Mentor radio M15 Owner's Manual

Solid-state vhf aeronautical band radio receiver/transmitter (118.000-136.975 mhz)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Solutions for Advancing Communications
M15- OWNER'S MANUAL
M15
Solid-State VHF Aeronautical Band
Radio Receiver/Transmitter
Mobile Transceiver
(118.000-136.975 MHz)
www.mentorradio.com
Phone: 216-265-2315 * Fax: 216-267-2915
M15-OM-11/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mentor radio M15

  • Page 1 Solutions for Advancing Communications M15- OWNER’S MANUAL Solid-State VHF Aeronautical Band Radio Receiver/Transmitter Mobile Transceiver (118.000-136.975 MHz) www.mentorradio.com Phone: 216-265-2315 * Fax: 216-267-2915 M15-OM-11/11...

  • Page 2: Circuit Description

    INTRODUCTION The Mentor Model M15 receives and transmits on up to six discrete channels in the vhf aviation band between 118 and 137 MHz (25 KHz channel spacing). It operates from a 14 v dc supply, and is intended for both vehicular and airborne application as well, and can also be used as a base station.

  • Page 3: Installation

    INSTALLATION The M15-25 can either simply rest on a shelf or desk, or it may be mounted in a 19 inch relay rack. When rack mounted, rear support is not required. This unit does not contain a cooling fan, and does not normally need one.

  • Page 4: Operation

    (fully CCW, without turning radio off). It is not necessary to turn off the M15 if the M15-25 is turned off—the power to the M15 is removed when the front panel rocker switch is turned off (green LED goes off). If the M15 has more than one frequency, select the desired channel.

  • Page 5: Remote Operation

    It’s level is factory adjusted to 0 dBm (0.77 v rms) but may be adjusted internally for any level from -7 to +10 dBm by trimmer potentiometer R205 on the printed circuit board inside the M15-25. Both the 4 ohm and the 500/600 ohm receiver audio outputs are unaffected by the volume control on the M15, the latter affecting only the speaker on the front panel of the M15-25.

  • Page 6: Maintenance

    With each new M15, Mentor Radio, LLC. include instructions on how to complete form 406 online at the FCC Internet web site (Dwg. 1100958). If the M15-25 is to be used on a channel in the frequency range 128 to 132 Mhz (the “enroute” channels), the license application is handled differently.
  • Page 8 In the past, Mentor Radio provided information required by Form 406 for its specific models. This information may still be needed when you make the online application, and is provided below for your assistance. The Mentor Radio Model identification is not the same as the FCC Identification.

  • Page 9: Limited Warranty

    LIMITED WARRANTY Your Mentor Radio, LLC. equipment is warranted to the original consumer purchaser only, for one full year, to be free from defects in materials and workmanship under normal use. This warranty does not include damage to the product resulting from accident or misuse. This warranty will not be effective unless you submit a Warranty Registration online at www.mentorradio.com .
