Masterbuilt Manufacturing, Inc
1 Masterbuilt Court
Columbus, Georgia 31907
Customer Service 1-800-489-1581
ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
ELECTRIC SMOKER MODELS 20070111, 20071712
THIS PRODUCT IS FOR OUTDOOR USE ONLY ~ HOUSEHOLD TYPE
Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver.
CARBON MONOXIDE HAZARD
Burning wood gives off carbon
monoxide which can cause death.
DO NOT burn wood chips inside homes,
vehicles, tents, garages or any enclosed
areas.
Use only outdoors where it is well
ventilated.
Failure to follow these warnings and instructions properly could result in personal injury or death.
WARNING
This manual contains important
information necessary for the proper and
safe use of this unit.
Read and follow all warnings
and instructions before using
smoker and during use.
Keep this manual for future reference.
Some parts may have sharp edges.
Handle with care.
Advertisement
Table of Contents
Related Manuals for Cookmaster 20070111
Summary of Contents for Cookmaster 20070111
- Page 1 ASSEMBLY, CARE & USE MANUAL WARNING & SAFETY INFORMATION ELECTRIC SMOKER MODELS 20070111, 20071712 THIS PRODUCT IS FOR OUTDOOR USE ONLY ~ HOUSEHOLD TYPE Masterbuilt Manufacturing, Inc 1 Masterbuilt Court Columbus, Georgia 31907 Customer Service 1-800-489-1581 Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver.
-
Page 2: Limited Warranty Information
LIMITED WARRANTY INFORMATION WARNINGS & IMPORTANT SAFEGUARDS Masterbuilt warrants its products to be free from defects in material and workmanship under proper assembly, normal use and recommended care for 90 days from the date of original retail purchase. READ ALL INSTRUCTIONS Masterbuilt warranty does not cover paint finish as it may burn off during normal use. - Page 3 MASTERBUILT SMOKIN’ RECIPES MASTERBUILT SMOKIN’ RECIPES MASTERBUILT SMOKIN’ RECIPES MASTERBUILT SMOKIN’ RECIPES WARNINGS & IMPORTANT SAFEGUARDS continued • Never move electric smoker when in use. Allow electric smoker to cool completely before moving or storing. SMOKED STUFFED SALMON MAPLE GLAZED HAM Servings for 4 Servings for 6-8 •...
-
Page 4: Troubleshooting Guide
TROUBLESHOOTING GUIDE DO NOT RETURN TO RETAILER STOP! For Assembly Assistance, Missing or Damaged Parts Call: MASTERBUILT Customer Service at 1-800-489-1581 or EMAIL us at: customerservice@masterbuilt.com. PARTS LIST Symptom Cause Possible Solution Power light won’t come on Not plugged into wall Check wall connection House fuse tripped Make sure other appliances are not... -
Page 5: Hardware List
WOOD SMOKING GUIDE FOR MEATS HARDWARE LIST WOOD FLAVOR POULTRY FISH BEEF PORK LAMB Hickory Pungent, smoky, bacon-like flavor M6x12 #8-32 Lock Nut Handle Bushing Mesquite Phillips Head Screw Qty: 1 Qty: 1 Sweet and delicate flavor Qty: 18 Alder... - Page 6 OPERATION INSTRUCTIONS ASSEMBLY INSTRUCTIONS Step 1: Plug power cord into an outlet (refer to Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver. “Warnings & Important Safeguards” section of manual). Step 2: Turn dial to set temperature. Ready light Step 1 will turn off when unit has reached set temperature Carefully position smoker as and is ready for use.
- Page 7 SMOKER IS NOW READY FOR USE ASSEMBLY INSTRUCTIONS Step 3 Insert temperature gauge (3) through slotted hole in smoker door (2) and secure into place with retainer ring (G). Insert door handle (4) through smoker door (2). Place washer (E), handle bushing (C) and door latch (D) onto handle.
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS (*Some parts not shown for clarity.) SOME PARTS NOT SHOWN FOR CLARITY Step 5 Step 7 Align control panel (7) with smoker Set wood chip tray (12) and water body (1), rest element of control bowl (13) into wood chip grate (11) panel (7) onto element support (8).
