Projector and Telescope
Instructions
Model Number: 73889
Please save these instructions for future reference.
Adult assembly is required.
Requires four "C" (LR14) alkaline batteries
for operation (not included).
Requires one KPR113 Krypton light bulb (included).
Adult assembly required for battery installation
and light bulb replacement.
Tool required for battery installation and light bulb replacement:
Phillips screwdriver (not included).
Advertisement
Table of Contents
Related Manuals for Fisher View-Master 73889
Summary of Contents for Fisher View-Master 73889
- Page 1 Projector and Telescope Instructions Model Number: 73889 Please save these instructions for future reference. Adult assembly is required. Requires four “C” (LR14) alkaline batteries for operation (not included). Requires one KPR113 Krypton light bulb (included). Adult assembly required for battery installation and light bulb replacement.
-
Page 2: Battery Installation
Battery Installation 1.5V x4 “C” (LR14) Shown Actual Size • Loosen the screw in the battery compartment door with a Phillips screwdriver. • Lift the battery compartment door to open. (The screw will remain in the door.) • Insert four “C” (LR14) alkaline batteries as indicated inside the battery compartment. - Page 3 Assembly Hole Threaded Bar Plastic Screw Tripod • Place the projector/telescope upside-down on a flat surface. • Position the tripod with the rib side facing down. • Insert the tripod into the center slot on the projector/telescope. • Align the holes in the projector/telescope with the hole in the tripod.
-
Page 4: Using The Telescope
Using the Telescope WARNING Never point the telescope at or near the sun. Viewing the sun can cause instant, permanent eye damage. Cushioned Eyepiece Telescope Focus Knob Angle Adjustment Knob Tripod Helpful Hints: This product has been designed for use with children. We do, however, recommend that you help them set up the product for telescope or projector use and teach them how... - Page 5 Telescope Tips STOP Actual Image Image Viewed Through Telescope • This telescope has a magnification power of 17.5X. This means that objects seen through the telescope look 17.5 times larger than with the eyes alone. • This telescope is a refracting telescope. When you look at an object with this telescope, the object will appear backwards.
-
Page 6: Using The Projector
Using the Projector Slot Advance Lever Reel Storage Compartment Projector Focus Knob On/Off Switch Tripod On/Off Switch Note: You can use the projector to send bright, clear images from any View-Master ® reel onto walls, ceilings or just about anywhere. •... - Page 7 Advance Lever Projector Focus Knob • To focus the image: Adjust the Advance projector focus knob until the Lever image is clear. Projector Focus Knob • To see the next picture: Press the advance lever. Helpful Hint: Since you cannot rewind to a favorite picture, continue to press the advance lever to find a desired picture.
- Page 8 Projector Tips • For the steadiest picture show, place the projector on a hard, flat surface. • Make sure the play area is completely dark for maximum picture clarity. • To turn the projector into a telescope, simply remove the reel and turn the projector off.
- Page 9 Light Bulb (Glass Bulb) Replacement IMPORTANT! Should the light bulb become non-functional, you are advised to remove or replace it. This should be carried out away from the child’s play area. Notch Light Bulb Keyhole Compartment Door Screw • Using a Phillips screw- driver, turn the keyhole clockwise.
-
Page 10: Care And Cleaning
Advisory Service 1-800-800-812 (valid only in Australia). Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. MADE IN CHINA. REELS MADE IN U.S.A. OF SOME IMPORTED MATERIALS. Manufactured for Fisher-Price. ©2000 Mattel, Inc. All Rights Reserved. View-Master ®...
