Assembly and Operating Instructions

Models: PG-30 & PG-36

S S

C C

U U

S S

MADE in the USA

A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACE)

TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE

INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.

Safety Notice:

FOR OUTDOOR USE ONLY!

Please read this entire manual before installation and use of this pellet fuel-burning appliance.

Failure to follow these instructions could result in property damage, bodily injury or even death.

Contact local building or fire officials about restrictions and installation inspection requirements in your area.

Save these instructions.

Manufactured By:

United States Stove Company • 227 Industrial Park Road, South Pittsburg, TN 37380 • Phone #: (800) 750-2723

Part No.: 852076

Table of Contents

Need help?

Do you have a question about the PG-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Fire PG-30

Page 1 Assembly and Operating Instructions Models: PG-30 & PG-36 MADE in the USA A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACE) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
Page 2 Introduction The entire family of United States Stove Company would like to thank you for purchasing your new pellet burning grill. At U.S. Stove, we build all of our products with a hands-on approach to detail and quality. Our old world team of Craftsmen take great pride in their superior workmanship to ensure you have years of trouble free use out of your pellet grill.
Page 3: Safety Information
Safety Information — IMPORTANT: Read this entire manual before installing — A power surge protector is required. This unit must be plugged and operating this product. Failure to do so may result into a 110 - 120V, 60 Hz grounded electrical outlet. Do not use in property damage, bodily injury, or even death.
Page 4: Clearance To Combustibles
Clearance to Combustibles Warning: Install your pellet grill only on a noncombustible floor or provide floor protection adequate to provide ember protection as shown below. Your pellet grill must be installed with 24” (609mm) clearance to combustibles as shown below. Warning: Do not operate this grill under a ceiling or overhang.
Page 5 Assembly Instructions READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE. Tools and Materials Needed For Installation: You will need a #2 phillips screw driver for assembly. Using a drill with a phillips bit will speed the assembly process. Two (2) 1/2” socket/ wrench to install wheels.
Page 6 Step 3: Handles and Side Table Assembly Attach front lid handle to grill lid using supplied bolts Attach side handle to main grill body using supplied bolts MAIN WIRING HARNESS TEMPERATURE PROB WIRES Attach side table to grill using 4 tinnerman clips and 3/8” bolts. Parts List Item Part Number...
Page 7 Step 5: Grill Surface, Drip Pan, and Flame Plate Assembly • Place flame plate in bottom of grill body. Center cutout in flame plate around auger body. Front of flame plate is to rest on flame plate mount. Insure flame plate is level. •...
Page 8 Initial Firing Procedure To Be Used on Initial Firing: (Searing Station is installed by Manufacturer. DO NOT remove.) Open the lid and remove the grilling surface, drip pan and flame plate. Open the pellet hopper lid and check for foreign objects in the hopper. Plug the grill into a three wire, grounded wall outlet.
Page 9 Standard Use Operating Instructions Always make certain that the grill is setting level or is slightly tilted towards the drip bucket. Standard Startup Sequence: Fill the hopper with pellets. Be sure to close and latch the hopper lid. Burn only pellets that are specifically manufactured for use in pellet grills and cookers.
Page 10: Operating Tips
Operating Tips • When the grill is plugged in, the control board will flash through a sequence of letters and numbers before going to a blank display screen. • When you turn the grill “ON” the Mode in which the grill is in flashes for 15 minutes, until startup sequence is finished. •...
Page 11: Maintenance
Maintenance Failure to clean and maintain this unit as indicated may result in poor performance and hazardous situations. The maintenance schedule must be adjusted based on use to insure proper operation and maximum efficiency of your pellet grill. When you are performing any maintenance on your grill, make sure the unit has been turned off, allowing full shutdown sequence, and then unplugged from the power source.
Page 12: Troubleshooting
Troubleshooting GRILL ENTERS SHUTDOWN MODE UNEXPECTEDLY Possible Causes: Possible Remedies: (Unplug stove first when possible) The convection blower is overheating and tripping the internal Clean any dust off of the windings and fan blades. If oiling the blower temperature shutoff. does not help, the blower may be bad. The grill is being left on the highest setting for extended periods of If operating the grill on the highest heat setting, the room temperature time. could increase enough and lead to potential overheating situations. If this happens, try operating at a lower heat setting. Fuel other than wood pellets is being burned in the stove. This pellet grill is designed and tested to use cooking wood pellets. Check for signs of fuel other than wood pellets. No other types of fuel have been approved for this pellet grill. If there are signs of other types of fuel being used, stop using them immediately. Power surge or brown out situation. A power surge, spike, or voltage drop could cause the thermocouple to malfunction. Use a surge protector Thermocouple switch is malfunctioning.
Page 13 Troubleshooting POWER FAILURE DURING USE Possible Causes: Possible Remedies: (Unplug stove first when possible) Power goes out during operation. Observe the grill to make certain unsafe burning conditions do not occur during the outage. To restart unit after power outage. Press the power and the prime button at the same time to resume standard operation. STOVE FEEDS PELLETS, BUT WILL NOT IGNITE Possible Causes: Possible Remedies: (Unplug stove first when possible) Bad igniter element.
Page 14: Replacement Parts
892219 (PG36) GRATE, GRILLING 892218 (PG30) 26154 (PG36) DRIP PAN, LEFT 26146 (PG30) 892220 HANDLE, LID 851713 LOGO, HOM_COMFORT 26158 BACKING PLATE - HOMCOMFORT 83602 BOLT, LEVELING (5/16-18) 69832 WELDMENT, BASE 69842 69835 STACK, SMOKE 80062 90° CONDUIT CLAMP 80086...
Page 15: Parts Diagram
Parts Diagram...
Page 16 Auger Parts Diagram...
Page 17: Wiring Diagram
Wiring Diagram...
Page 18: How To Order Repair Parts
How to Order Repair Parts This manual will help you obtain efficient, dependable service from your Grill, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. When writing, always give the full model number which is on the nameplate attached to the grill. When ordering repair parts, always give the following information as shown in this list: 1. The part number 2. The part description 3. The model number: PG-30, PG-36 4. The serial number:____________________ United States Stove Company 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (800) 750-2723 WWW.USSTOVE.COM...
Page 19 WARRANTY INFORMATION CARD Name__________________________________________ Telephone #: (_____)_____________ City____________________________________________ State_______ Zip_________________ Email Address __________________________________________________________________ Model # of Unit________________________________ Serial #___________________________ Fuel Type: qWood qOther _________________________ qCoal qPellet qGas Place of Purchase (Retailer)______________________________________________________ City____________________________________________ State_______ Zip_________________ If internet purchase, please list website address___________________________________ Date of Purchase _______________________________________________________________ Reason for Purchase: qAlternative Heat...
Page 20 Ê É Fold Here Fold Here Fold Here PLACE STAMP HERE United States Stove Company P.O. Box 151 South Pittsburg, TN 37380...
