hg6300, hg6310 & hg6320
Gas Hobs
Manual for Installation, Use and Maintenance
Customer Care Department • The
Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the hg6300 and is the answer not in the manual?

Questions and answers

Related Manuals for CDA hg6300

Summary of Contents for CDA hg6300

  • Page 1 Gas Hobs Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu...
  • Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
  • Page 3 safety (LVD) and Electromagnetic interference compatibility (EMC). Parts intended to come into contact with food conform to EEC/89/109. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
  • Page 4 • This hob (Class 3) has been designed for use only as a cooking appliance. Any other use (e.g. heating rooms) should be considered incorrect and potentially dangerous. • These instructions are valid only for the countries of destination, the symbols of which appear on the cover and on the appliance.

  • Page 5: Using Your Hob

    Using Your Hob Fig. 1 Gas burners: Gas flow to the burners is controlled by the control knobs (5, 6, 7 and 8 on the diagrams on pages 6 & 7). There are 3 positions shown on the control panel. Turning the control knob to the positions shown below achieves the following: Closed (OFF position) Maximum position: Provides fast boiling function...
  • Page 6 Fig. 2 hg6310 Fig. 3...
  • Page 7 hg6320 Fig. 4 Key to Figs 2, 3 & 4 Gas burners: 1. Triple burner 3.5kW 2. Rapid burner 3.0kW 3. Semi-Rapid burner 1.75kW 4. Auxiliary burner 1.0kW Control panel: 5. Front left burner control knob 6. Back left burner control knob 7.

  • Page 8: Igniting The Burners

    Igniting the Burners The hob is fitted with a flame failure device. Flame failure devices operate by shutting off the supply of gas to the burner in the event that the flame is extinguished accidentally. Fig. 5 To ignite the burners, follow these instructions: 1.

  • Page 9: Efficient Use Of Your Hob

    Efficient Use of Your Hob The hob is equipped with burners of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate burner depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and burner are correctly chosen.
  • Page 10 Correct Use of the Optional Wok Pan Adaptor (hg6310 & hg6320 only) The wok pan adaptor is a special stand that is designed to be fitted over the triple ring burner to give support to round bottomed woks. When using a wok, always place the wok pan adaptor in position over the pan support on the triple ring burner as shown in Fig.5.

  • Page 11: Care And Maintenence

    Care and Maintenence As the hob has a stainless steel or enamel surface, you should use a nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. Stainless steel can be effectively cleaned by simply using a dilute solution of water and mild detergent and drying to a shine with a clean cloth.
  • Page 12 127.3 125.4 Rapid 218.8 214.8 Triple Total rated gas input : 7.5kW (hg6300) 8.0kW (hg6310 & hg6320) Mains electrical voltage: 230 – 240Vac, 50Hz Total rated electrical consumption: <1W If Your Hob is Not Working 1. Check that the mains supply has not been switched off.

  • Page 13: Mains Electricity Connection

    Mains Electricity Connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE. DOUBLE POLE SWITCHED We recommend that the appliance is FUSE SPUR OUTLET connected by a qualified electrician, who is a member of the N.I.C.E.I.C.

  • Page 14: Gas Supply Requirements

    • T his appliance is category II2H3+ and is designed for use in the UK and Ireland. The installation must comply with the Gas Safety (installation and use) Regulations 1984. • T he CDA Group Ltd is not legally able to provide any assistance in the installation of gas appliances except to Gas Safe registered installers. Any Gas Safe registered fitter requiring help must provide their name, address and registration number.
  • Page 15 Ventilation All rooms require a window or equivalent (e.g. a door) which can be opened. Some rooms require a permanent vent in addition to a win- dow (see below). This unit must not be used in a room which is less than 5m .

  • Page 16: Natural Gas To Lpg Conversion

    Natural Gas to LPG Conversion This hob can be converted from natural Required: gas to propane operation at a nominal • 7mm AF nut spinner inlet pressure of 37mbar, or butane • Replacement injectors • LPG identity plate operation at a nominal inlet pressure of 28/30mbar. This conversion must only be carried out by a competent person Fig.
  • Page 17 LPG to Natural Gas Conversion Required: • 7mm AF nut spinner This hob can be converted from • Replacement injectors propane operation at a nominal • NG identity plate inlet pressure of 37mbar or butane operation at a nominal inlet pressure of 28/30mbar to natural gas at 20mbar. This conversion must only be carried out by a competent person (i.e.

  • Page 18: Fitting The Hob

    Fitting the Hob Unpacking the hob: Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 150mm away from any adjacent vertical surfaces, e.g.

  • Page 19: How To Install The Hob

    withstanding temperatures 65°C above ambient or greater (typically 80-90°C). • I f there is no oven to be built in below the hob it is recommended that, an isolation shelf should be fitted to protect the user from high temperatures. If the hob is to be installed above a working drawer, then a partition should be fitted to protect the contents and user from the heat generated during use.
  • Page 20 2. Position the hob seal, as shown in the diagram below (Fig. 14), ensur- ing that the ends meet without overlapping. Do not use silicone type sealant. 3. Secure the hob to the worktop using the fixing brackets and screws supplied, as shown in the following diagram (Fig.
  • Page 21 NOTES:...
  • Page 22 NOTES:...
  • Page 23 NOTES: E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
  • Page 24 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu © CDA 2014...

This manual is also suitable for:

Hg6310Hg6320Hg6100Hg6120
