Do you have a question about the W-512 and is the answer not in the manual?

Questions and answers

Leonard Dow
May 23, 2025

How to hook up a w 512 vcr to a one. ROKU TV

User image 6830bbe66d0f0
2 comments:
Leonard Dow
May 23, 2025

Leonard Dow

User image 6830bcfea7a53
Mr. Anderson
May 25, 2025

To connect a Toshiba W-512 VCR to a Roku TV, follow these steps:

1. Identify the Output on the VCR:
- The Toshiba W-512 VCR likely has composite video outputs (yellow for video, red and white for audio).

2. Identify the Input on the Roku TV:
- Most Roku TVs have a composite input, usually labeled as AV IN or Video In, using a 3.5mm AV jack or standard RCA ports.

3. Use the Correct Cable:
- If your Roku TV uses a 3.5mm AV input, use a 3.5mm to RCA cable (red/white/yellow on one end, 3.5mm plug on the other).
- If your TV has RCA ports, use a standard RCA cable (red/white/yellow on both ends).

4. Connect the VCR to the TV:
- Plug the yellow, white, and red RCA cables into the matching color OUT ports on the VCR.
- Plug the other end into the TV’s AV IN port (directly or using the 3.5mm AV adapter, if required).

5. Power On Devices:
- Turn on both the VCR and the Roku TV.

6. Select the Correct Input on the TV:
- Use the Roku TV remote to select the AV input (may be labeled as AV, Composite, or Video).

7. Test the Connection:
- Play a VHS tape in the VCR. You should see the video and hear the audio on the TV.

If your Roku TV lacks composite inputs, you will need an RCA to HDMI converter. Connect the VCR to the converter with RCA cables, then connect the converter to the TV using an HDMI cable. Select the correct HDMI input on the TV.

This answer is automatically generated
