Service Manual
PLASMA TV
OWNER'S MANUAL
MODELS:
DU-42PZ60/60A/60B/60C/60K/60R/60S
DU-42PZ60H/60HA/60HB/60HC/60HK/60HR/60HS
DU-42PZ70/70A/70B/70C/70K/70R/70S
DU-42PZ70H/70HA/70HB/70HC/70HK/70HR/70HS
DU-50PZ60/60A/60B/60C/60K/60R/60S
DU-50PZ60H/60HA/60HB/60HC/60HK/60HR/60HS
DU-50PZ70/70A/70B/70C/70K/70R/70S
DU-50PZ70H/70HA/70HB/70HC/70HK/70HR/70HS
Please read this manual carefully and completely before
operating your TV.
Retain this manual for future reference.
Record model number and serial number of the TV in the
spaces provided below.
See the label attached on the back cover and relate this
information to your dealer if you require service.
Model Number :
Serial Number :
Internet Home Page : http://www.lg.ca
Advertisement
Table of Contents
Related Manuals for LG DU-42PZ60
Summary of Contents for LG DU-42PZ60
- Page 1 Record model number and serial number of the TV in the spaces provided below. See the label attached on the back cover and relate this information to your dealer if you require service. Model Number : Serial Number : Internet Home Page : http://www.lg.ca...
-
Page 2: Warnings
Warning arning arning WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Safety Instructions
Safety Instructions Safety Instructions Safety Instructions Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. -
Page 4: Safety Instructions
Safety Instructions Safety Instructions continued Safety Instructions continued 14. Outdoor Antenna Grounding 19. Servicing If an outside antenna or cable system is connected to the Do not attempt to service this product yourself as opening or product, be sure the antenna or cable system is grounded so removing covers may expose you to dangerous voltage or as to provide some protection against voltage surges and other hazards. -
Page 5: Table Of Contents
Contents Contents Contents Warnings ........2 Auto Clock Setup . -
Page 6: Introduction
Introduction Introduction Introduction What is a Plasma Display Panel (PDP)? A plasma display panel is the latest display technology and the best way to achieve flat panel displays with excellent image quality and large screen sizes that are easily viewable. The PDP can be thought of as a descendant of the neon lamp and it can be also be viewed as a series of fluorescent lamps. -
Page 7: Controls
Introduction Controls Controls - This is a simplified representation of front panel. Here shown may be somewhat different from your TV. - This manual explains the features available on the DU-50PZ60/70 series TVs. Front Panel Controls Front Panel Controls Remote Control Sensor ON/OFF S-VIDEO VIDEO... -
Page 8: Connection Options
Introduction Connection Options Connection Options Back Connection Panel Back Connection Panel DVD/DTV Input (Component 1-2) Connect a component video/audio device to these jacks. S-Video Input Connect S-Video out from an S-VIDEO Digital Audio (DVI: Digital Visual device to the S-VIDEO input. Interface/Component1) Input/ Digital Audio Output Connect digital audio from various types... -
Page 9: Remote Control Key Functions
Installation Remote Control Key Functions Remote Control Key Functions - When using the remote control, aim it at the remote control sensor on the TV. LIGHT MODE Illuminates the remote control buttons. Selects the remote operating mode: TV, VCR, DVD, CABLE, HDSTB or AUDIO. TV/VIDEO Select other operating modes, for the Selects: DTV, Analog, Video1-2,... -
Page 10: Installation
Installation Installation Installation Ensure that the following accessories are included with your plasma display. If an accessory is missing, please contact the dealer where you purchased the product. MODE COMP/RGB/DVI FLASHBK MUTE SURF RATIO INFO MENU EXIT SOUND VIDEO PLAY PAUSE STOP RECORD SKIP... -
Page 11: External Equipment Connections
Installation External Equipment Connections External Equipment Connections Antenna Connection Antenna Connection Analog and Digital TV signals provided on one antenna - Antenna or Cable Service without a Cable Box Connections - For optimum picture quality, adjust antenna direction if needed. Multi-family Dwellings/Apartments (Connect to wall antenna socket) Wall Antenna... -
Page 12: Vcr Setup / Cable Tv Setup
Installation NOTE: All cables shown are not included with the TV VCR Setup VCR Setup - To avoid picture noise (interference), leave an adequate distance between the VCR and TV - Use the ISM Method (on the Option menu) feature to avoid having a fixed image remain on the screen for a long period of time. Typically a frozen still picture from a VCR. -
Page 13: External A/V Source Setup
Installation External A/V Source Setup External A/V Source Setup How to connect Connect the audio and video cables from the external equip- ment's output jacks to the TV input jacks, as shown in the figure. When connecting the TV to external equipment, match the AUDIO INPUT VIDEO INPUT AUDIO... -
Page 14: Hdstb Setup / Digital Audio Output
Installation HDSTB Setup HDSTB Setup - This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below. - This TV supports HDCP (High-bandwidth Digital Contents Protection) protocol for DTV (480p,720p,1080i) mode. -
Page 15: Pc Setup
Installation PC Setup PC Setup - This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. The TV sends config- uration information (EDID) to the PC using the Video Electronics Standard Association (VESA) Display Data Channel (DDC) protocol. -
Page 16: Screen Setup For Pc Mode
Installation Operation Operation Screen Setup for PC mode Screen Setup for PC mode - Be sure to select the RGB-PC/RGB-DTV source before operation. (For RGB-DTV input source, Position and Reset are available.) - In DVI-PC and DVI-DTV input source, settings are not adjustable. - You can manually adjust picture position and minimize image shaking for the PC input source. -
Page 17: Turning The Tv On
Operation urning the TV On urning the TV On Turning on the TV just after installation 1. Connect power cord correctly. 2. Press the ON/OFF button on the TV. At this moment, the TV is switched to standby mode. Press the TV/VIDEO, CH ( ) button on the TV or press the POWER, TV/VIDEO, COMP/RGB/DVI, CH (+ , -), Number (0 ~ 9) button on the remote control and then the TV will switch on. -
Page 18: Setup Menu Options
Operation Setup Menu Options Setup Menu Options EZ Scan (Channel Search) EZ Scan (Channel Search) - Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list. - Run EZ Scan again after any Antenna/Cable connection changes. EZ Scan SETUP ANT 1... -
Page 19: Dtv Signal Strength
Operation DTV Signal Strength DTV Signal Strength - Reveals how strong your DTV signal is and whether you need to adjust your antenna or digital cable input. The higher the signal strength, the less likely you are to experience picture degradation. - Digital DTV Signals: May not be available in all areas, nor are broadcast on all programs. -
Page 20: Main Picture Source Selection
Operation Setup Menu Options continued Setup Menu Options continued Main Picture Source Selection Main Picture Source Selection - Changes the picture source so you can watch your off-air TV, cable TV, VCR, DVD, or any other devices that are connected to your TV. -
Page 21: Video Menu Options
Operation ideo Menu Options ideo Menu Options EZ Picture EZ Picture - EZ Picture adjusts the TV for the best picture appearance. Select the preset value in the EZ Picture menu based on the program category. - When adjusting Video menu options (contrast, brightness, color, sharpness, tint, and color temperature) manually, EZ Picture automatically changes to Normal Digital Preset... -
Page 22: Audio Menu Options
Operation Audio Menu Options Audio Menu Options Audio Language Audio Language - Other languages may be available if a digital signal is provided by the broad- Audio Language SETUP English casting station. EZ SoundRite Spanish VIDEO EZ Sound French Press the MENU button and then use button to select the menu. -
Page 23: Stereo/Sap Broadcasts Setup
Operation Stereo/SAP Stereo/SAP Broadcasts Setup Broadcasts Setup - This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program; if the station transmits an additional sound signal as well as the original one. - Stereo or SAP can be received only when the TV station transmits those signals even though you have selected Stereo or SAP. -
Page 24: Time Menu Options
Operation ime Menu Options ime Menu Options Auto Clock Setup Auto Clock Setup - The time is set automatically from a digital channel signal. - The digital channel signal includes information for the current time provided by the broadcasting station. - Set the clock manually, if the current time is set incorrectly by the auto clock function. -
Page 25: Sleep Timer / Auto Off
Operation Sleep imer Sleep imer - The Sleep Timer turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off. - You can also set up the Sleep Timer in the TIME menu. -
Page 26: Option Menu Features
Operation Option Menu Features Option Menu Features Aspect Ratio Control Aspect Ratio Control - Lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV with a 16:9 ratio picture format. When you receive an analog picture with a 4:3 aspect ratio on your 16:9 TV, you need to specify how the picture is to be dis- played. -
Page 27: Caption / Caption Mode
Operation Caption Caption 1. Use the CC button repeatedly to select Caption EZ Mute , or • EZ Mute shows the selected captions option (if available on program) when the TV sound is muted . • You can also use the OPTION menu to select Caption... -
Page 28: Caption Option / Ez Demo
Operation Option Menu Features continued Option Menu Features continued Caption Option Caption Option - Customize the DTV/CADTV captions that appear on your screen. 1. Press the MENU button and then use button to select the OPTION D / E menu. Aspect Ratio Style Custom... -
Page 29: White Wash
Operation White W White W - White Wash removes permanent images from the screen. Aspect Ratio SETUP - Set White Wash ‘ ’ until fixed image disappears. Caption - Note: An excessive permanent image may be impossible to clear entirely with VIDEO Caption Mode White Wash. -
Page 30: Lock Menu Options
Operation Lock Menu Options Lock Menu Options Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed. -
Page 31: Parental Lock Setup
Operation Parental Lock Setup Parental Lock Setup - Lets you set up blocking schemes to block specific channels, ratings, and external viewing sources. - A password is required to gain access to this menu if the Lock System is turned on 1. -
Page 32: Watching Pip/Pop/Twin Picture
Operation (Picture-In-Picture) / POP win Picture (Picture-In-Picture) / POP win Picture - PIP lets you view 2 different inputs (sources) on your TV screen at the same time. One source will be large, and the other source will show a smaller inset image. - Twin Picture mode splits the screen into 2, allowing 2 picture sources to be shown on the TV screen at the same time. -
Page 33: Moving The Pip Sub Picture
Operation Moving the PIP sub picture Moving the PIP sub picture D / E / F / G In PIP mode, press the button to move the sub picture to a different location on the screen. Adjusting Main and Sub Picture Sizes for Adjusting Main and Sub Picture Sizes for win Picture win Picture... -
Page 34: External Control Device Setup
External Control Device Setup External Control Device Setup External Control Device Setup - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and control the Monitor’s functions externally. - Connect the serial port of the control device to the RS-232C jack on the Monitor back panel. - RS-232C connection cables are not supplied with the Monitor. - Page 35 1 ~ 64 functions or communication errors. 24. Orbiter Pixel Setting 0 ~A Data 1: Illegal Code 2: Not supported function 3: Wait more time * DU-42PZ60/70 series TV only COM- COM- DATA 0 DATA 1 DATA 2 DATA 3...
- Page 36 External Control Device Setup 01. Power (Command2:a) 05. Volume Mute (Command2:e) G To control Power On/Off of the Monitor. G To control volume mute on/off. You can also adjust mute using the MUTE button on Transmission remote control. [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 0 : Power Off 1 : Power On...
- Page 37 External Control Device Setup 09. Color (Command2:i) 14. PIP / POP / Twin Picture (Command2:n) G To control the PIP (Picture-in-Picture)/POP/Twin picture. G To adjust the screen color. You can also control the PIP/POP/Twin picture using the You can also adjust color in the Video menu. PIP button on the remote control.
-
Page 38: External Control Device Setup
External Control Device Setup 19. Color Temperature (Command2:u) 24. Orbiter Pixel Setting (Command2:s) G To adjust color temperature. G To adjust pixel number in orbiter function. You can also adjust color temperature in the Video Transmission menu. [j][s][ ][Set ID][ ][Data][Cr] Transmission [k][u][ ][Set ID][ ][Data][Cr] Data Min: 0 ~ Max: A... -
Page 39: Ir Codes
IR Codes IR Codes IR Codes How to Connect How to Connect G Connect your wired remote control to the Remote Control port on the TV. Remote Control IR Codes Remote Control IR Codes G Output waveform Single pulse, modulated with 37.917KHz signal at 455KHz Carrier frequency = 1/T Duty ratio = T1/T... -
Page 40: Ir Codes
IR Codes Code (Hexa) Function Note 0x0B TV/VIDEO R/C Button MODE R/C Button 0x08 POWER R/C Button (Power On/Off) 0xC4 POWER ON Discrete IR Code (Only Power On) 0xC5 POWER OFF Discrete IR Code (Only Power Off) 0x98 COMP/RGB/DVI R/C Button 0x79 RATIO R/C Button... -
Page 41: Programming The Remote
Programming the Remote Programming the Remote Programming the Remote G The remote control is a multi-brand or universal remote control. It can be programmed to operate most remote-controllable devices of other manufacturers. Note that the remote control may not control all models of other brands. Programming a code into a remote mode Programming a code into a remote mode 1. -
Page 42: Programming Codes
TATUNG 039 043 AKAI 016 043 046 124 047 048 PULSAR TEAC 034 039 043 125 146 LG (GOLDSTAR) 001 012 013 020 QUARTZ 011 014 TECHNICS 031 033 070 AMPRO 101 106 114 123 QUASAR 033 066 075 145... -
Page 43: Programming Codes
106 186 FINEARTS SHARP 031 032 051 052 FISHER 089 099 MAGNAVOX 072 082 117 119 LG(GOLDSTAR) 001 021 024 029 MARANTZ 002 018 020 025 156 184 199 200 087 107 108 110 034 041 081 090 206 209... -
Page 44: Troubleshooting Checklist
Troubleshooting Checklist roubleshooting Checklist roubleshooting Checklist • Check whether the TV is turned on. No picture & • Is the power cord inserted into wall power outlet? No sound • Test the wall power outlet, plug another product’s power cord into the outlet where the TV’s power cord was plugged in. -
Page 45: Maintenance
Maintenance Maintenance Maintenance - Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen Cleaning the Screen 1. -
Page 46: Product Specifications
Product Specification Product Specifications Product Specifications DU-42PZ60/42PZ60A DU-42PZ70/42PZ70A DU-50PZ60/50PZ60A DU-50PZ70/50PZ70A /42PZ60B/42PZ60C /42PZ70B/42PZ70C /50PZ60B/50PZ60C /50PZ70B/50PZ70C /42PZ60K/42PZ60R /42PZ70K/42PZ70R /50PZ60K/50PZ60R /50PZ70K/50PZ70R /42PZ60S /42PZ70S /50PZ60S /50PZ70S MODELS DU-42PZ60H/42PZ60HA DU-42PZ70H/42PZ70HA DU-50PZ60H/50PZ60HA DU-50PZ70H/50PZ70HA /42PZ60HB/42PZ60HC /42PZ70HB/42PZ70HC /50PZ60HB/50PZ60HC /50PZ70HB/50PZ70HC /42PZ60HK/42PZ60HR /42PZ70HK/42PZ70HR /50PZ60HK/50PZ60HR /50PZ70HK/50PZ70HR /42PZ60HS /42PZ70HS /50PZ60HS /50PZ70HS Width (inches / mm) - Page 47 Notes Notes Notes Owner’s Manual 47...
