Panel Controls Table 2-1. 5015SLR Front and Rear Panel Controls Functions LCD ON/OFF Power On/Off POWER (LED) Power Indicator On = Power On, Off = Power Off AUTO Automatically optimize positions, phase &... -
Page 9: I/O Panel
Used to enable or disable (lock) adjustment buttons on front of monitor Video Inputs The 5015SLR monitor has two video input options: Digital Video Input (DVI), a DVI-D connector, for digital signal input to an analog monitor; VGA Input (VGA), to connect this VGA monitor for standard analog input from a computer. -
Page 10: Location And Enclosure Considerations
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Location and Enclosure Considerations • Account for the unit dimensions and operational thermal environment when selecting an installation location or enclosure (see page 3, 11, and 28 for unit dimensions and thermal specifications). -
Page 11: Panel Installation
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Panel Installation This monitor should be mounted and used where NEMA 4 and NEMA 12 type enclosures are employed. When mounted properly, the monitor meets or exceeds the sealing requirements set forth in the NEMA 4 and NEMA 12 specifications (per NEMA 250). - Page 12 5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Figure 2-7. Black Bezel Mounting Clip Locations 144812(D)
- Page 13 Mounting into a 5015SLR Opening The 5015SLR has 14 total mounting clips: 4 on both the top and bottom of the monitor, and 3 mounting clips on both of the sides. Hold the monitor in place while you install the mounting clips (see Figure 2-7 or Figure 2-8 for mounting clip locations).
-
Page 14: Power Management
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Panel Mounting Clip Display Unit Figure 2-9. Fastening the Monitor to the Panel Caution Over-tightening the clips can cause damage to the monitor, which can result in loss of seal integrity. - Page 15 5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation (no solder), continuous, and able to safely conduct the ground-fault current in the system with minimal impedance (minimum wire required is 18 AWG, 1 mm). Observe the following practices: •...
-
Page 16: Excessive Heat
– DC Return Input Protective Earth Ground Caution: Use AWG18 wire or greater for the 5015SLR’s power cable. Isolate the AC main circuit line, I/O signal lines, and power cord - do not bind or group them together. Excessive Heat... -
Page 17: Line Voltage Variation
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Noise commonly enters through input, output, and power supply lines and may also be coupled through the capacitance between these lines and the noise signal carrier lines. This usually results from the presence of high voltage or long, close-spaced conductors. - Page 18 5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation It is the responsibility of the customer to ensure that the product is properly rated for the location. If the intended location does not presently have a Class, Division, and Group rating, then users should consult the appropriate authorities having jurisdiction in order to determine the correct rating for that Hazardous Location.
-
Page 19: Definitions
Combustible dusts of an electrically conductive nature may be present in • • • • hazardous quantities. Note Pro-face/Xycom 5015SLR systems are not suitable for installation within Division 1 locations. Note Electrical equipment cannot be installed in Division 1 locations unless they are intrinsically safe, installed inside approved explosion-proof enclosures, or installed inside approved purged and pressurized enclosures. - Page 20 5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Division 2 Locations Class I volatile flammable liquids or flammable gasses are handled, processed, • • • • or used, but confined within closed containers or closed systems from which they can escape only in cases of accidental rupture or breakdown of such enclosures or systems, or in case of abnormal operation of equipment.
-
Page 21: Power Switch
USB connections can be used when the 5015SLR is installed within a suitable enclosure, such that the USB cables are not operator accessible. If the USB cable leaves the enclosure, then it must have adequate strain relief provided by the system integrator/customer. -
Page 22: Operation And Maintenance
5015SLR Flat Panel Industrial Touch Monitor Chapter 2 – Installation Operation and Maintenance The systems have been designed for compliance with relevant spark ignition tests. However, please note that the workstation front panel contrast adjustment tactile switches and keyboard connector are the only make/break components intended to be exercised by the operator in the course of normal operation. -
Page 23: Chapter 3 - Monitor Settings
Mode and Image Adjustment Not all video controllers produce exactly the same video output levels or the same timing. The 5015SLR uses on-screen configuration menus to make setup and adjustment easy. For units with black bezels, the menus are selected and the menu items are adjusted using the buttons located on the front panel of the monitor. - Page 24 5015SLR Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Brightness Contrast Clock Phase H. Position V. Position Sharpness Option Volume Mute Note: This feature only exists on the black bezel units and is currently not used. Auto Brightness Off...
- Page 25 5015SLR Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings 9300 7500 6500 User Green Blue … English Français … Deutsch … … Español Italiano OSD Time Out OSD Position OSD Transparen Auto Setting Recall Aspect Ratio Option Analog...
-
Page 26: Recall The Factory Default Settings
5015SLR Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Light Enable Light Contrast Light Bright Light H Start Light H Width Light V Start Light V Height Note: This feature only exists on the black bezel units. Recall the Factory Default Settings Follow these steps to reset the factory default settings for the OSD. -
Page 27: Video Modes
5015SLR Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Video Modes The following video modes are supported on the 5015SLR flat panel SXGA monitor: • 1280 x 1042 • 1024 x 768 • 800 x 600 • 640 x 480 NOTE All video modes are non-interlaced. -
Page 28: Chapter 4 - Operator Input
3. Choose “Flat Panel Monitors” from the links at the top of the home page and then choose the “5015SLR” on the next page. From the 5015SLR page, you can download the User Manual and/or the appropriate touch screen driver. -
Page 29: Calibrating The Touch Screen
5015SLR Flat Panel Industrial Touch Monitor Chapter 4 – Operator Input Calibrating the Touch Screen You need to calibrate the touch screen in the following cases: The cursor does not follow the movement of your finger or pen. • • • •... -
Page 30: Chapter 5 - Hardware
Chapter 5 – Hardware VGA Input Connector Analog Signal Input Connector Pin (D-sub connector with 15 pins) Table 5-1. VGA Input Connector Pinout D-Shell (Female) Symbol Description Red, analog Green, analog Blue, analog Reserved for monitor ID bit 2 (grounded) DGND Digital Ground AGND... -
Page 31: Dvi-D Input Connector
5015SLR Flat Panel Industrial Touch Monitor Chapter 5 – Hardware DVI-D Input Connector The DVI-D Input Connector is a D-sub connector with 26 pins (P3). Table 5-2. DVI-D Input Connector Pinout Signal Name Signal Name TMDS Data 2- TMDS Data 2+... -
Page 32: Touch Screen Rs-232 Output Connector
Clear To Send Note Since all serial interface signals are the same on the PC side, use a straight cable to connect the 5015SLR to the PC. Touch Screen USB Output Connector Table 5-4. Touch Screen USB Output Pinout Symbol... -
Page 33: Hardware Specifications
Appendix A – Technical Specifications Hardware Specifications Table A–1. 5015SLR Hardware Specifications Characteristic Specification Mechanical* Height 13.78” (350.01 mm) Width 16.48” (418.59 mm) Depth 2.9” (73.66 mm) Weight 15.1 lbs (6.85 kg) Electrical AC Power 100-240 VAC, 1.0A, 50/60 Hz, 70W Nominal DC Power 19-30 VDC, 3.5A maximum, 66.5W Nominal... -
Page 34: Environmental Specifications
5015SLR Flat Panel Industrial Touch Monitor Appendix A – Technical Specifications Environmental Specifications Table A-2. 5015SLR Environmental Specifications Characteristic Specification Temperature Operating 0° to 50° C (32° to 122° F) Non-operating -20° to 60° C (-4° to 140° F) Humidity... -
Page 35: Before Contacting Technical Support
Appendix B – Technical Support Pro-face Technical Support offers a variety of support options to answer any questions on Pro-face products and their implementation. Before Contacting Technical Support Refer to the relevant chapter(s) in your documentation for a possible solution to any problem you may have with your system. -
Page 36: Product Repair Program / Returning A Unit To Pro-Face
5015SLR Flat Panel Industrial Touch Monitor Appendix B – Technical Support Product Repair Program / Returning a Unit to Pro-face Pro-face’s Product Repair & Customization Department (PR&C) restores equipment to normal operating condition and implements engineering changes that enhance operating specifications. Pro-face tests products returned to Pro-face with the standard Pro-face test diagnostics. - Page 37 144812(D) Xycom Automation, L.L.C. Canada Sales: 905-607-3400 750 North Maple Rd. Northern Europe Sales: +44-1604-790-767 Saline, MI 48176 Southern Europe Sales: +39-011-770-53-11 Phone: 734-429-4971 Fax: 734-429-1010 http://www.profaceamerica.com...
