I NS T R U CT I O N M A N UA L
BABY ZOOM™ WIFI
VIDEO MONITOR & INTERNET
VIEWING SYSTEM
WARNING:
STRANGULATION HAZARD - Children have
STRANGLED in cords. Keep this cord out of reach
of children (more than 3 feet (0.9 m) away from the
crib). Use enclosed Security Clips to help secure cord away
from baby's reach. Never use extension cords with AC
Adapters. Only use the AC Adapters provided.
System Requirements: You need a broadband Internet connection
(cable/DSL) with recommended upload speed of 300 bps and a wireless
router or a cable/DSL modem. You must have a smartphone or tablet with
Android 2.3.4. or higher or Apple iOS 5.0 or higher for setup.
Keep this instruction manual
Tools required for wall mount:
screwdriver and drill (not included)
For technical support see back page.
Please read the
following instructions
and warnings carefully.
for future reference.
Adult use only.
WARNING:
BC
Adult assembly required.
Keep small parts away from
children when assembling
2 8 6 3 0
.
Advertisement
Table of Contents
Related Manuals for Summer 28630
Summary of Contents for Summer 28630
- Page 1 2 8 6 3 0 Please read the following instructions and warnings carefully. Keep this instruction manual for future reference. Tools required for wall mount: screwdriver and drill (not included) For technical support see back page. Adult use only. WARNING: Adult assembly required.
- Page 2 BATTERY WARNING: • Use only the original rechargeable battery provided. Please contact Summer Infant, Inc. for replacement battery. Contact information can be found at the end of these instructions or on the battery itself. • Clean battery and product contacts prior to battery installation.
- Page 3 components: hardware: Camera Monitor AC Adapters (2) features (monitor): front back Sound Video On/Off Lights Power/ Menu Volume Talk Up/Down Back Belt Clip/ Pan/ Kickstand Scan/ Brightness Menu Up/Down Control Zoom/Select AC Adapter Jack Microphone Battery Compartment features (camera): front back Power On LED Camera...
- Page 4 setting up a camera for the first time: Connect your device (phone or tablet) to your home WiFi Network and download the free APP for your Apple ® or Android™ phone or tablet. Welcome Welcome to the AT&T AT&T 12:34 PM 12:34 PM to the Google...
- Page 5 camera setup (table top): Determine a location for the camera that will provide the best view of your baby in the crib. Place the camera on a flat surface, such as a dresser, bureau or shelf. NEVER place camera or cords within 3 feet of the crib.
- Page 6 camera setup (wall mount option): WARNING: STRANGULATION HAZARD - Children have STRANGLED in cords. Keep this cord out of reach of children (more than 3 feet (0.9 m) away from the crib). Use enclosed Security Clips to help secure cord away from baby’s reach.
-
Page 7: Pairing Monitor And Camera
pairing monitor and camera: The monitor and camera are paired at the factory for privacy reasons. If the monitor and camera are not pairing with each other for any reason, follow steps to re-pair: 1. Move the monitor to the same area as the camera and make sure both are turned on. - Page 8 camera features: • Pan/Scan: Keeping baby in view is important as they get more mobile and curious. Parents can use the pan and scan feature to adjust the camera view by pressing the up, down, left, and right arrows on the front of the in-home handheld. •...
- Page 9 internet status lights: Remote Internet & Local Internet Connection Four solid green LEDs indicates your camera has a local and remote internet connection. This means you can view on your smartphone, tablet, or computer in and out of your home. Note: You can turn off the lights on the front of the camera by sliding the Internet Status Light switch on back of camera.
- Page 10 smartphone & tablet features: Home Logout screen Status Press the up and down arrows and the left and right arrows to move the camera and change view on screen. Tap the screen to make arrows appear or disappear. Pinch the screen to zoom in on the image on live viewing screen.
- Page 11 smartphone & tablet features: Privacy Mode allows you to block anyone outside your home from remote viewing. Remote viewers are anyone you’ve shared access with, viewing on a network other than your home network. Press Volume to adjust the volume of your live video. Slider bar will appear.
- Page 12 viewing on a PC or Mac: Visit www.summerlinkwifi.com to view on your PC or Mac computer. You must have Internet Explorer 9 and higher, Firefox 4.0 or higher, Chrome, or Safari 5.0 or higher. problem solving & troubleshooting: IN-HOME HANDHELD MONITOR: No picture or sound: •...
- Page 13 add a Link WiFi camera: The Baby Zoom WiFi Video Monitor & Internet Viewing System accepts up to 2 cameras, and enables parents to monitor more than one child or room in the home. The expandable system gives parents the ability to easily and conveniently keep an eye on things from wherever they are, anytime.
- Page 14 IM PORTAN T S A F ETY INSTRU CTIONS 1) Read Instructions - All the safety and operating instructions should be read before the product is operated. 2) Retain Instructions - The safety and operating instructions should be retained for future reference.
- Page 15 Summer Infant, Inc. Monitor Warranty Policy Summer Infant, Inc. will repair or replace (at our option) your unit free of charge for 12 months from the date of purchase if the unit is defective in workmanship or materials. To claim your repair/replacement, the product must be returned to Summer Infant along with a copy of the original purchase receipt.
- Page 16 We LOVE our consumers! Get to know us at: www.summerinfant.com Summer Infant stands behind all of its products. If you are not completely satisfied or have any questions, please contact our Consumer Relations Team between 8AM - 6PM EST at 1-800-268-6237 or www.summerinfant.com/contact...
