10' x 17' Staged-Bounce Rectangular Trampoline
Assembly, Installation, Care, Maintenance, and Use
Read these materials prior to assembling and using this trampoline
Retain address information for future use.
JumpSport, Inc.
2055 South 7th Street, Suite A
San Jose, CA 95112 U.S.A.
User's Manual
WARNING
DO
NOT
attempt
or
somersaults.
Landing
head or neck can cause serious
injury, paralysis or death, even
when landing in the middle of the
bed.
Use trampoline only with mature, knowledgeable supervision.
Instructions
allow
on
the
The maximum user weight is 225 pounds. This
trampoline is not recommended for use by children
under six years of age.
1
DO NOT allow more than one
person on the trampoline.
Use by more than one person
at the same time can result in
serious injury.
408-213-2551
www.jumpsport.com
