- Page 1 WOO AUDIO WTP-1AND WDS-1 Top-Loading CD Transport & 24-Bit/192kHz Digital to Analog Convertor Owner’s Manual Please review this manual before operating your WOO AUDIO™ product. ©2012 WOO AUDIO Inc. All rights reserved. www.wooaudio.com Rev 1.1. Feb 20, 2014 1 ...
-
Page 2: Important Safety Information
Important Safety Information CAUTION: These amplifiers are shipped without the vacuum tubes installed. It is necessary to install the tubes first. It is essential that the tubes are installed correctly or serious damage that is not covered by the warranty will result. Turn off immediately in the event of malfunction Should you notice smoke or an unusual smell coming from the equipments, turn it off immediately. -
Page 3: Table Of Contents
Table of Contents IMPORTANT SAFETY INFORMATION TABLE OF CONTENTS OVERVIEW GETTING STARTED QUICK INSTALLATION OPERATIONS FAQ - FREQUENTLY ASKED QUESTIONS WARRANTY AND SERVICE PRODUCT SPECIFICATION WDS-1 PRODUCT SPECIFICATION WTP-1 ©2012 WOO AUDIO Inc. All rights reserved. www.wooaudio.com Rev 1.1. Feb 20, 2014 3 ... -
Page 4: Overview
WTP-1 Overview Thank you for choosing a Woo Audio product. The WTP-1 is finely hand-crafted Top- Loading CD Transport that delivers uncompromised performance and superior listening experience. Vibration resistant CD tray construction Customized high damping suspension springs for CD tray ... - Page 5 WDS-1 Overview Thank you for choosing a Woo Audio product. The WDS-1 is finely hand-crafted Digital to Analog Converter that delivers uncompromised performance and superior listening experience. 24-Bit, 192kHz high resolution playback Ultra-low jitter USB 2.0 runs on Asynchronous mode ...
-
Page 6: Getting Started
Getting Started What’s in the box? WTP-1 ① WTP-1 Top-Loading CD Transport ② Premium Remote Control ③ Magnetic Disc Clamp ④ Rubber Transport Plate WTP-1 ① WDS-1 Digital to Analog Converter Power cord and AC Umbilical cord are not included and can be purchased separately. - Page 7 Back Panel Diagram WTP-1 WDS-1 ① AC Inlet ② AC Umbilical Cord Female Outlet ③ AC Umbilical Cord Male Inlet ④ Fuse Port ⑤ Optical Output(Top) and Input(Bottom) ⑥AES/EBU Output(Top) and Input(Bottom) ⑦Coaxial BNC Output(Top) and BNC Input(Bottom) ⑧ USB 2.0 Input ⑨...
- Page 8 Front Panel Diagram WTP-1 WDS-1 ⑪ WTP-1 Power Button/Simultaneous Power button when units are stacked ⑫ WDS-1 Power Button ⑬ Play/Pause Button ⑭ Stop Button ⑮ Rev/Rewind(Hold down) Button ⑯ Next/Fast Forward(Hold Down) Button ⑰ Input Button ⑱ Filter Button ⑲...
- Page 9 Volume Down Volume Up The Premium Remote Control is included standard with the WTP-1 and can be purchased separately for the WDS-1 Premium Remote Control has a range of 10 feet working at angles up to 30 degrees ©2012 WOO AUDIO...
-
Page 10: Quick Installation
U.K. U.S. Take the AC umbilical cord and plug it into AC Female Outlet ② of the WTP-1 and AC Male Inlet of WDS-1 ③. Refer to the above diagram. * If you are intending to use the AC umbilical cord to stack the two units, attach and power up the two units first side by side before stacking the units together. - Page 11 Powering Up To power up on the WTP-1 press the power button⑪ until pressure is felt and the VFD screen should turn on. To power up on the WDS-1 press the power button⑫ until pressure is felt and the VFD screen should turn on.
- Page 12 Using the Asynchronous USB 2.0 port: The WDS-1 offers a fourth source of music input, a USB 2.0 port ⑧ refer to the above diagram, which allows for usage of the WDS-1 DAC with Windows or Mac OS computer. Installing the USB driver *These steps only apply for Windows XP/Vista/7/8.
- Page 13 Connecting the Amp to the WDS-1: The WDS-1 offers two sources of output, XLR ⑨ and RCA ⑩ refer to the above diagram to connect the amp of your choice. We highly recommend one of our Woo Audio Amplifiers. ©2012 WOO AUDIO Inc. All rights reserved. ...
-
Page 14: Operations
Before you begin using your WTP-1 make sure you remove the rubber transport plate from the CD tray. Opening of the CD tray on the WTP-1 is done by sliding the cover horizontally until it rotates to the left and the CD tray is revealed. - Page 15 Using the WDS-1 Digital to Analog Converter: Now that we have everything properly connected and setup we can begin to enjoy the music. Buttons Input: Allow for the selection of input device. Coaxial -> Optical -> AES/EBU -> USB Filter: Choose one of two of our filter settings ...
-
Page 16: Faq - Frequently Asked Questions
I want to change my unit from 110v to 220v but I can’t seem to find the switch. o The WTP-1 and WDS-1 units are not customer switchable but instead can be factory configured before you order or you can send it in and we can change it for you. -
Page 17: Warranty And Service
Warranty and Service Woo Audio warrants this product free from defects in materials and workmanship for 1 year from the original date of purchase. The tubes are warranted for 30 days unless otherwise stated. In the event that your Woo Audio product requires servicing, please contact us directly to get a return instruction. - Page 18 Product Specification Model: WDS-1 Chipset: PCM1795 D/A USB receiving chipset: C-Media 6631A Sampling Rate: Up to 24-Bit, 192kHz for all inputs Inputs: Asynchronous USB 2.0, Optical, AES/EBU, Coaxial BNC Outputs: 1 RCA unbalanced, 1 XLR balanced Max Output: 2.2vRMS@RCA, 4.4vRMS@XLR Frequency response: 10Hz to 20kHz, +/- 0.5dB Distortion:...
- Page 19 84mm (H) x 230mm (W) x 320mm (D) measurement, same for both units: Weight (AMP & PSU): 10 lbs / 4.5 kg Woo Audio is committed to continuously improve its products. We reserve the right to improve the design without notice. ©2012 WOO AUDIO Inc. All rights reserved. ...
