Adman Technologies Pvt. Ltd.

Face-Entry

Face Recognition based Access Control

System Model DH -1(Stand Alone system)

Face - Entry

User Manual

Table of Contents

Need help?

Do you have a question about the DH-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adman Technologies DH-1

Page 1: User Manual
Adman Technologies Pvt. Ltd. Face-Entry Face Recognition based Access Control System Model DH -1(Stand Alone system) Face - Entry User Manual...
Page 2 Adman Technologies Pvt. Ltd. Face-Entry User Manual Adman Technologies Pvt. Ltd. A-53, DDA Shed, Okhla Phase – II New Delhi – 20 Phone: 011-43119696 * Fax: 011-43119634 E-Mail info@admantechnologies.com Catalog no. CTE0011 28-May-2009...
Page 3: Table Of Contents
T able of Contents Introduction ......................4 Safety instructions....................5 Face-Entry operation modes................6 System Activation....................7 Enroll process ....................9 Show personal data ..................16 Update personal data..................17 Delete employee ....................18 Reports......................19 Administrator Login ..................24 Logout Administrator ..................
Page 4: Introduction
Introduction ime Watch would like to thank you for purchasing Face-Entry face recognition system. We in TimeWatch are using all our resources and energy to supply you with an advanced state of the art face recognition system. This manual will instruct you via simple operation guidelines for short and successful assimilation of the system in your organization.
Page 5: Safety Instructions
Safety instructions 1. The system has a permanent connection to power line. Hence, for security reasons it should have an external standard power circuit breaker for 110/220Vac, 10A current trip, located near the system. 2. Readily accessible disconnect device (two pole circuit breaker) should be incorporated external to the equipment 3.
Page 6: Face-Entry Operation Modes
Face-Entry operation modes Face-Entry system operates in three modes: 1. Match mode – This is the normal daily mode, which allows users/employees face recognition based authentication. 2. Administrator mode - This mode enables enrolling new users/employees, updating the database and producing reports. 3.
Page 7: System Activation
System Activation Face-Entry activation process designed to be as simple as possible, however since we have to secure the biometric information only authorized person may activate the system. Please perform the following steps to activate the system: 1. Using included wireless keyboard press the Escape button to exit Face-Entry main application. 2.
Page 8 6. After system activation you can change default username and password by selecting Administrator dropdown menu > Change Username and Password 7. Important! Logout Administrator every time you finish using it.
Page 9: Enroll Process
Enroll process NOTE! Only Administrator has the privilege to Enroll. The unique identifier of each user can be one of the following: 1. RFID card - A new card should be allocated to the new employee and his/her name printed on the card.
Page 10 Present the new employee RFID card as shown in the picture below or type the 4 digits employee's number and press “Enter” using the touch screen key pad. 6. If the RFID card or the 4 digits employee number is already in use following question will appear: 7.
Page 11 9. An Enroll screen will be displayed for entering the personal details. 10. Checking the “Allow Access” checkbox will grant access to user, leaving this checkbox unchecked won’t grant access to the user despite the successful face recognition. Note! All details in the enroll screen are mandatory to enter. 11.
Page 12 Please refrain from situations as shown in the pictures below Look straight to the camera – stand with your face looking towards the camera The face should be fully exposed and not covered by any other object that may hide crucial face characteristics during image...
Page 13 Get closer! – you are too far from the camera Too many people! – verify that there are no people standing near you in front of the camera Note! Fully frontal and well aligned image will promise an efficient verification process.
Page 14 Match mode (normal operation mode) Please perform the following steps to switch the system mode to Match mode: 1. Press on Escape to exit C-Entry main application. 2. In the main menu select > Match mode Please perform the following step for user authentication. 1.
Page 15 4. In case the user authentication is not confirmed access will be denied and “Sorry, Authentication Not Confirmed” message will be displayed as shown in the picture below...
Page 16: Show Personal Data
Show personal data Please perform the following steps to display employee’s personal data 1. Login as Administrator to the system 2. In Administrator drop down menu select “Show Personal Data” 3. Present the employee’s RFID card or type employee's ID number. The employee’s personal data will be presented NOTE! The Personal Data can not be modified at this stage, for updating Personal Data go to next page...
Page 17: Update Personal Data
Update personal data Please perform the following steps to update Employee’s personal data in the system database: 1. Login as Administrator to the system 2. In Administrator drop down menu select “Update Personal Data” bar 3. Present the Employee’s RFID card or type employee's ID number and the employee’s personal data will available for editing.
Page 18: Delete Employee
Delete employee Please perform the following steps to delete an employee from the system database 1. Login as Administrator to the system 2. In Administrator drop down menu select “Delete employee” bar 3. Present the Employee’s RFID card or type employee's ID number 4.
Page 19: Reports
Reports Please perform the following steps to generate reports: 1. Login as Administrator to the system Select “Reports” bar. The administrator can produce report of all transactions in the system for all users or per specific user/s and per specific dates.
Page 20 3. Selecting the users or/and the required dates and click the “Create transaction Report” button.
Page 21 By selecting Date/Time in “Dates” you can filter the report...
Page 22 5. In order to generate Attendance reports press “Create Attendance Reports” button. The reports will be generated in “T_A Report” on your system’s desktop. The Time and Attendance reports in two modes: Default Mode: a. Press “Clear Dates” button to disable “From date:”, “To date:”. b.
Page 23 If present date after 15 you will have the report from 1 same month till the present date Selected Period mode a. Press “Use Dates” button to enable “From date:”, “To date:”, “From Time:”, “To Time:”. b. Select a report period in “From date:” “To date:” boxes. c.
Page 24: Administrator Login
Administrator Login C-Entry system offers two options to login as administrator: 1. User name and password login: In the main menu select > Face Recognition and login as administrator with user name and password as described in page no.4. The system allows only one administrator of that type in the system. 2.
Page 25: Logout Administrator
Logout Administrator Although when switching from Administrator mode to Match mode the system automatically logs out from Administrator mode, it is highly recommended that the administrator will logout by selecting “Logout Administrator”.
Page 26: Remote Support
Remote support Please perform the following steps for having remote technical support: 1. In the main menu select > Face Recognition 2. Login as administrator 3. Press on Windows key + D to minimize Face-Entry application 4. Verify the system is connected to the internet 5.
