PORTABLE GAS-POWERED
OWNER'S
EARTH
Earth, Ice and Wood
the little
DRILL
FITS ALL
CHAIN
SAWS
MANUAL
ALSO CONTAINS:
LEWIS MULTI-DRILL Parts Lists
LEWIS MULTI-DRILL Accessories
LEWIS EARTH AUGERS
LEWIS ICE AUGERS
ICE
drill
DRILL
WOOD
that could
Build wood and metal fences
u
u
Plant trees and shrubs
u
Go ice fishing
Build log cabins
u
u
Drill boom logs
u
Drill railway ties
Advertisement
Summary of Contents for Lewis DH3-WD
- Page 1 PORTABLE GAS-POWERED DRILL OWNER’S MANUAL ALSO CONTAINS: LEWIS MULTI-DRILL Parts Lists LEWIS MULTI-DRILL Accessories LEWIS EARTH AUGERS LEWIS ICE AUGERS EARTH WOOD Earth, Ice and Wood the little drill that could Build wood and metal fences DRILL Plant trees and shrubs...
- Page 2 Maximum chainsaw size is 100cc’s or 7 horsepower. Electric chainsaws and smaller gas chainsaws will give satisfactory performances with lighter loads only. If you have purchased a model DH3-WD Direct Drive version, then your saw must have an accessible outboard sprocket. Most modern saws are built this way. If you...
-
Page 3: Operating Tips
Do not take chances with your safety!!! W A R R A N T Y If your LEWIS MULTI-DRILL fails to operate properly due to a manufacturing defect within 1 year of purchase, please return it freight pre-paid with a copy of your receipt. -
Page 4: Direct Drive
Assembly & Mounting Instructions STEP 1 for DH3-WD Direct Drive 1.Remove bar and chain from your chainsaw, retain bar-mounting nuts. 2. Remove the spring clip from your saw’s output shaft, then remove the large washer and drive sprocket. Re-install spring clip but not large washer or sprocket. - Page 5 If the cutter-less chain is too long, then grind off rivets to remove links as necessary. Lewis 5. Slide supplied chain guard over Multi-Drill studs and secure with 2 flat washers and nuts, as well as 1 bolt and washer on round end.
- Page 6 Assembly & Mounting Instructions STEP 2 for DH3-WD Direct Drive for DH3-WU Universal Drive 1. Install handle: Remove the three 3/8” bolts from the top of the Lewis Multi- Drill. Keep unit upright as oil will leak out. Position handle where desired and replace bolts.
- Page 7 Lewis Multi-Drill Parts List...
- Page 8 Lewis Multi-Drill Direct Drive Parts Lewis Multi-Drill Direct Drive...
- Page 9 Lewis Multi-Drill Universal Drive Parts Lewis Multi-Drill Universal Drive...
- Page 10 Lewis Earth Augers Length 38 inch / 97 cm Flute 1/8 inch fully welded steel Replaceable Alloy Tips Shaft 1 3/8 inch diam. steel shaft Drive Hub 1” ID Built to last a lifetime! WEIGHT: 12 lbs. / 5.5 Kg...
- Page 11 Lewis Augers Length 38 inch / 97 cm Flute 1/16 inch fully welded steel Replaceable Alloy Cutters Shaft 1 3/8 inch diam. steel shaft Drive Hub 1” ID Built to last a lifetime! WEIGHT: 10 lbs. / 4.5 Kg is perfect for thick ice (2-3 feet and more!) conditions where target fish species are small.
- Page 12 Accessories Lewis Drive Extensions allow you to drill a deeper hole with an auger by extending its shaft length and they are available in 2 sizes - the 12 inch and the16 inch - c/w 1 inch drive hub and MDP01 retainer pin.
