Mountaineer 2009
Blue Ridge
ASSEMBLY MANUAL
Copyright © 2009 Gorilla Playsets
All Rights Reserved
Gorilla Playsets
190 Etowah Industrial Court
Canton, GA 30114
(800) 882-0272
5/MAY/2009 – Version 1.4.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blue Ridge Mountaineer 2009 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorilla Playsets Blue Ridge Mountaineer 2009

  • Page 1 Mountaineer 2009 Blue Ridge ASSEMBLY MANUAL Copyright © 2009 Gorilla Playsets All Rights Reserved Gorilla Playsets 190 Etowah Industrial Court Canton, GA 30114 (800) 882-0272 5/MAY/2009 – Version 1.4.2...
  • Page 2 STOP…PLEASE READ!! IF YOU HAVE MISSING OR DAMAGED PARTS OR NEED ASSISTANCE ASSEMBLING, PLEASE CALL gorilla playsets MANUFACTURING DIRECT. (800) 882-0272 FACTORY HOURS – MON.–FRI., 8AM-5PM EST DO NOT RETURN THIS PRODUCT TO THE RETAILER OR CONTACT THE RETAILER DIRECT. THE RETAILER DOES NOT STOCK COMPONENTS.
  • Page 3 Blue Ridge Mountaineer TABLE OF CONTENTS Warranty and Safety Guidelines………………………….……………………….…..4-10 Kit Contents and Tool List…………..……………………….……………………….11-28 Framing the play set...………………………………………...……………..…...steps 1-7 Constructing deck and upper panel boards………………..……………..…..steps 8-10 Constructing rock wall and securing to fort…………………………..…..steps 11-15 Constructing and attaching ladder..….……..………….…………………….steps 16-17 Assembling Tic-Tac-Toe Panel……………………………………………….steps 18-19 Installing panel slats and Tic-Tac-Toe Panel..…..………..…………...…………step 20 Assembling Swing……………………………..………..…..………..…..steps 21-28...
