IQ DPF800SB User Manual

Iq digital picture frame
Hide thumbs
Table of Contents

Advertisement

Quick Links

IQ DIGITAL PICTURE FRAME
iQ DIGITAL PICTURE FRAME
User Guide
Model: DPF800SB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPF800SB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IQ DPF800SB

Summary of Contents for IQ DPF800SB

  • Page 1 IQ DIGITAL PICTURE FRAME iQ DIGITAL PICTURE FRAME User Guide Model: DPF800SB...

  • Page 2: Table Of Contents

    IQ DIGITAL PICTURE FRAME Table of Contents Introduction ....................... 3   Main Features ....................3   Getting Started ....................4   Package Contents ..................4   Installing your unit ..................5   Connecting to a PC ..................5   Operation ....................... 5  ...

  • Page 3: Introduction

    IQ DIGITAL PICTURE FRAME Introduction Congratulations on your purchase of IQ Digital Picture Frame. Before operating the unit, please read this manual thoroughly, and retain it for future reference. This manual will help you use many of the exciting and useful features that will make your Digital Picture Frame viewing more enjoyable.

  • Page 4: Getting Started

    IQ DIGITAL PICTURE FRAME Getting Started Package Contents Digital Picture Frame User Manual AC/DC Adapter Remote control USB Cable...

  • Page 5: Installing Your Unit

    IQ DIGITAL PICTURE FRAME Installing your unit • Open the package and remove the protective foam. Remove the protective sleeve from the unit. • Install the Digital Picture Frame stand as the back of the unit. • Plug in the AC adapter into power outlet. Plug the other end into the unit.

  • Page 6: Controls

    IQ DIGITAL PICTURE FRAME 3. The slideshow will start automatically: Controls...

  • Page 7: Using Your Remote Control

    IQ DIGITAL PICTURE FRAME Using your Remote Control The following table briefly describes the remote control functions Button Description Power Turn on/off Photo Access your photo files Music Access your music files Video Access your videos files Combo Start the slideshow...

  • Page 8: Inserting Memory Cards

    IQ DIGITAL PICTURE FRAME Inserting Memory Cards The Digital Picture Frame is compatible with the following memory cards: • Secure Digital Card (SD) • MultiMedia Card (MMC) • Memory Stick • CompactFlash (CF) Card • XD Picture Cards Insert the memory card with the front label facing AWAY from you. Do not force the memory card into the memory slot.

  • Page 9: Main Menu

    IQ DIGITAL PICTURE FRAME Main menu Upon turning on the Digital Picture Frame, you will go straight to the MENU screen. To set the Auto Start feature Choose the SETUP screen. Use the left/right arrow to go to the “Set up”. Press Enter button to enter the options screen.

  • Page 10: Viewing Pictures

    IQ DIGITAL PICTURE FRAME Viewing Pictures Make sure you have at least one picture on your memory card or your USB flash drive. When this is done: • Select the desired flash media on main menu. (SD/xD/CF/MS/USB/NAND-Internal Memory) • Select the “PHOTO” option from the menu and press “ENTER”...

  • Page 11: Previous

    IQ DIGITAL PICTURE FRAME • Once a slideshow is playing or a picture is being shown, press the “ENTER” button. The following menu will appear: Previous Play previous picture in the picture list Play or Pause Play or pause the current slideshow.

  • Page 12: Watching Video

    IQ DIGITAL PICTURE FRAME Watching video The Digital Picture Frame supports the following video formats: • Motion JPEG (.avi): video format used by most digital cameras MPEG-I • MPEG-2 • MPEG 4 Make sure you have at least one video on your memory card or your USB flash drive.

  • Page 13: Previous

    IQ DIGITAL PICTURE FRAME Once a movie is playing, press the ENTER button on the remote control. The following menu will appear: Previous Play previous movie in the play list Fast Forward Play forward the movie by 2/3/4 times speed.

  • Page 14: Play Or Pause

    IQ DIGITAL PICTURE FRAME Play or Pause Play or Pause the movie. Fast Backward Play backward the movie by 2/3/4 times speed. Next Play next movie in the play list Stop Stop the movie and return to the playlist Zoom...

  • Page 15: Listening To Mp3 Music

    IQ DIGITAL PICTURE FRAME Listening to MP3 music Make sure you have at least one MP3 file on your memory card or your USB flash drive. When this is done: • Select the desired flash media on main menu. (SD/xD/CF/MS/USB/NAND-Internal Memory) •...

  • Page 16: File Management

    IQ DIGITAL PICTURE FRAME • Press VOL+ to increase the volume or VOL- to decrease the volume. • Press Play/Pause button on remote control to play or pause the music file. • Press Stop button on the remote control to return to the list of music files.

  • Page 17: Previous

    IQ DIGITAL PICTURE FRAME Previous Play previous picture in the picture list Play or Pause Play or pause the current slideshow. Next Play next picture in the picture list Rotate Use the rotate function to change the picture orientation to either portrait or landscape.

  • Page 18: Copying And Deleting Files

    IQ DIGITAL PICTURE FRAME Copying and Deleting Files To copy and delete files on your memory card, USB drive or internal memory. Copy • Select the desired flash media on main menu. (SD/xD/CF/MS/USB/NAND-Internal Memory) • Select the “FILE” option from the menu and press “ENTER”...
  • Page 19 IQ DIGITAL PICTURE FRAME • Press Enter to start copying the file. Delete • Select the desired flash media on main menu. (SD/xD/CF/MS/USB/NAND-Internal Memory) • Select the “FILE” option from the menu and press “ENTER” • A list of available files will be displayed. Use the up and down arrows to highlight your required file and press the right arrow to highlight the desired file.

  • Page 20: Using The Setup Option

    IQ DIGITAL PICTURE FRAME Using the SETUP option The following options can be changed by using the “SETUP” option from the main menu: (Press “MENU” then select the “SETUP” button) Function Description Language Includes English, French, Spanish, Deutsch, Italian Slideshow time...

  • Page 21: Technical Support

    IQ DIGITAL PICTURE FRAME Technical Support Frequently asked questions 1) Q: If I keep showing the same photo for a long time, will it damage the LCD screen? A: No. The Digital Picture Frame can display the same photo continuously for a long time.
  • Page 22 IQ DIGITAL PICTURE FRAME Troubleshooting Symptom Cause Corrective Actions Digital Picture The Power connector to the Please be sure that the AC adaptor is Frame doesn’t unit is not securely inserted. properly connected to the frame. power on. Memory card inserted in the...

  • Page 23: Specifications

    IQ DIGITAL PICTURE FRAME Specifications Type IQ Digital Picture Frame Size 8inch Resolution 800x600 Alimentation 12 V Consumption 6 Watts Working Temperature -20 to +65 degrees Response Time 25ms Display Mode File Format JPEG, MPEG1, MPEG2, MP3, MPEG4 Photo Size...

  • Page 24: Maintenance And Precaution

    IQ DIGITAL PICTURE FRAME Maintenance and Precaution • The Digital Picture Frame is for indoor use only. • To reduce the risk of fire or electric shock; do not expose this appliance to rain or moisture. • Do not block the ventilation holes on the back of the Digital Picture Frame at any time.
