- Page 1 D V D P l a y e r MD 42072 Instruction manual Kodak DOLBY – – P H OTO D I G I T A L MD 42072 MSN 5001 4410...
-
Page 2: Table Of Contents
Content Introduction • Safety Precautions..................2 • Important Safety Instructions ................3 • Features......................5 • Front Panel and Rear Panel Illustration ............6 • Remote Control....................7 Connections • Connecting to a TV set ...................8 • Connecting to an AV Receiver with 2 Channel Analog Audio Input ....9 •... -
Page 3: Introduction
Safety Precautions Introduction CAUTION: CAUTION THE UNIT EMPLOYS A LASER SYSTEM. TO EN-SURE THE PROPER USE OF THE UNIT, Risk of electric shock Do not open READ THIS MANUAL CAREFULLY AND KEEP IT FOR FUTURE REFERENCE. CAUTION IF THE UNIT REQUIRES SERVICING, RISK OF ELECTRIC SHOCK CONTACT THE SELLER OR SEE DO NOT OPEN... -
Page 4: Important Safety Instructions
Important Safety Instructions Introduction 1. Read Instructions 9. Power Sources All the safety and operating instructions should This product should be operated only from the be read before the product is operated. type of power source indicated on the marking label. - Page 5 Important Safety Instructions Introduction 11. Object and Liquid Entry Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
-
Page 6: Features
Features Introduction Disc formats supported by this player: Dolby Digital DOLBY Multi-angle D I G I T A L KODAK picture CDs Kodak Closed Caption Picture CD COMPATIBLE MP3 files on Subtitle choices CD-R/CD-RW DVD video Audio choices V I D E O Parental Lock 16:9 TV Aspect Ratio... -
Page 8: Remote Control
Remote control Introduction A-B REPEAT MUTE POWER PROG TIME AUDIO STEP SUBTITLE 0-9 NUMBER KEY ZOOM 10+ KEY REPEAT RETURN VOL+ MARK MENU ANGLE VOL- SETUP LEFT ENTER RIGHT STOP PLAY DOWN PAUSE PREV TITLE NEXT SEARCH QUICKLY FORWARD CLEAR SEARCH QUICKLY BACKWARD OPEN/CLOSE SLOW... -
Page 9: Connections
Connecting to a TV Set Connections Connections 230V 50H Z VIDEO IN VIDEO Connect either the Scart cable or the Cinch cable. -
Page 10: Connecting To An Av Receiver With 2 Channel Analog Audio Input
Connecting to an AV Amplifier with 2 Channel Analog Audio Input Connections 230V 50Hz YELLOW WHITE VIDEO Amplifier V O L U M E D O W N B A S S M I C E C H O DVD IN Notes: 1. -
Page 11: Connecting To An Av Receiver With Digital Audio Input
Connecting to an AV Amplifier with Digital Audio Input Connections 230V 50Hz Notes: 1. Select the Coaxial digital audio output. 2. Set the player's audio out to Raw or PCM mode . 3. Set the Amplifier to the AV input. -
Page 13: Advanced Features
Modes and Features Setup Advanced Features In stop mode, press SETUP, and the TV screen will display the Setup Menu as follows: Press to change items Setup Menü A. Press ENTER to display each submenu B. Press SETUP to exit the Setup Menu Language Setup Select [Language] in the Setup Menu, and press ENTER to display the [Language] submenu: Press... -
Page 14: Language Setup
Modes and Features Setup Advanced Features Language Setup Select [Subtitle], and press ENTER or to display the [Subtitle] submenu: Press to change your selection Note: Subtitle languages vary by disc. A. Press ENTER to confirm B. Press SETUP to exit the Setup Menu Select [Audio],and press ENTER or to display the [Audio] submenu:... -
Page 15: Video Setup
Modes and Features Setup Advanced Features Video Setup Select [Video] in the Setup Menu,and press ENTER to display the [Video] submenu: Press to select the menu item A. Pre ss ENTER or to set B. Press to return to the Setup Menu Select [TV shape], and press ENTER or to display the [TV shape] submenu: Press... -
Page 16: Audio Setup
Modes and Features Setup Advanced Features Select [Video Output], and press ENTER or to display the [Video Out] submenu: A . Press ENTER to confirm B. Press SETUP to exit the Setup Menu Press to change your selection Audio Setup The Audio menu allows you to set the analog and digital audio outputs to correspond with the external components you have connected to the player. - Page 17 Modes and Features Setup Advanced Features System Setup 1:K id Sa fe 3:P G I The system menu allows you to block playback of 4:P G- 13 5:P G- R DVDs based on their ratings. 7:N C - 17 8:A du lt Setting the Password &...
-
Page 18: Remote Control Operation
Remote Control Operation Advanced Features • During playback, press STANDBY to stop the player and return to standby mode. • While the player is in standby, press STANDBY • To open the disc tray, press OPEN/CLOSE. • To close the disc tray, press OPEN/CLOSE again. •... - Page 19 Remote Control Operation Advanced Features During playback, press OSD to display the current time counter position. Elapsed time of the current track/chapter Elapsed time of the current track Press OSD again to display additional information about the playing disc. Elapsed time of the current track Disc type Total tracks Current track...
- Page 20 Remote Control Operation Advanced Features During playback, press TIME, and the [Track Search] menu will display as follows: Notes: 1. Time searches for an exact time in the movie 2. In Title/Chapter mode, you cannot SELECT a value outside the range of the total number of titles or chapters 3.
- Page 21 Remote Control Operation Advanced Features • During DVD or CD playback, press once >> to play the next chapter, title or track. • During DVD or CD playback, press >> and hold to scan forward. The player will review the disc at 2, 4, 8 and 20 times normal speed as follows: •...
- Page 22 Remote Control Operation Advanced Features • Press PLAY from stop mode to start playback. • Press PLAY during playback to replay the last 10 seconds. This function is not available if the elapsed time of current track is less than 10 seconds Note: MP3 discs and some DVD discs do not have a 10 second review feature.
- Page 23 Remote Control Operation Advanced Features While [PROGRAM] is on, press ENTER to display the [Program] submenu: Input the track numbers in the order you would like them to play. When finished, select [Play Program] and then press ENTER to play the tracks in the new programmed order.
- Page 24 Remote Control Operation Advanced Features • Press SLOW repeatedly to slow motion playback at variable speeds. • Press STEP during playback to pause playback. • Press STEP repeatedly to play frame. • Press PLAY to resume normal playback. • During the playback of medion, without DVD´s •...
- Page 25 Remote Control Operation Advanced Features • Press VOL+, to increas the loudness. • Press VOL-, to decreas the loudness.. • Press MUTE to mute the Audio output • Press MUTE again to resume normal audio output During DVD playback, press ZOOM to magnify the image as ZOOM Press during the playback ZOOM, to change the size of ? During DVD playback, press...
- Page 26 Remote Control Operation Advanced Features During DVD playback • Press ANGLE to view scenes from different camera angles. • Press ANGLE repeatedly to change from one camera angle to another. Note: This function is disc specific. Audio During DVD playback •...
-
Page 27: Mp3 Playback
MP3 Playback Advanced Features Supported formats: • Disc format: ISO 9660, Joliet • Music file format: MP3 • MP3 bit rate (data rate): 32 -192 kbps • Total number of music files and albums: around 350 per disc. • Sampling rate: (CBR)32kHz/44. 1kHz/48kHz/64kHz; (VBR) 16kHz/22kHz/24kHz/32kHz (MPEG ) Note: The player will not identify or play MP3 discs under the following conditions:... -
Page 28: Kodak Picture Cd Playback
Kodak Picture CD Playback Advanced Features The introduction of KODAK Picture CD A Kodak Picture CD has the size and shape of a regular CD. You can order a KODAK Picture CD simply by checking the box on the photo finishing envelope when you drop off a roll of film (35 mm or Advanced Photo System (APS) color print film) at the time of processingin Kodak Express store displaying "Kodak Picture CD"... -
Page 29: Others
Troubleshooting Others If you have any questions, please consult the troubleshooting guide below. NO PICTURE OR SOUND • Ensure the disc format is compatible with the player. • Ensure the power button is on. • Please check whether you have tried to play •... -
Page 30: Insert Batteries
Remote Control Operation Extra Insert batteries Using the remote control Point the remote control at the remote sensor. 1. Open the cover (The pictures below are for reference only.) DVD/SVCD/VCD/CD/CD-R/CD-RW MP3 PLAYER POWER OPEN/CLOSE PLAY STOP 2. Insert batteries Make sure to match the "+" and "-" of the batteries with the marks inside the battery compartment 3. -
Page 31: Specifications
Specifications Others Type ...............DVD PLAYER Model .............MD 42068 Video standard..........NTSC/PAL/AUTO Compatible Discs DVD+R/RW, DVD-R/RW, CD-R/RW, MP3-CD, JPEG, VCD, SVCD D/A converter ..........96KHz/24bit Digital audio output ........coaxial Power requirements........AC 230V ~ 50Hz Power consumption ........25 W Specifications are subject to change without notice. -
Page 32: Enter
MTC Medion Technologie Center Medion Electronics Ltd. Freiherr-vom-Stein-Str. 131 120 Faraday Park D-45473 Mülheim / Ruhr Faraday Road Dorcan Tel. 01805 / 633 633 • Fax 01805 /566 566 Swindon SN3 5JF (0,12 Euro/Minute innerhalb des Festnetzes ) Wilts ce-support@medion.com Hot-Line: 0870 727 03 70 http://www.medion.com Fax: 017 93 71 57 16...
