Cadi .Sense User Manual

Wireless thermometer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Cadi.Sense
Wireless Thermometer
User Manual
v3.21.3
T-S1-800.900-I10-C01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cadi.Sense and is the answer not in the manual?

Questions and answers

Related Manuals for Cadi Cadi.Sense

Summary of Contents for Cadi Cadi.Sense

  • Page 1 Cadi.Sense Wireless Thermometer User Manual v3.21.3 T-S1-800.900-I10-C01...

  • Page 2: Table Of Contents

    Overview..........................6 Setup I – Performing a quick setup................. 6 Setup II – Setting up to access Cadi.Sense from outside your home ....... 7 Setup III (Advanced) – Performing port forwarding to access your SmartNode from outside your home ....................9 Using your iPhone or Android app to access Cadi.Sense ........

  • Page 3: Introduction

    To view the latest user manual, go to www.cadisense.com. Important safety information  DO NOT use the Cadi.Sense or any electrical part that comes with the package if there is any visible damage.  DO NOT force open or attempt to service the Cadi.Sense or any electrical part that comes with the package.

  • Page 4: Intended Use

    Cadi.Sense User Manual Intended use The Cadi.Sense wireless thermometer is intended for use in children for monitoring body temperature continuously and automatically. Package contents  ThermoSensor (with storage case)  SmartNode (plug) T-S1-800.900-I10-C01...

  • Page 5: How Does The Cadi.sense Work

    It is recommended that you determine your child’s normal temperature when measured using the Cadi.Sense, by carrying out the measurement for at least 24 hours when the child is healthy. As a reference, a Cadi.Sense temperature above 37.8°C may suggest that your child has a fever.

  • Page 6: How To Set Up And Use The Cadi.sense

    1. Set up the system for wireless access, by following the instructions in Sections 2.2, 2.3, 2.4, and 2.5. 2. Understand the LED indicators and Cadi.Sense icons, by reading Sections 2.6 and 2.7 respectively. 3. Know how to attach the ThermoSensor to the patient, by following the instructions in Section 2.8.

  • Page 7: Setup Ii - Setting Up To Access Cadi.sense From Outside Your Home

    “Home page” icon Figure 3 will appear. Setup II – Setting up to access Cadi.Sense from outside your home This setup enables you to connect your mobile device to the Internet, so that you can access temperature readings from outside your home via the Internet.
  • Page 8 Cadi.Sense from anywhere in the world! Go to “www.cadisense.com”, and then click “Access Cadi.Sense”. Type in your SmartNode ID (which can be found on your SmartNode; you should have written it in Step 1 of Section 2.2). The password is “cadi”, and the default port is “50000”. Then click “Login”.

  • Page 9: Setup Iii (Advanced) - Performing Port Forwarding To Access Your Smartnode From Outside Your Home

    Cadi.Sense User Manual Figure 7. Cadi.Sense page without UPnP/port forwarding setup. Figure 8. Cadi.Sense page with UPnP/port forwarding setup. Setup III (Advanced) – Performing port forwarding to access your SmartNode from outside your home This setup enables you to view your SmartNode webpages from outside your home via the Internet.

  • Page 10: Using Your Iphone Or Android App To Access Cadi.sense

    In addition, it also allows wireless monitoring of your children’s temperature anytime, anywhere. Step 1: After installing and setting up the Cadi.Sense app, click “+” on the home tab and enter the necessary information to create a new profile for your child. T-S1-800.900-I10-C01...

  • Page 11: Understanding The Smartnode Leds

    User Manual Step 2: On the home tab, select your child, click another “+” sign, and select “Cadi.Sense Monitoring”. Type in some notes in the Description field for your own reference and also type in your 8-digit sensor ID (serial number) in the Sensor field (the sensor ID can be found on the ThermoSensor).

  • Page 12: Understanding The Cadi.sense Icons On Your Smartnode Webpages

    Cadi.Sense User Manual Understanding the Cadi.Sense icons on your SmartNode webpages Go to home page (temperature monitoring page): View a single sensor temperature in large font size. Refresh: Manually refresh the current page to get the latest temperature. The page will actually refresh automatically every 5 minutes.
  • Page 13 Cadi.Sense User Manual Click these icons and you will see the following screens: Main page Home page Advanced settings menu (sensor details) (temperature monitoring) Setting date, time, and Add sensor Remove sensor timezone (by entering sensor ID) (by clicking inside the red box)

  • Page 14: How To Attach The Thermosensor

    Cadi.Sense User Manual Temperature chart Temperature history Sensor settings (name, alert, °C or °F, temperature threshold) How to attach the ThermoSensor Step 1: Apply a small amount of body lotion on the left or right side of the lower abdomen.
  • Page 15 Cadi.Sense User Manual Step 4: Remove the rectangular backing liner to expose the adhesive. Step 5: Stick the exposed adhesive to the inside of the diaper/undergarment in such a position that the sensor's metal part will touch the lower abdomen (left or right) when the diaper/undergarment is properly worn.

  • Page 16: How To Clean And Store The Thermosensor And The Smartnode

    Cadi.Sense User Manual The ThermoSensor may take about 30 minutes to warm up from room temperature to body temperature. A temperature reading is sent wirelessly every 30 seconds to your SmartNode, and this reading will be converted into an equivalent body temperature, which will appear on your mobile device or computer.

  • Page 17: Advanced Features

    Cadi.Sense User Manual Step 3: Clean the SmartNode with a soft cloth moistened with alcohol. Step 4: Place both the SmartNode and the ThermoSensor with its storage case in the original package, and store the package in a cool, dry place and keep it out of reach of babies and young children.

  • Page 18: Resetting The Smartnode

    SmartNode, so it is advisable to keep this page open. Step 2: Connect your laptop to the SmartNode physically using a LAN cable, which is provided in your Cadi.Sense package. Step 3: Go to your laptop’s web browser and enter “http://10.10.10.10/main.asp”. Click the “Device Settings”...

  • Page 19: Others

    Cadi.Sense User Manual Step 4: Reset the SmartNode (this is important!), by following the instructions in Section 3.2 or those on the webpage from which you downloaded the firmware. Step 5: Reboot the SmartNode by switching it off and on again. The reboot will take about 1 minute.

  • Page 20: Getting Technical Support

    Click the “Refresh” icon, and check the “Last Refreshed Time” to ensure that the Cadi.Sense web page has really been refreshed. Note that both the times, stated below the temperature and last refreshed time, are based on our server time. Two dashes for temperature reading means that no readings have been recorded for the past 30 minutes.

  • Page 21: Specifications

    Cadi.Sense User Manual Medical Device Safety Service GmbH EC REP Schiffgraben 41 30175 Hannover, Germany CADI SCENTIFIC PTE LTD Complies with 31 Ubi Road 1 IDA Standards #03-00 Aztech Building DB 10249 Singapore 408694 www.cadi.com.sg Note: The stick-on dressing is supplied by Shanghai Huyou Medical Electrode Ltd, 45 Lane 1398, Zhenchen Road, Baoshan, 200435 Shanghai, China.
  • Page 22 Cadi.Sense User Manual SmartNode specifications Radio Radio frequency (short range device) 868.4 MHz , 919.8 MHz, or 925 MHz, depending on countries WLAN WiFi 802.11b/g/n Interface Ethernet 1 x 10/100 Auto MDI/MDIX Ethernet Port Power Input voltage 100–240 VAC, 50–60 Hz Maximum current: 0.12 A...

  • Page 23: More About Port Forwarding

    Cadi.Sense User Manual More about port forwarding Port forwarding screens for the following WiFi routers are shown below: 1. Aztech DSL1015EW(S) or DSL1000ER 2. 2WIRE 5012NV T-S1-800.900-I10-C01...
  • Page 24 Cadi.Sense User Manual 3. 2WIRE 2701HGV-E 4. Linksys E2000 T-S1-800.900-I10-C01...
  • Page 25 Cadi.Sense User Manual 5. Dlink DIR 655 6. ZyXel T-S1-800.900-I10-C01...
  • Page 26 Cadi.Sense User Manual 7. ASUS-RTN16 8. EnGenius ESR9850 T-S1-800.900-I10-C01...

  • Page 27: More About The Smartnode

    Cadi.Sense User Manual More about the SmartNode The SmartNode supports wireless 802.11b/g/n standards with one 10/100Base-T Ethernet port. It is designed with MIMO technology to extend the reach of any existing wireless router/AP to maximize the coverage in your home or office. It basically receives the signal from your wireless router/AP and repeats it to extend the range to farther locations that are previously unreachable.
  • Page 28 Cadi.Sense User Manual  Click the “Connect to WiFi Router” icon. When a screen appears and asks “Please select your WiFi router”, click your router’s SSID, type in your router’s password, and then click “Apply”. Be patient as the SmartNode needs about 1 minute to connect to your WiFi router and about one minute to reboot.
  • Page 29 Cadi.Sense User Manual To configure the SmartNode for use as a WiFi AP:  Plug in the SmartNode to a power socket and switch it on. (Note: The SmartNode takes about 30 seconds to start up.)  Connect the SmartNode to your modem-router using an Ethernet cable.
  • Page 30 Cadi.Sense User Manual T-S1-800.900-I10-C01...
  • Page 31 Cadi.Sense User Manual Using WPS (WiFi Protected Setup) WPS is an alternative and easier way to connect the SmartNode to your WiFi router or a wireless client. To connect the SmartNode to your WiFi router/AP via WPS:  Press the WPS button on the SmartNode for 5 seconds to activate WPS Enrollee mode.
  • Page 32 Cadi.Sense User Manual Reboot Reboot allows you to reboot the device for new settings to take effect. Device settings Device Settings includes the following options:  Device information  IP address (LAN configuration)  Settings backup (configuration settings) T-S1-800.900-I10-C01...
  • Page 33 Cadi.Sense User Manual  Firmware upgrade  Password (system password) Device information This page shows the device information. Below is the list of information shown in this menu. Firmware Version – Shows the current firmware version of the device Build Date –...
  • Page 34 Cadi.Sense User Manual Settings backup (configuration settings) This page allows you to back up and restore the current device configuration, as well as to reset the device to its factory default settings. Backup – To back up the current configuration of the device to a file Update –...
  • Page 35 Cadi.Sense User Manual Password (system password) The password menu allows you to change the device’s password to access SmartNode webpages. Setting a static IP on your PC The SmartNode will only give an IP address to your PC upon initial installation. Once you have associated the SmartNode with your WiFi router/AP, you may no longer have access to the device’s webpages.
  • Page 36 Cadi.Sense User Manual  Click to select Internet Protocol Version 4 (TCP/Ipv4) (“TCP/IP” for Windows XP), and then click “Properties”.  Select “Use the following IP address:” and type in “10.10.10.20” as the IP address and “255.255.255.0” for the subnet mask. Leave the other fields blank.
