Summary of Contents for Axxion ADVP-204
- Page 1 USER MANUAL ADVP-204 DVD/MPEG4/CD/MP3/PLAYER Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
-
Page 2: Table Of Contents
Content INTRODUCTION Safety Precautions Panel Illustration Remote Control CONNECTIONS Connecting to a TV set Advanced Features MP3/WMA/MPEG4 playing PICTURE CD PLAYBACK SYSTEM SETUP OTHERS Specifications Accessories... -
Page 3: Safety Precautions
Safety Precautions Battery Disposal CAUTION Please ensure batteries are disposed of safely. RISK OF ELECTRIC SHOCK Never dispose of batteries in a fire or with other household DO NOT OPEN waste. Check with your local authority for disposal regulations. Safety is Important To ensure your safety and the safety of others, please This symbol indicates that this product incorporates double read the Safety Instructions before you operate this... -
Page 4: Panel Illustration
Panel Illustration PREVIOUS BUTTON LCD DISPLAY NEXT RIGHT SPEAKER PLAY LEFT SPEAKER DISC DOOR STOP OPEN DISC TOP BATTERY CHARGE INDUCATOR SETUP BUTTON SENSOR MENU BUTTON POWER (ON/OFF) SWITCH TFT ON/OFF DC 12V INPUT JACK (power supply) MOVE ( PHONE JACK SOURCE AV OUTPUT JACK PAUSE... -
Page 5: Remote Control
Remote Control Remote Control Note: 1. In this manual, will be used to represent the different NAVIGATION ARROW S on the remote control. 2 In order to operate any of the remote functions. First push the Power switch in “ON” position. 3. -
Page 6: Connections
C onnecting to a TV Set Connections Phone Jack Function Insert the earphone into the earphone jack, to listen the music or movie privately. Battery charging When the unit battery is powered out, connect the AC adapter onto the unit. the battery will charge automatically. Volume adjust Use VOLUME CONTROLL in the side of the unit to adjust the volume. -
Page 7: Mp3/Wma/Mpeg4 Playing
MP3/WMA/MPEG4 PLAYING Insert the MP3/WMA/MPEG4 disc, use navigation keys to open the desired directory. Press ENTER to enter the sub directory. Use the navigation keys to select the desired track and then ENTER to play the file. Press the PLAY/PAUSE key to pause the playback, press the stop key to stop the play. -
Page 8: Picture Cd Playback
PICTURE CD PLAYBACK SYSTEM SETUP MENU OPERATION Press the SETUP button on the remote control and the SETUP MENU will be displayed. Use the direction buttons for up and down movement to select the desired item, then press the ENTER button to confirm. Press LEFT direction button return to the main menu. - Page 9 SYSTEM SETUP DVD Menu RATING SETUP Set the default DVD menu language. Select Rating in the setup menu, and display the Rating submenu: Note: not every disc supports this function. Note: Not all DVD support ratings. Language Parental Control VIDEO SETUP Set Password Video Select Video in the setup menu, and display the Video submenu:...
-
Page 10: Others
Specifications Other Play mode NTSC/PAL Output characteristic Disc mode DVD,VCD, CD, MP3, CD-R, CD-RW, JPEG, Display Device Color TFT-LCD DVD+ -R/W, MPEG4, Screen Size 7 inches Video characteristic Video S/N ratio 65dB. Video output 1Vp-p(75 ) Resolution 500 lines. Audio output Audio characteristic Power Voltage DC IN 12V... - Page 11 If at any tim e in the future you should need to dispose of this product please note that: W aste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
