PARKSIDE PLAY SYSTEM – F24068
INSTALLATION AND OPERATING INSTRUCTIONS
22'6"
10'6"
18' 8" (5.7 m)
10'
4 - 8 Hrs
Two person
assembly
3404068
WARNING
often and give them to any future owner of this play system. Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE - 22'6" x 28' (6.9 x 8.5 m) area requires Protective Surfacing. See page 3.
28'
MAXIMUM VERTICAL FALL HEIGHT - 6'6" (2.3 m)
CAPACITY - 4 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as schools, churches, nurseries,
day cares or parks
Solowave Design
375 Sligo Rd. West, PO Box 10
Mount Forest, ON Canada N0G 2L1
General Inquiries:
8:00am - 4:30pm EST
Toll Free: 1-877-966-3738
support@solowavedesign.com
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions
Table of Contents
Warnings and Safe Play Instructions . . . . . . . . . . pg. 2
Protective Surfacing Guidelines . . . . . . . . . . . . . . pg. 3
Instructions for Proper Maintenance . . . . . . . . . . pg. 4
About Our Wood – Limited Warranty . . . . . . . . . . pg. 5
Keys to Assembly Success . . . . . . . . . . . . . . . . . . pg. 6
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 7
Installation of I.D./Warning Plaque . . . . . . . . Final Step
Rev 12/16/2009
Advertisement
Related Manuals for Big Backyard F24068
Summary of Contents for Big Backyard F24068
- Page 1 PARKSIDE PLAY SYSTEM – F24068 INSTALLATION AND OPERATING INSTRUCTIONS WARNING 22’6” To reduce the risk of serious injury or death, you must read and follow these instructions. Keep and refer to these instructions 10’6” often and give them to any future owner of this play system. Manufacturer contact information provided below.
-
Page 2: Warnings And Safe Play Instructions
Warnings and Safe Play Instructions CONTINUOUS ADULT SUPERVISION REQUIRED. Most serious injuries and deaths on playground equipment have occurred while children were unsupervised! Our products are designed to meet mandatory and voluntary safety standards. Complying with all warnings and recommendations in these instructions will reduce the risk of serious or fatal injury to children using this play system. - Page 3 Protective Surfacing - Reducing Risk of Serious Head Injury From Falls. One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM F1292.
- Page 4 Instructions for Proper Maintenance Your Big Backyard Play System is designed and constructed of quality materials with your child’s safety in mind. As with all outdoor products used by children, it will weather and wear. To maximize the enjoyment, safety and life of your Play Set, it is important that you, the owner, properly maintain it.
- Page 5 About Our Wood Solowave Design™ uses only premium playset lumber, ensuring the safest product for your children’s use. Although great care has been taken in selecting the best quality lumber available, wood is a product of nature and susceptible to weathering (changes in the aesthetics of the wood).
-
Page 6: Keys To Assembly Success
Keys to Assembly Success Tools Required Shovel Measuring Drill (1/8” Safety Hammer Ratchet 1/2”, Level #2 & #3 Phillips Square Step Tape 3/16” Bit) Glasses 7/16” & 9/16” or Robertson Ruler Ladder Part Identification Key 2X A1 Post 2 x 4 x 83” On each page, you will find the parts and quantities required to complete the assembly step illustrated on that page. - Page 7 Wood Parts Identification (Reduced size) Nominal Actual Nominal Actual Size Size Size Size 1 - Upright (2" x 3" x 34") 1" x 6" 5/8" x 5 3/8" 1" x 3 1/2" " x 4" 3660632 2" x 6" 2" x 3" 1 3/8"...
- Page 8 Wood Parts Identification (Reduced size) Nominal Actual Nominal Actual Size Size Size Size 2 - Dormer Eave (5/4" x 4" x 22") 1" x 6" 1" x 3 1/2" 5/8" x 5 3/8" " x 4" 2" x 6" 2" x 3" 1 3/8"...
- Page 9 Hardware Parts Identification (Actual Size) (4) Flat Head Screw #8 x 1-1/8" (9260514) (17) Pan Screw #8 x 1/2" (9264502) (72) Flat Head Screw #8 x 1-1/2" (9260512) (4) Pan Screw #12 x 2" (9264620) (26) Flat Head Screw #8 x 2-1/2" (9260522) (10) Flat Head Screw #8 x 3"...
- Page 11 • THE CARTON I.D. STAMP IS LOCATED ON THE END OF EACH CARTON • YOU WILL NEED THIS INFORMATION IF YOU CALL CONSUMER RELATIONS DEPARTMENT PRODUCT NUMBER: F24068 CARTON I.D. STAMP: __ __ __ __ __ 14459 ___ (Box 1) CARTON I.D.
- Page 12 Step 1 Assemble Two Walls HARDWARE LIST Using 1 Hex Bolt 5/16" x 4" (5/16" T-Nut, Washer and Lockwasher), attach loosely leaving a gap between the Roof Upright (2" x 3" x 42 3/4") 2 pcs 5/16x4" Hex Bolt and 2 Posts (5/4" x 4" x 79"). 2 pcs 5/16"...
- Page 13 Step 2 Assemble Floor Supports HARDWARE LIST Attach 4 T-Nuts 1/4" to the backs of the Floor Supports (5/4" x 4" x 39 1/2"). 4 pcs 1/4" T-Nut Using 2 Wood Screws (#8 x 3") per side attach the 4 pcs #8x3" Wood Screw SL Braces (2 x 3 x 15") to the Floor Supports (5/4"...
- Page 14 Step 4 Attach 2 Walls to Floor Supports HARDWARE LIST Take previously assembled Floor Supports and attach to both Uprights of the previously assembled Walls using 2 Hex Bolts 1/4" x 3 1/2" (1/4" T-Nut, Flat Washer, and Lock Washer). 2 pcs 1/4x3-1/2"...
- Page 15 Step 5 Attach CE Access Boards, Floor Gussets HARDWARE LIST Hold the CE Access Boards against the 2 Posts in the proper position before proceeding to drill, making sure the lower CE Access Boards 20 pcs #8x1-1/2" Wood Screw are flush with the bottom of the Ground Sides, and the upper CE 2 pcs #8x2-1/2"...
- Page 16 Step 6 Assemble CE Floor and CE Rock Boards Hold the CE Rock Board against the 2 Posts. HARDWARE LIST Make sure the CE Rock Boards are evenly spaced between the CE Access Boards,before proceeding to drill. Follow the same procedure for the 40 pcs #8x1-1/2"...
- Page 17 Step 7 Assemble Roof HARDWARE LIST Using 4 Wood Screws #8 x 2-1/2" per side, fasten both Dormer Eaves (5/4 x 4 x 22") to both Roof Sides (1 x 4 x 38"). 14 pcs #8 x 2½" Wood Screw Using 4 Wood Screws #8 x 1-1/8", fasten both Roof Ridges (1 x 2 x 35") together.
- Page 18 Step 8 Attach Dormer Eave to Roof Front Assemby HARDWARE LIST Using 4 Wood Screws #8 x 1-1/2", fasten the Dormer Eave assembly to the Roof Ridge assembly. 4 pcs #8 x 1½" Wood Screw #8 x 1 1/2" Wood Screw Dormer Eave 5/4"x 4"x 22"...
- Page 19 Step 10 Attach Roof to Fort HARDWARE LIST Using 2 Hex Bolts 1/4" x 3" (1/4" T-Nut, Washer, and Lock Washer) attach the Roof Assembly to the Fort. 2 pcs 1/4 x 3" Hex Bolt 2 pcs 1/4" Flat Washer Using 2 Wood Screws #8 x 1-1/2"...
- Page 26 Final Step: Attach I.D. Plaque ATTACH THIS WARNING & I.D. PLAQUE TO A PROMINENT LOCATION ON YOUR PLAY EQUIPMENT! (Fort or Swing Post) This provides warnings concerning safety and important contact information. A Tracking Number is provided to allow you to get critical information or order replacement parts for this specific model Attach with screws provided to a location...
- Page 27 NOTES...
- Page 28 Would you recommend the purchase of our products to friends and family? Comments: MAIL TO: Fill out your registration card online at Solowave Design www.bigbackyard.com/ownerslounge 375 Sligo Road W. Mount Forest, Ontario, Canada Big Backyard would like to say Thank You for N0G 2L1 your time and feedback. Attention: Customer Service...
