Smart Parts hammer drill Operating And Maintenance Manual

Paintball marker

Advertisement

Quick Links

Impulse
TM
Operating and Maintenance Manual for:
Impulse
TM
Impulse Vision
TM
Please read all operating instructions before using the Impulse
paintball marker.
TM
100 Station Street • Loyalhanna, PA 15661
Telephone 724.539.2660 • Fax 724.539.2298
www.smartparts.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the hammer drill and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Parts hammer drill

  • Page 1 Impulse Operating and Maintenance Manual for: Impulse Impulse Vision Please read all operating instructions before using the Impulse paintball marker. 100 Station Street • Loyalhanna, PA 15661 Telephone 724.539.2660 • Fax 724.539.2298 www.smartparts.com...
  • Page 2 If you must dry-fire the Impulse, remove the barrel and place a rag over the front portion of the marker where the barrel screws into. This will simulate the paintball and create the required back-pressure to re-cock the marker.
  • Page 3: Electrical Power Supply

    Impulse. To use your Impulse with C02, your bottle will need to have an anti-syphon tube that is correctly fit- ted to the Impulse to prevent liquid C02 from entering the marker. If your C02 bottle does not include an anti-syphon tube or your anti-syphon tube does not correctly position onto the marker, call a certified airsmith to install one into your bottle.
  • Page 4 With the Impulse in Eye-On Mode, it will only fire when a paintball has been detected by the Vision Eye and is in the chamber ready to fire. With the Vision Eye turned off, the Impulse will fire every time the trigger is pulled regardless of the position of the paintball.
  • Page 5 20 shots per second Input Pressure Adjustment The input pressure adjustment is made to the Max-Flo regulator included with the Impulse. The operating pressure should be set between 150-200 psi, depending on the velocity desired. Please read the Max-Flo operating manual included with the Impulse.
  • Page 6 [50] O-Ring (13/70) [414] Bolt Pin [419] Aluminum Bolt [Bolt] [Hammer Assembly] Vision Eye Assembly [660] [737] [763] [655VF] [Vision Eye Assembly] [655UB] [891] [660] Vision Eye Ball Detent [763] Vision Eye Cover [737] Vision Eye Screw [655VF] Eye Flex Circuit [Grip Frame Screw] [655UB] Upper Board [891]...
  • Page 7 [233] O-Ring (09/90) [204] Seat Base [46] O-Ring (10/70) Max-Flo V-Reg Assembled [44] O-Ring (15/70) [397] Locknut GTS [46] Impulse Vertical Nut [536] O-Ring (20/70) [209] Poppet Guide [50] O-Ring (13/70) [231] O-Ring (09/70) [207] Spring Retainer [211] Filter [206] Poppet Spring...
  • Page 8 Lubricating the Bolt To remove the bolt from the Impulse, remove the bolt pin located at the top of the body and slide the bolt out the back of the body. Wipe clean with a paper towel. Apply a generous amount of Dow 33 Shocker lubricant to the bolt.
  • Page 9: Troubleshooting

    - Verify that the bolt pin is correctly inserted through the bolt and into the bolt actuator. - Verify that bolt is inserted correctly, with the air input facing down. - Reset dwell to zero and readjust to desired velocity. (See page 5 for resetting the Impulse Operating Pressures) - Verify that solenoid is correctly plugged into the circuit board.
  • Page 10: Technical Support

    - Check that both ball detents are clean and properly holding paintball in breech. - Verify that the Impulse is in Eye-On Mode and that the Vision Eye is correctly detecting the paintball. (See page 4 for LED Display Modes) - Decrease input pressure from air source.
  • Page 11 100 Station Street • Loyalhanna, PA 15661 Telephone 724.539.2660 • Fax 724.539.2298 www.smartparts.com...

This manual is also suitable for:

ImpulseImpulse vision
