T W O - W A Y
S T A R T E R
PS-7080 TW
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere
between 3 to 6 months. When the battery is low, the transmitter will
produce two beeps in a repetitive cycle. At that point you should
replace your battery with a new one. That is why we recommend that
you keep a spare battery somewhere handy such as the glove
compartment.
P. 1
M A N U A L
S Y S T E M
UserGuide
T R A N S M I S S I O N
W I T H
F U L L
R E M O T E
A L A R M
User Guide
Advertisement
Table of Contents
Related Manuals for Polarstart PS-7080 TW
Summary of Contents for Polarstart PS-7080 TW
- Page 1 S Y S T E M W I T H F U L L A L A R M PS-7080 TW UserGuide A note concerning the battery inside the transmitter: Depending on your usage of the transmitter, the battery can last anywhere between 3 to 6 months.
-
Page 2: Table Of Contents
Table of Contents Table of Contents......... 2 Start Attempts Indicator (Valet Introduction..........2 Mode) ............. 9 Using the Remote Control....2 “Home Valet ” Mode......9 LCD Remote Functions ....... 3 Remote Valet Mode ......10 LCD Transmitter Operation (First Panic Mode..........10 Car Control)........... -
Page 3: Lcd Remote Functions
The functions of the transmitter are as follows: LCD Remote Functions The transmitter offers several command-confirmation and timer features. This section explains some of the key functions available on the remote control. Next section gives a summary of the button combinations used to access the functions (see LCD remote operation tables). Note: If you wish to exit a function while still in the process of accessing it, simply stop and wait for at least 10 seconds: the transmitter will return to its normal state. -
Page 4: Time Or Alarm Clock Adjustments
Press once to switch the Alarm Clock ON ALARM CLOCK Melody Press twice to switch the Alarm MODE ON/OFF Clock OFF Time or Alarm Clock Adjustments User Transmitter The backlight will turn on the moment the 1. Press and hold the button until a FUNCTION button is pressed. -
Page 5: Home Valet Tm
Home Valet FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS / DESCRIPTION Step 1 : Press ; within 5 seconds, TO ENTER HOME 1 BEEP press icon w ill be Step 2: VALET ™ MODE simultaneously within 5 displayed and there will be 1 beep. seconds Insert the key in the ignition switch TO EXIT HOME... -
Page 6: Runtime Options (Once The Car Has Been Remote Started)
*Runtime Options (once the car has been remote started) FUNCTION BY PRESSING ICON DIESEL 4 minutes 9 minutes ENGINE RUNTIME 15 minutes 20 minutes 25 minutes 30 minutes LCD Transmitter Operation (Second Car Control) Basic Vehicle Operation FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION... -
Page 7: Remaining In Ready Mode
Press and hold either: to lock the doors and shut down the engine; LOCK to unlock the doors and shut down the engine; UNLOCK to shut down the engine without affecting the doors. START/STOP Remaining In Ready Mode Once the vehicle is in ready mode you can start and stop the vehicle at wish. However, should any of the following occur, the vehicle will exit ready mode –... -
Page 8: Using The System
Using the System Arming and Disarming the System To d i s a r m the alarm and starter kill (if installed) and unlock the doors (if installed): Press and hold the button for approx imately 1 second. UNLOCK There will be two chirps if the siren or horn is so configured. icon will appear, the parking lights will flash twice and the L.E.D. -
Page 9: Valet Mode With The Valet Switch
5. Exit the vehicle and close the door. 6. Press and hold either: to lock the doors and shut down the engine after 60 sec.; LOCK to unlock the doors and shut down the engine after 60 sec.; UNLOCK to shut down the engine immediately, without affecting the doors START/STOP (This will by -pass turbo mode). -
Page 10: Remote Valet Mode
To take the system o u t o f home valet mode: • Turn the ignition key to the position. IGNITION ON (RUN) The system will warn you if someone attempts to start your vehicle while it stands in Home Valet Mode. -
Page 11: Temporary Chirp Delete
To exit cold weather mode, do any one of the following actions: • Open the hood. • Start the engine by remote. • Turn the ignition key to the position. IGNITION ON (RUN) • Press the brake pedal. • Press and hold the button for 3 seconds (the parking lights will flash once). -
Page 12: Shock Sense, Warn-Away Sense
not be able to st a rt your vehicle with the key unless the system has been unlocked and disarmed first, or put into valet mode. Note: If the starter kill is installed, your vehicle will benefit from a protection against starter motor damage that could occur after remote-starting the engine should the user, by force of habit, turn the ignition key to the position. -
Page 13: Ignition-Controlled Door Locks
Ignition-controlled Door Locks This is an added security feature. If your system was installed with the ignition-controlled door locks option, the doors will automatically be locked as soon as the ignition key is turned to the position while the brakes are pressed. When the key is turned to the position, IGNITION ON (RUN) the doors will automatically be unlocked. -
Page 14: Troubleshooting Poor Transmitting Range
Troubleshooting Poor Transmitting Range Many factors may affect the operating range of the transmitter. Some of these are: • The condition of the battery in the transmitter. • The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…) •... -
Page 15: Diagnostics - Parking Light Flash Table
Diagnostics – Parking Light Flash Table Flashes Description • Doors locked, alarm and starter kill armed. • End of run time. • button pressed TRUNK • Start signal received by the system. • Cold weather mode cancelled. • Cannot start after maximum number of attempts is reached. •...
