CAR AUDIO
VENTED BOX VOLUME
(INCLUDES DRIVER/PORT DISPLACEMENTS)
Reference 1042w
(side view)
3
V = 1.75 ft (49.55 liters)
BOX
VENTED ENCLOSURE
FREQUENCY RESPONSE @ 2.83 V
dBSPL
105
100
In-Car
12 dB LP @ 80 Hz
95
90
85
Out-Of-Car
80
75
70
65
60
55
20 Hz
30 40 50 60
VENTED ENCLOSURE CONE
EXCURSION @ 250 W
30m M
20m
10m
5m
2m
1m
500u
200u
100u
50u
20u
10u
5u
20 Hz 30 40 50
