Summary of Contents for Sirius XM RAdio SXSD2
- Page 1 Portable Speaker Dock Installation & User Guide...
-
Page 3: Table Of Contents
Table of Contents Introduction ..........4 Compatibility . -
Page 4: Introduction
. For the latest information about this and other SiriusXM product and accessories, visit www.siriusxm.com . Compatibility The SXSD2 Portable Speaker Dock is compatible with these Dock and Play Radios: SiriusXM Dock & Play Radios: • Onyx Plus and Edge XM Dock &... -
Page 5: Safety Precautions
. • Installation must be performed according to this installation guide . Sirius XM Radio, Inc . is not responsible for issues arising from installations not performed according to the procedures in this guide . • Use only the provided AC Power Adapter . - Page 6 Introduction • Make sure that you insert the AC Power Adapter’s plug all the way into the outlet . • Insert the Radio into the Portable Speaker Dock only when the Portable Speaker Dock is off . • This device should be unplugged from the AC outlet during a thunder and lightning storm, and when the device will not be used for an extended period of time .
-
Page 7: What's In The Box
Introduction What’s in the Box? Adapter 1 (SiriusXM & XM Radios) Adapter 2 (Sirius Radios) Portable Speaker Dock Radio Dock Adapters memo display t-mix menu direct – mute jump bank PULL Indoor/Outdoor Remote Control AC Power Adapter Power Cord Home Antenna... -
Page 8: Controls And Connectors
Introduction Controls and Connectors The following section identifies and describes the controls and connectors of the Portable Speaker Dock . Front View Rear View source aux in Bottom View 1. Power and Volume Knob: Pressing the knob turns the Portable Speaker Dock’s power On or Off . - Page 9 Introduction 4. Radio Dock Adapter Slot: Holds adapter for the Radio . 5. Headphone Connector: Stereo headphone jack to privately listen to the Portable Speaker Dock . 6. Power On/Low Battery/Mute Light: The light is blue when the Portable Speaker Dock is powered on . The light will turn red when the batteries in the Portable Speaker Dock are nearly discharged and need replacement .
-
Page 10: Remote Control Functions
Introduction Remote Control Functions Arrow Buttons Up/Down Power Button Press to preview and tune to channels Press to turn Portable Speaker through the channel lineup; also press to Dock on and off. scroll through lists and highlight menu items. Pause and Replay Buttons For Radios which have these features, Arrow Buttons Left/Right pause, rewind, and replay live radio... -
Page 11: Remote Control Battery Replacement
Introduction Remote Control Battery Replacement The Remote Control has a child resistant battery compartment which requires a pointed object to open the battery compartment . A paper clip is recommended, as shown . To Replace the Battery: 1. Press the paper clip or Paper Clip other object into the lock release opening... -
Page 12: Installation
Installation Installing the Radio Dock Adapter for Your Radio 1. Select the Dock Adapter for your Radio by referring to “What’s in the Box?” on page 7 to identify the adapter, or turn the adapters over and locate the name imprinted on the underside of the adapter: SiriusXM &... -
Page 13: Docking The Radio
Installation Docking the Radio Place your Plug and Play Radio into the Portable Speaker Dock as follows: 1. Be sure the Portable Speaker Dock is powered off . 2. Align the Radio with the Radio Dock Adapter and connector . 3. -
Page 14: Removing The Radio Dock Adapter
Installation Removing the Radio Dock Adapter If it becomes necessary to remove the Radio Dock Adapter, remember that the Radio Dock Adapters are constructed from precision molded plastic . During removal, extra care must be taken to not bend, force, or otherwise stress the adapter, or break off the tabs that hold the adapter in the Portable Speaker Dock . -
Page 15: Installing The Indoor/Outdoor Home Antenna
Installation Installing the Indoor/Outdoor Home Antenna Before installing the Indoor/Outdoor Home Antenna, please read this entire section . The Indoor/Outdoor Home Antenna should be placed into the storage area on the top of the Portable Speaker Dock as shown below . The antenna clamshell should face the sky . -
Page 16: Using Your Portable Speaker Dock Outdoors Or On-The-Go
Installation Using Your Portable Speaker Dock Outdoors or On-The-Go If you are using the Portable Speaker Dock outdoors, try using it with the antenna in the storage area . Place the Portable Speaker Dock where there are no obstructions to block the antenna’s view of the sky, such as trees, bridges, buildings, etc . -
Page 17: Other Indoor/Outdoor Antenna Installation Suggestions
Installation Aiming screen of your Radio to see a visual indication of signal strength . If you’re receiving a good Satellite and Terrestrial signal strength, you’re done . If not, try some of the suggestions which follow . Other Indoor/Outdoor Antenna Installation Suggestions If you find you are getting a signal, but it’s inconsistent, try moving the Indoor/Outdoor Home Antenna closer to a window, ideally one that is facing... - Page 18 Installation an unobstructed view . No trees or buildings blocking its aim . If the antenna is aimed through a window, be aware that blinds, screens, or any other non-glass elements such as thermal SOFFIT insulation can sometimes cause reception issues . If this is the case, you may want to use another window or place the antenna outside of the window .
- Page 19 Installation probably want to purchase a second indoor/ outdoor antenna, so that you’ll have one to use with the Portable Speaker Dock when on-the-go . An additional antenna can be purchased at www.siriusxm.com . 1-3/8 in Note that you will want to consider any potential hazards when you choose the mounting location, and possibly consider 1-1/8 in...
- Page 20 Installation Indicator or Antenna Aiming screen .) If the signal reception is low, or intermittent, try another location for the antenna . Verify that the antenna is pointed south, and that the antenna’s view of the sky is not blocked by a tree, a building, a bridge, or anything else . Adjust until you are receiving a good signal .
-
Page 21: Subscribing To The Sirius Or Xm Service
Subscribing to the Sirius or XM Service If you have not yet subscribed to the Sirius or XM satellite radio service, you’ll need to before you can listen to SiriusXM programming on your Radio . To subscribe, refer to the Quick Start Guide which accompanied your Radio for instructions, or go to www.siriusxm.com/guides to access the Quick Start and User Guides for your Radio . -
Page 22: Operation
Operation Power on the Portable Speaker Dock by pressing the Power/Volume knob on the front panel . The light on the front panel surrounding the knob should light up blue to indicate power is on . If the Radio does not power on at the same time, press the Power button on the Radio . - Page 23 Operation estimated at approximately 8 hours at half volume . Expect the actual battery life to vary . Storing the Portable Speaker Dock When the Portable Speaker dock is powered off, it is placed into sleep mode, and continues to use a small amount of power . For this reason, if you do not intend to use the Portable Speaker Dock for a period of time, do one of the following: • Keep the Portable Speaker Dock connected to an outlet using the AC...
- Page 24 Operation Muting the Audio The audio of the Portable Speaker Dock can be muted by pressing the Mute button on the Remote Control . When the audio is muted, the light which surrounds the Power/Volume knob will blink to indicate the Portable Speaker Dock is muted .
-
Page 25: Optional Accessories
Optional Accessories The following optional accessories are available for purchase from your SiriusXM retailer or at www.siriusxm.com to maximize your SiriusXM experience . SiriusXM Home Distribution Kit Connect up to two Sirius or XM Radios to an outdoor antenna up to 150 feet away using standard off-the-shelf RG6 cables . -
Page 26: Troubleshooting
Troubleshooting Symptom Solution Portable Speaker Dock The AC Power Adapter is not connected, or does not power on the AC outlet into which it is plugged is not working . Check that the AC Power Adapter is connected to the Portable Speaker Dock . Try plugging the AC Power adapter into a different outlet . - Page 27 Troubleshooting Troubleshooting Continued Symptom Solution Radio displays: Acquiring No satellite signal is being received . Check Signal for obstacles over or around the antenna . Ensure that the antenna is pointed in the right direction toward the sky for your area to be able to see the satellites .
-
Page 28: Specifications
Specifications System Power Requirements: 12V DC, or 8 D-size alkaline batteries Operating Temperature: 32°F to 122°F (0°C to 50°C) Power: 5W RMS per channel (max) Frequency Response: 60 Hz – 20KHz Total Harmonic Distortion (THD): 0 .2% at 1 Watt Signal-to-Noise Ratio (S/N): 70dB Maximum Headphone Output Impedance:... -
Page 29: Fcc Statement
• Consult the dealer or an experienced radio/TV technician for help . WARNING! The FCC and FAA have not certified Satellite Radio Receiver use in any aircraft (neither portable nor permanent installation) . Therefore, Sirius XM Radio Inc . cannot support this type of application or installation . -
Page 30: Copyrights & Trademarks
Copyrights & Trademarks ©2014 Sirius XM Radio Inc . “Sirius”, “XM” and all related marks and logos are trademarks of Sirius XM Radio Inc . “BBC” and “Radio One” are trademarks of the British Broadcasting Corporation and are used under license . BBC logo © BBC 1996 . -
Page 31: Indoor/Outdoor Antenna Template
Indoor/Outdoor Antenna Template 1-3/8” 1-1/8”... - Page 32 Sirius XM Radio Inc. 1221 Avenue of the Americas siriusxm.com New York, NY 10020 1.866.635.2349 © 2014 Sirius XM Radio Inc . SXSD2 140303b...
