KAM BDX900 USB
HARDWARE
OVERVIEW
The KAM BDX900 USB turntable is designed to give you
maximum flexibility and features for minimum cost. This
deck should combine all the features you may have
wished for with a top build quality and specification.
PRECAUTION
Read the manual carefully before operation.
Do not remove cover or back to prevent electrical shock.
NO USER REPLACEABLE PARTS INSIDE.
The apparatus should not be exposed to dripping or
splashing and no objects filled with liquids, such as
drinks glasses, should be placed on the apparatus. Use
the unit on a flat surface. Be sure not to connect the
power or cables before moving the unit. Do not use
chemical solvents on the unit.
Checklist of Parts:
1 x Turntable unit
1 x Turntable platter
1 x Slip mat
1 x 45 RPM adapter
1 x Counterweight
1 x Cartridge
1 x Headshell
1 x Target light
1 x USB cable
1 x mains power cable
q START/STOP BUTTON Press this button to start
1% ANTI-SKATE KNOB This applies inward force to
or stop the platter.
the tone arm so it doesn't skip outward across
the record due to the centrifugal force of the
w PLATTER The platter is equipped with a
slipmat. This makes it easier to manipulate the
record spinning. Cartridge manufacturers usually
record for scratch performances.
specify the proper setting for this.
1^ TONE ARM LIFT Controls the up and down
e MOTOR OFF Press the button to disengage the
motor, and the LED will flash. Press the button
action of the tone arm.
again to re-engage the motor.
1& TONEARM CLAMP & REST Use this rest for the
r TARGET LIGHT Insert target light to the deck
tonearm while changing a record. Attach the
and it will light up.
tonearm to the rest using the clamp when the
turntable isn't used or when it is transported.
t PLATTER REVOLUTION SPEED BUTTONS For 33
rpm - press 33. For 45 rpm - press 45. For 78
This prevents the tone arm from accidentally
rpm - press 33 & 45 simultaneously.
turning towards the platter and damaging the
needle of the cartridge.
y REVERSE This button is used to reverse the
direction of the platter rotation.
1* HEAD SHELL LOCKING NUT Attach the head
shell by inserting it into the front end of the tone
u PITCH SLIDER Use this to change the speed of
the platter. When the pitch slider is at 0%, the
arm and then turn the locking nut clockwise.
pitch indicator will light.
1( HEADSHELL Install cartridge here. When
installing a cartridge, refer to the installation
i 45RPM ADAPTER Place on center spindle for
instructions supplied by the manufacturer of that
playing 7" records with large center holes.
cartridge. Attach the stylus protector to guard
o POWER ON/OFF SWITCH Used to turn the
turntable on and off.
the stylus tip from damage.
Attach wires as follows:
1) POWER CORD CONNECTOR Used to connect to
the mains, using the supplied power cord.
White (L+) Left channel +
1! USB SOCKET USB output connection.
1@ PHONO/LINE SWITCH This is a switchable
Blue (L-) Left channel –
'phono level' or 'line level' output (using RCA
jacks) which can be connected to the 'phono' or
Red (R+) Right channel +
'line' input on an exterior unit.
1# TONE ARM This is a fully manual tone arm. To
Green (R-) Right channel –
start playback, gently place the stylus on the
record using the headshell finger support. Don't
Visit the Kam website: www.kam.co.uk/tuition for
drop the stylus onto the record as it may cause
full tone arm assembly instructions.
damage to the diamond tip and to the record.
2) OUTPUT L & R This is the standard analog
1$ COUNTERWEIGHT Adjustment creates the
output (RCA jacks) which can be connected either
proper downward pressure of the stylus to the
to a phono or line input on any DJ mixer, or
record. By sliding the counterweight onto the
amplifier depending on the setting of the phono /
rear of the tone arm. Twist it lightly and it will
line selector.
screw onto the rear shaft of the tone arm.
BELT DRIVE USB TURNTABLE
q
e
1$
1&
w
1#
1*
1(
y
t
q
r
1@
1!
2)
1)
o
OPERATING
1. Turn the power dial to turn on and the speed
indicator and the strobe-illuminator will light up.
2. Insert target light for illumination the stylus.
3. Place a record on the turntable mat. When
playing a 45rpm record with a large center hole;
place the 45rpm adapter on the center spindle.
4. Set the rotation speed to match the record.
5. Release the arm clamp.
6. Set the cueing lever to the up position.
7. Press the Start/Stop button and the turntable
platter will start to rotate.
8. Move the tone arm over the desired groove.
9. Set the cueing lever to the down position, the
tone arm will descend slowly onto the record and
play begins.
10. Adjust the pitch to a desirable speed. During
play, observe the strobe dots. If the strobe dots
appear to the right, the pitch is slower than the
rated speed. If they flow to the left, the rated
speed. If the strobe dots appear stationary, which
means the platter is in normal turntable speed,
move the pitch control slider up or down to
adjust the speed.
11. To suspend play, lift arm with cueing lever.
12. When play is finished, raise the cueing lever,
move the tone arm to the armrest and secure
the tone arm with the arm clamp.
13. Press the Start/Stop button to stop the
platter rotating.
14. Turn the power dial to turn off the power.
FURTHER INFORMATION
You will find two free downloadable PDF files at
www.kam.co.uk/tuition. One covers everything
you need to know about correct connection and
installation of you new Kam turntables and all
other related equipment. The other provides a
step by step guide to mixing for beginners.
SPECIFICATION
MOTOR
DC motor
DRIVING METHOD
Belt drive
START TIME
Less than 1 second
STOP TIME
Less than 1 second
1%
SPEED SELECTION
33rpm / 45rpm / 78rpm
SPEED ADJUSTMENT
+/-10%
1^
WOW & FLUTTER
Less than 0.2% WRMS (JIS WTD)
i
TONE ARM TYPE
Static balanced S-shaped tone arm
TRACKING ERROR ANGLE
Less than 3°
CARTRIDGE WEIGHT
13 ~ 18g
u
ANTI-SKATE RANGE
0 ~ 4g
COMPUTER INTERFACE
USB 1.1 compliant
Windows ME/2000/XP
Apple OS9.1 / OSX
POWER SUPPLY
AC240V ~ 50Hz
POWER CONSUMPTION
5.5 Watts
DIMENSIONS
449 x 145 x 370mm
WEIGHT
4Kgs
Due to continuous product development, specifications and appearance are subject to change.
