  • Page 1 CM900 Monitor User’s Guide...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Monitor User’s Guide ............3 Packing List ................ 3 Safety Information .............. 3 Setup Instructions .............. 5 Swivel Base ...................5 Power Cord....................6 Video Cable ...................7 Operating Instructions ............8 General Instructions ................8 Cleaning the Monitor................8 Front Panel Controls................8 Accessing the Adjustment Controls.............10 Adjusting the Picture................11 Monitor Drivers ..............

  • Page 3: Monitor User's Guide

    PACKING LIST Before setting up and using your monitor, examine the items in the monitor package. If anything is missing or damaged, please contact MicronPC immediately. Look for the following items: • 19-in Cathode-Ray Tube (CRT) Monitor •...
  • Page 4 • The monitor must only be connected to the AC power source as indicated on the label. If you are unsure of the type of AC power available, ask your local power company. Only connect this monitor to a power outlet that matches the power requirements of this monitor. •...

  • Page 5: Setup Instructions

    SETUP INSTRUCTIONS This section provides information for attaching the swivel base to your monitor and for using the power cord and video cable. Swivel Base To attach the swivel base to the monitor, complete the following steps: Carefully turn the monitor upside down. (See Figure 1.) Figure 1: Installing and Removing the Swivel Base Facing the monitor screen, locate the openings on bottom of the monitor.

  • Page 6: Power Cord

    Adjusting the Monitor’s Viewing Angle • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the base so you do not topple the monitor when you change the monitor’s angle.

  • Page 7: Video Cable

    To connect the power cord to your monitor and a power source, use the following instructions: Caution: If the AC outlet is not grounded (with three holes), install the proper grounding adapter (not supplied). Plug the power cord into your monitor’s power input socket. See Figure 3 for the socket’s location.

  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS The following sections provide information about operating and adjusting your monitor. General Instructions To turn on the monitor, complete the following steps: Check that the power cord is connected to the monitor and a power socket. Check that the video cable is connected to your computer’s video port. Locate the power button (see Figure 4 on page 9).
  • Page 9 Figure 4: Control Buttons Table 1: Control Buttons Descriptions Feature Description Exit Press this button to close the On Screen Display (OSD) menu. This will also back out of a menu selection. Press this button to adjust your monitor’s Brightness brightness.

  • Page 10: Accessing The Adjustment Controls

    Accessing the Adjustment Controls The following list explains how to access and use the adjustment controls appearing in the On Screen Display (OSD) Main Menu: Press the Menu button to make the OSD window appear. The menu will look like Figure 5. Press the buttons to select the desired function.

  • Page 11: Adjusting The Picture

    Adjusting the Picture The table below describes the functional control icons that appear on the OSD menu. Table 2: Functional Control Icons Function Icon Description Contrast Use this function to adjust the picture’s contrast. Brightness Use this function to adjust the picture’s brightness. H-Center Use this function to adjust the picture’s horizontal position.
  • Page 12 Table 2: Functional Control Icons (Continued) 6500°K/9300°K The OSD menu presents two different color sets 6500 (Color on the screen. You can select 6500°K or 9300°K 9300 Temperature) by pressing the Menu button. User Color If the 9300°K (normal white) or 6500°K (warmer (Red/Blue) white) is not satisfactory, you can adjust the Red/Blue GAIN controls to obtain the optimum...

  • Page 13: Monitor Drivers

    If you do not have Internet access, you may also call MicronPC Technical Support at (800) 877-8856 to request the files be sent to you. WARRANTY INFORMATION In the unlikely event that you have a failure with your MicronPC monitor, you can contact MicronPC Technical Support at http://www.micronpc.com/support/index.html.

  • Page 14: Plug & Play Ddc1/2B Feature

    If the following information does not successfully solve your issue, please visit the MicronPC Technical Support Site at http://www.micronpc.com/support/index.html. If you do not have Internet access, you may also call MicronPC Technical Support at (800) 877-8856. Table 3: Troubleshooting Monitor Issues...
  • Page 15 Table 3: Troubleshooting Monitor Issues (Continued) • The picture is fuzzy. Adjust the contrast and brightness controls. • Make sure there are no electrical devices or power sources within 30 inches of the display. These devices may cause interference. • Try manually degaussing the monitor.

  • Page 16: Appendix B - Factory Preset Timing

    APPENDIX B — FACTORY PRESET TIMING Table 4: Factory Preset Timing Standard Resolution Horizontal Vertical Frequency Frequency 720 x 400 31.50 kHz 70 Hz 640 x 480 31.50 kHz 60 Hz VESA 640 x 480 43.20 kHz 85 Hz 800 x 600 53.60 kHz 85 Hz 1024 x 768...

  • Page 17: Appendix C - Connector Pin Assignment

    APPENDIX C — CONNECTOR PIN ASSIGNMENT Figure 6: 15-pin Color Display Signal Cable Table 5: Video Cable Pin Assignments Pin # Description Pin # Description Green Ground Blue Monitor Ground Ground DDC-Serial Data Ground H-sync R-Ground V-sync G-Ground DDC-Serial Clock B-Ground APPENDIX D —...
  • Page 18 Table 6: Monitor Specifications (Continued) • Dot Clock 200 MHz • Recommended Viewing Minimum: 800 x 600 @ 85 Hz Resolutions • Nominal: 1280 x 1024 @ 85 Hz • Maximum: 1280 x 1024 @ 85 Hz • Maximum Resolution 1600 x 1200 •...

  • Page 19: Appendix E - Fcc Notice

    APPENDIX E — FCC NOTICE FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
