Summary of Contents for Etec MP691
- Page 1 MP3 Digital Audio Player MP691 &MP692 User Manual...
-
Page 2: General Description Of Functions
General Description of Functions •USB 2.0 •Supports multiple audio formats MP3, WMA, WAV •No Driver Installation necessary for WINDOWS: 2000, XP, or Newer. •Voice Recorder •7-Band EQ Natural, Rock, Pop, Soft, Classic, Jazz and Bass •Color Backlit Display •Multiple play modes Normal, repeat- one, repeat-all, random play, and browse play modes •Automatic OFF •Fast forward and reverse... -
Page 3: Lcd Screen
STATEMENT Thank you for purchasing this digital MP3 player. Prior to using the product, please read the operation manual for the best use of the player. The contents of the manual may be modified from time to time. No prior notice will be given when there are any changes to the performance or functions of the product. - Page 4 Display screen BIT RATE TRACK TIME BATTERY POWER METER FILE FORMAT TRACK NUMBER SONG TITLE Battery indicator Displays the battery charging status. When the battery is fully charged, it will be displayed as on the picture (blue square). When the battery is low, the square will become empty. Key operation •...
- Page 5 Press and hold “► ” button to turn the MP3 player on. While the MP3 is playing, press and hold the “► ” to turn the MP3 player off. • Play/Pause In the Music mode, press the “► ” button to playback the music. •...
- Page 6 Press: Press the button then release it immediately. Long time press: Press and hold the button for about 2 seconds, then release it. Press and hold: Press and keep holding the button. • Music playback Please, follow the steps below Connect your earphone to the earphone jack of the MP3 player.
-
Page 7: Basic Function
Then the song text file should be Big Big World.lrc How to make sure the MP3 player has recognized the .LRC file with the song text? The MP3 player will recognize the .LRC file with the song text by self-reacting when the .LRC has the same file name as the song. Then long time press “Menu”... - Page 8 Record mode: Play mode: System setting: Connecting PC to enter USB mode: The digit here means the total capacity of the disk, with the percentage representing the occupied space ratio. Volume adjustment...
-
Page 9: Play Music
Press “VOL”, then press”NEXT/ ” to increase the volume. then press ”PRE/ ” to decrease the volume. Power ON/OFF At power off status, short press Play key to turn on the power. It will display logo At power on status, long press Play key to turn off the power. Play or stop (under record mode, with pause function）... -
Page 10: Voice Record
How to use lyric files? Keep the name of lyric file same as that of the track file. For example: The name of track files is Yesterday.mp3 The name of lyric files is Yesterday.lrc Voice record It is recommended to have enough battery capacity to carry out recording operation. The player supports storage of multiple record files under each folder. -
Page 11: System Setting
Short press Mode key to enter the play mode interface. Press again Play key to start play. Select the record file. Last key: select the last record file Next key: select the next record file Volume adjust Press “VOL”, then press ”NEXT/ ” to increase the volume. then press ”PRE/ ”... - Page 12 “EQ mode” Setting “Repeat” Setting Memory information: “Language” Setting “Backlight time” setting...
- Page 13 “Power off” Setting “Backlight mode” setting The operation method is referred to “EQ mode” setting (mode 0-6 is mono-color, & mode 7 changes to 7-color setting) “Language select” setting The operation method is referred to “EQ mode” setting. Enter the Language interface first. “Play mode”...
-
Page 14: Troubleshooting
appear in the resource manager of WINDOWS. In this case, it is available for you to use MP3 player as a common disk as shown in the picture below: Trouble Shooting: Problem Solution No power Check if the battery is installed correctly. Check if the power is ON. - Page 15 Technical parameters Items Parameters Music format MP3, WMA，WAV Bit rate 56Kbps～256Kbps Frequency range 20Hz～20KHz ≥86DB Signal/noise ratio ≥85DB (1KHZ referenced signal) Separation ≤3DB (20HZ~20KHZ) Frequency response Output power of the earphone L 4mW, R 4mW EQ mode Normal, POP, Jazz, Rock, Classic, Bass,Soft Display Type of port 2.0，Compatible with USB1.1...
-
Page 16: Limited 90-Day Warranty
During the initial 90 day period after original purchase, we will service or exchange, at no charge. To obtain warranty service or replacement within the duration of the 90-day warranty, return the product freight prepaid to the address below. eTEC USA 823 Old Settlers Trail Suite 100... - Page 17 Under no circumstances shall eTEC USA, be liable for any loss (direct, indirect, incidental, foreseen, unforeseen, special or consequential) or for any damage arising out of, or in connection with, the use of this product.
