Dynavector SSP-5 Operation Manual

Superstereo processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Dynavector SuperStereo Processor
SSP-5
Operation Manual
Introduction ............................................................ 2
Speaker Locations ................................................ 3
Connection Method A ............................................ 5
Connection Method B ............................................. 6
Front Panel Controls ............................................... 7
Rear Panel Controls ............................................... 8
Operation --- Sound Reproduction ......................... 11
Specifications ......................................................... 12
16-15 Iwamoto-cho 2-chome Chiyoda-ku
Tokyo 101-0032 Japan
Phone 813-3861-4341 Fax 813-3862-1650
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSP-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dynavector SSP-5

  • Page 1: Table Of Contents

    Dynavector SuperStereo Processor SSP-5 Operation Manual Introduction ............2 Speaker Locations ..........3 Recommended speakers for SuperStereo ..... 4 Connection Method A ..........5 Connection Method B ..........6 Front Panel Controls ..........7 Rear Panel Controls ..........8 Preset Controls for Adjusting the Input Level ..9 Adjusting the Sound Balance Between Speakers ..

  • Page 2: Introduction

    While the addition of 2 extra centre speakers using the Adp-2 SuperStereo processor with a conventional stereo system will produce highly enjoyable and musical results, the use of the SSP-5 processor together with the Adp-2 and a total of 4 sub speakers to give 6 speaker SuperStereo will further significantly enhance the naturalness and immediacy of the sound.

  • Page 3: Speaker Locations

    Speaker Locations We recommend two alternative speaker locations. You should choose the one best suited to the size and type of your listening room. Position (A) Normal Location Position (B) Compact Location Locate each speaker as shown in the drawing at (A) Locate each speaker as shown in the drawing at (B) Side speakers should be located between 1.5 and 2.5 The side and rear speakers are located in the same po-...

  • Page 4: Recommended Speakers For Superstereo

    Recommended speakers for SuperStereo We recommend small sub speakers for SuperStereo since they are quite capable of bringing out the ambience of even a large concert hall. Recommeded speakers Front speakers:use existing speakers Side speakers:use small speakers (5 – 10 cm driver unit) Rear speakers:use small speakers (10- 13cm driver unit) NOTE 1.When you use large speakers for the side and the rear the sound will tend to be boomy and lack definition.

  • Page 5: Connection Method A

    Connection Method A Normal connection / using SSP-5 + SS-Adp2 + 4 channels of power amplification. We recommend this set-up for normal home use. You will need 2 extra stereo power amplifiers (or a 4-channel amplifier), the side speakers being driven by the Adp2...

  • Page 6: Connection Method B

    Connection Method B Connection Method B is using SSP-5 + SS-Adp2 + 6 channels of power amplifica- tion. Should you wish to have high sound levels, you will need to have available also an extra stereo power amplifier for the side speakers. A multi-channel amplifier...

  • Page 7: Front Panel Controls

    (8) and (9). (3) INPUTS The two inputs ( A and B) are selectable.Thus you can connect two sources to the SSP-5 (eg a pre-am- Remote Control Unit plifier and a CD player). (1) MUTE key...

  • Page 8: Rear Panel Controls

    FRONT MAIN position, the output will be the signal entering into INPUT A or B. When the switch When the overflow indicator on front panel of SSP-5 for FRONT MAIN/CENTER AUX IN is set to the CEN- lights up or blinks, you should select the HIGH position.

  • Page 9: Preset Controls For Adjusting The Input Level

    6. The volume control of the pre-amplifier should be turned up to gradually until just before the overflow indicator on the front panel of SSP-5 starts to blink. 6. When the indicator blinks at frequent intervals you The volume control of the pre-amplifier should be should select HIGH position of the INPUT LEVEL set at this position.

  • Page 10: Adjusting The Sound Balance Between Speakers

    SSP-5. speakers will be reduced. 10. The FRONT MAIN/CENTER LEVEL control of SSP-5 should be turned to the right gradually to the 5. The FRONT MAIN/CENTER LEVEL control of point which gives the best and most natural sound SSP-5 should be turned to minimum. The sound reproduction.

  • Page 11: Operation

    Operation --- Sound Reproduction Once you set the input level of SSP-5 and the sound volume of each pair of speakers, you can operate SSP-5 most easily by using the unit’s remote control. MUTING the sound 1. Play some music on a CD player or other source.

  • Page 12: Specifications

    Specifications Type Reverberation Analogue/digital SuperStereo processor SuperStereo analogue/digital feedback gain Input impedance Low pass filter 50Kohms <REAR low pass filter fc=2,000Hz, -12dB/oct> (INPUT A,B, AUX IN FRONT, REAR, CENTER) Power supply voltage Input voltages AC 100/110 volts or INPUT A, B HIGH 2.5 volts AC 220 –...
