SERVICE MANUAL
Color Digital Camera
MODEL NAME
Contents
1. OUTLINE OF CIRCUIT DESCRIPTION .................... 2
2. DISASSEMBLY ........................................................ 13
3. ELECTRICAL ADJUSTMENT .................................. 16
4. TROUBLESHOOTING GUIDE ................................. 21
5. PARTS LIST ............................................................. 22
CABINET AND CHASSIS PARTS 1 ........................ 22
CABINET AND CHASSIS PARTS 2 ........................ 23
ELECTRICAL PARTS .............................................. 24
ACCESSORIES ....................................................... 30
PACKING MATERIALS ............................................ 31
CIRCUIT DIAGRAM (Refer to the separate volume)
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part
designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
SX113/EX, U
PRODUCT SAFETY NOTICE
FILE NO.
VPC-SX550EX
(Product Code : 126 265 01)
(Europe)
(PAL Genenral)
VPC-SX550
(Product Code : 126 265 02)
(U.S.A.)
(Canada)
REFERENCE No. SM5310163

Advertisement

Table of Contents
loading

Related Manuals for Sanyo VPC-SX550EX

Summary of Contents for Sanyo VPC-SX550EX

  • Page 1: Table Of Contents

    FILE NO. SERVICE MANUAL Color Digital Camera VPC-SX550EX (Product Code : 126 265 01) (Europe) (PAL Genenral) VPC-SX550 (Product Code : 126 265 02) (U.S.A.) (Canada) MODEL NAME Contents 1. OUTLINE OF CIRCUIT DESCRIPTION ....2 2. DISASSEMBLY ............13 3.

  • Page 2: Outline Of Circuit Description

    1. OUTLINE OF CIRCUIT DESCRIPTION 1-1. CA1 CIRCUIT DESCRIPTION Around CCD block 1. IC Configuration IC903 (ICX267) CCD imager IC902, IC904, IC908 (74ACT04MTC) H driver IC907 (CXD3400N) V driver IC905 (AD9803) CDS, AGC, A/D converter 2. IC903 (CCD) [Structure] Interline type CCD image sensor Optical size 1/2 inch format Effective pixels...
  • Page 3 3. IC902, IC904, IC908 (H Driver) and IC907 (V Driver) 4. IC905 (CDS, AGC Circuit and A/D Converter) An H driver and V driver are necessary in order to generate The video signal which is output from the CCD is input to Pin the clocks (vertical transfer clock, horizontal transfer clock (30) of IC905.
  • Page 4 5. Transfer of Electric Charge by the Horizontal CCD The transfer system for the horizontal CCD emplays a 2-phase drive method. The electric charges sent to the final stage of the horizontal CCD are transferred to the floating diffusion, as shown in Fig. 1-6. RG is turned on by the timing in (1), and the floating diffusion is charged to the potential of PD.
  • Page 5 1-2. CA2 CIRCUIT DESCRIPTION 1. Circuit Description 1-8. 8-bit D/A circuit (Audio) 1-1. Scannning converter (Interlace converter) This circuit converts the audio signals (analog signals) from This circuit uses the function of a 64-Mbit SDRAMs to con- the microphone to 8-bit digital signals. vert the non-interlaced signal which is output from the CCD 1-9.
  • Page 6 3. LCD Block During EE, gamma conversion is carried out for the 10-bit RGB data which is input from the A/D conversion block of the CCD to the ASIC in order that the γ revised can be displayed on the video. The YUV of 640 x 480 is then transferred to the SVRAM.
  • Page 7 1-3. CA3 CIRCUIT DESCRIPTION 1. Outline 4. Analog system 5.0 V Power Output This is the main CA3 power block, and is comprised of the 5 V (A) is output. Feedback is provided to the swiching con- following blocks. troller (Pin (1) of IC521) so that PWM control can be carried Switching controller (IC521) out.
  • Page 8 1-4. PW1 POWER CIRCUIT DESCRIPTION 1. Outline 3. Digital 3.3 V Power Output This is the main PW1 power circuit, and is comprised of the 3.3 V (D) is output. Feedback for the 3.3 V (D) is provided to following blocks. the switching controller (Pins (1) of IC501) so that PWM con- Switching controller (IC501) trol can be carried out.
  • Page 9 1-5. PW1 STROBE CIRCUIT DESCRIPTION 1. Charging Circuit 2. Light Emission Circuit When UNREG power is supplied to the charge circuit and the When RDY and TRIG signals are input from the ASIC expan- CHG signal becomes High (3.3 V), the charging circuit starts sion port, the stroboscope emits light.
  • Page 10 1-6. SY1 CIRCUIT DESCRIPTION 1. Configuration and Functions For the overall configuration of the SY1 circuit board, refer to the block diagram. The configuration of the SY1 circuit board centers around a 8-bit microprocessor (IC301). The 8-bit microprocessor handles the following functions. 1.
  • Page 11 2. Internal Communication Bus The SY1 circuit board carries out overall control of camera operation by detecting the input from the keyboard and the condition of the camera circuits. The 8-bit microprocessor reads the signals from each sensor element as input data and outputs this data to the camera circuits (ASIC) or to the LCD display device as operation mode setting data.
  • Page 12 4. Power Supply Control The 8-bit microprocessor controls the power supply for the overall system. The following is a description of how the power supply is turned on and off. When the battery is attached, a regulated 3.2 V voltage is normally input to the 8-bit microprocessor (IC301) by IC302, so that clock counting and key scanning is carried out even when the power switch is turned off, so that the camera can start up again.

  • Page 13: Disassembly

    2. DISASSEMBLY 2-1. REMOVAL OF CABINET ASSEMBLY (FRONT) AND CABINET ASSEMBLY (BACK) 8. Button info 1. Five screws 9. Screw 1.7 x 2.5 7. Screw 1.7 x 3.0 1.7 x 4.0 2. Cabinet back 10. Cabinet top 12. Screw 1.7 x 2.5 13.
  • Page 14 2-3. REMOVAL OF HOLDER BATTERY AND PW1 BOARD 4. Holder battery 2. Two screws 3. Remove the solders. 1.7 x 3.0 2. Two screws 1.7 x 3.0 5. Three screws 1.7 x 2.5 1. Screw 1. Screw 1.7 x 2.5 1.7 x 2.5 6.
  • Page 15 2-5. REMOVAL OF CA3 BOARD AND CA2 BOARD 4. Two screws 1.7 x 2.5 2. Two screws 1.7 x 4.0 5. Two connectors 3. Lens VF 4. Screw 1.7 x 2.5 6. CA3 board 8. Holder chassis M 7. CA2 board 1.

  • Page 16: Electrical Adjustment

    3. ELECTRICAL ADJUSTMENT 3-3. Adjustment Items and Order 3-1. Table for Servicing Tools 1. IC501 Oscillation Frequency Adjustment 2. 5.0 V (D) Voltage Adjustment Ref. No. Name Part code 3. 3.3 V (D) A Voltage Adjustment Color viewer 5,100 K VJ8-0007 4.
  • Page 17 3-5. Connecting the camera to the computer 1. Turn off both camera and computer. 2. Locate the port cover on the side of the camera. Press on the arrows and slide the cover down to open it. 3. Line up the arrow on the cable connector with the notch on the camera's serial port. Insert the connector. 4.
  • Page 18 4. 3.4 V (D) B Voltage Adjustment 3-6. Adjust Specifications L5009 ST side Measuring Point [PW1 board (Side B)] Digital voltmeter Measuring Equipment ADJ. Location VR504 3.40 ± 0.03 V ADJ. Value Q5006-1,2,5,6 Adjustment method: D5012-2 1. Adjust with VR504 to 3.40 ± 0.03 V. VR504 VR507 5.
  • Page 19 A from the point where the pulse at CL170 rises until POWER switch: ON the position where the video signal at CL173 starts in 0.82 ± 0.1 µsec (for VPC-SX550EX) or 1.5 ± 0.1 µsec (for Adjustment condition: More than A3 size siemens star chart VPC-SX550).
  • Page 20 10-2. LCD RGB Offset Adjustment Adjusting method: 1. Adjust LCD “RGB offset” so that the amplitude of the CL173 waveform is 7.3 V ± 0.3 Vp-p. 7.3 V ± 0.3 Vp-p CL173 waveform CL173 waveform VG + 0.2 ± 0.05 Vp-p 10-3.

  • Page 21: Troubleshooting Guide

    4. TROUBLESHOOTING GUIDE POWER LOSS INOPERTIVE TAKING INOPERATIVE PUSH SUTTER NORMAL MAIN SW MAIN SW ON BUTTON IC301-2, 3 IC301-4 (SCAN IN 0) CHECK CHECK R3025, (SCAN IN 4, 5) PULSE INPUT S3062, R3021 R3026, D3067, D3068 PULSE INPUT CN301-7, 8 CHECK IC301, IC302-7 (UNREG) CHECK PW1, CA2...

  • Page 22: Parts List

    5. PARTS LIST LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION 411 018 1802 SCR PAN PCS 1.7X2.5 CABINET & CHASSIS PARTS 1 636 057 5233 HOLDER CARD-SX113/J 636 057 9064 ASSY,COVER LENS A-SX113/U 636 057 8371 COMPL,COVER BATT-SX113/J 636 057 8296 ASSY,CABI FRONT-SX113/J 636 054 7216 SPRING P COVER-SX112/J...

  • Page 23: Cabinet And Chassis Parts 2

    645 035 4458 LENS(ASSY) 636 057 6520 COMPL PWB,CA-3,VPC-SX550 ONLY 411 018 1802 SCR PAN PCS 1.7X2.5 636 057 6544 COMPL PWB,CA-3,VPC-SX550EX ONLY 645 038 1751 OPTICAL FILTER 636 056 2653 SPACER LENS-SX112/J 636 053 9181 SPACER 636 056 2615...

  • Page 24: Electrical Parts

    ELECTRICAL PARTS Note: 1. Materials of Capacitors and Resistors are abbreviated as follows ; Resistors Capacitors MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor OXIDE-MT Oxide Metallized Film Resistor TA-SOLD Tantalum Solid Capacitor AL-SOLID Aluminum Solid Capacitor NP-ELECT...
  • Page 25 IC111 409 426 7707 IC W48C53-08H C1081 403 329 6508 TA-SOLID 10U M 6.3V IC121 409 475 0100 IC 26501113CN,VPC-SX550EX ONLY C1082 403 329 6508 TA-SOLID 10U M 6.3V IC121 409 484 8609 IC 26500113GN,VPC-SX550 ONLY C1083 403 322 1005 CERAMIC 0.1U Z 16V...
  • Page 26 401 226 1503 MT-GLAZE 0.000 ZA 1/16W,VPC-SX550 ONLY Q5102 405 153 3302 TR SSM3K01F(BRA) R1104 401 226 1503 MT-GLAZE 0.000 ZA 1/16W,VPC-SX550EX ONLY Q5103 405 092 1100 TR 2SA1577-P R1108 401 105 7909 MT-GLAZE 0.000 ZA 1/16W 405 092 1209...
  • Page 27 CERAMIC 1000P K 50V,VPC-SX550 ONLY R5207 401 166 3001 MT-FILM 2.7K DU 1/16W C1724 403 139 7306 CERAMIC 18P J 50V,VPC-SX550EX ONLY R5213 401 105 0702 MT-GLAZE 100K JA 1/16W C1726 403 207 0307 CERAMIC 1U Z 16V R5214 401 105 2805 MT-GLAZE 2.2K JA 1/16W...
  • Page 28 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION Q5003 405 092 1100 TR 2SA1577-P L5009 645 033 7918 INDUCTOR,10U M 405 092 1209 TR 2SA1577-Q L5010 645 036 5362 INDUCTOR,6.2U M 405 092 1407 TR 2SA1577-R L5011 645 033 8663 INDUCTOR,10U K Q5004 405 092 1100...
  • Page 29 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C5411 403 330 5903 CERAMIC 0.01U K 500V R5084 401 225 1306 MT-GLAZE 470 JA 1/16W C5412 404 077 5805 ELECT 60U A 330V R5085 401 225 1306 MT-GLAZE 470 JA 1/16W C5414 403 279 5002 CERAMIC...

  • Page 30: Accessories

    MT-GALZE 3.3K JA 1/16W 645 037 0328 BATTERY CHAGER,VPC-SX550 ONLY R3002 401 105 5400 MT-GLAZE 47K JA 1/16W 645 037 0342 BATTERY CHAGER,VPC-SX550EX ONLY R3003 401 105 0603 MT-GLAZE 10K JA 1/16W 645 037 0205 BATTERY,RECHARGE,COMP. R3004 401 105 4304...

  • Page 31: Packing Materials

    CASE SOFT-SX113/J 645 036 4129 CORD,POWER-1.2MK,VPC-SX550EX ONLY 645 036 4112 CORD,POWER-1.9MK,VPC-SX550 ONLY 645 040 3477 DISC,CD-ROM CEL SSP50 E (Sanyo Software Pack For Digital Cameras) 645 040 3460 DISC,CD-ROM PS8-USB (MGI PhotoSuite) 636 056 1007 STRAP HAND-SR662/J 9112 636 057 7015...
  • Page 32 OVERALL WIRING...
  • Page 33 SANYO Electric Co., Ltd. Apr./ '00/ 4,760 MI Printed in Japan Osaka, Japan...
