UDS-1000
USB 2.0 Docking Station
User's Manual
Ver. 1.00-0512

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDS-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for LevelOne UDS-1000

  • Page 1 UDS-1000 USB 2.0 Docking Station User’s Manual Ver. 1.00-0512...

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION ......................3 ........................3 EATURES ....................3 ACKAGE ONTENTS .................... 4 YSTEM EQUIREMENTS ....................4 VAILABLE FUNCTIONS ....................... 5 NTERFACES LED I ......................6 NDICATOR INSTALLATION ........................ 7 98/98SE ......................7 A. USB Hub Installation.................... 7 B.

  • Page 3: Introduction

    Backward compatible with USB 1.1 devices Easy installation and compatible with Windows 98/98SE/ME/2000/XP 1.2 Package Contents The product you purchased should contain the equipment and accessories shown as follows: UDS-1000 USB 2.0 Docking Station VGA/USB Combo Cable Power Adapter CD with Manual / Driver...

  • Page 4: System Requirements

    1.3 System Requirements A PC with Pentium series, equivalent, or above. A minimum of 16M bytes of RAM. One available USB type A downstream port (UHCI, OHCI, or EHCI). Windows 98 or later. 1.4 Available functions The available functions of USB 2.0 Docking Station depend on the status of power supplied: Bus powered Connect the USB/VGA combo Y cable to your PC to provide bus power.

  • Page 5: Interfaces

    1.5 Interfaces Two mini-din PS/2 ports for keyboard, mouse. One RJ45 10/100T base Ethernet connector. One DB-9 RS-232 serial interface connector supports baud rates from 4800 to 115.2K. One DB-25 parallel connector supports IEEE-1284 bi-directional printer port. Three USB receptacles type A downstream ports. One male and one female DB-15 VGA connectors.

  • Page 6: Led Indicator

    1.6 LED Indicator Power Indicator The Power Indicator will turn RED as either bus power or external power is supplied, even both of them supplied. LAN Indicator Link/Act (RED): This LED turns on if the 10/100Mbps (100BASE-TX) Ethernet is connected. Transmission (RED): Blinking to indicate that the data is being received or transmitted through the RJ-45 port.

  • Page 7: Installation

    2 Installation This installation guide is written in accordance with different operation systems, including Windows 98/98SE/ME, Windows 2000/XP. Power on your computer and make sure that the USB & VGA ports are enabled and working properly. 1. Put CD into CD-ROM drive of PC or Notebook. 2.
  • Page 8 A2. Tick “Search for the best driver for your device” and press “Next” to continue. (Ref. Fig. Win98-A2) Fig. Win98-A2 A3. Tick “CD-ROM drive” and press “Next” to start the searching process. (Ref. Fig. Win98-A3) Fig. Win98-A3 A4. Press “Next” to start the installation process.

  • Page 9: Ieee-1284 Controller Installation

    A5. Press “Finish” to complete the installation of USB HUB. (Ref Fig. Win98-A5) Fig. Win98-A5 2.1.2 B. IEEE-1284 Controller Installation B1. Please insert the “USB 2.0 VGA LAN DOCK” CD into your CD-ROM drive and press “Next” to continue. (Ref. Fig. Win98-B1) Fig.
  • Page 10 B3. Tick “Specify a location” and click “Browse” to select the location of the driver folder in the “USB 2.0 VGA LAN DOCK” CD. Press “Next” to start the searching process. Fig. Win98-B3 (Ref. Fig. Win98-B3). B4. Press “Next” to start the installation process.

  • Page 11: Usb-To-Serial Port Installation

    2.1.3 C. USB-to-Serial Port Installation C1. Please insert the “USB 2.0 Docking Station” CD into your CD-ROM drive and press “Next” to continue. (Ref. Fig. Win98-C1) Fig. Win98-C1 C2. Tick “Search for the best driver for your device” and press “Next”...
  • Page 12 C4. Press “Next” to start the installation process. (Ref. Fig. Win98-C4) Fig. Win98-C4 C5. Press “Finish” to complete the installation of USB-to-Serial Port. (Ref. Fig. Win98-C5) Fig. Win98-C5...

  • Page 13: Usb Composite Device Installation

    2.1.4 D. USB Composite Device Installation D1. Please insert the “Windows 98” CD into your CD-ROM drive and press “Next” to continue (Ref. Fig. Win98-D1) Fig. Win98-D1 D2. Tick “Search for the best driver for your device” and press “Next” to continue.
  • Page 14 D4. Press “Next” to start the installation process. (Ref. Fig. Win98-D4) Fig. Win98-D4 D5. Press “Finish” to complete the installation of Composite Device. (Ref. Fig. Win98-D5) Fig. Win98-D5...

  • Page 15: Ethernet Port Installation

    2.1.5 E. Ethernet Port Installation E1. Please insert the “USB 2.0 VGA LAN DOCK” CD into your CD-ROM drive and press “Next” to continue. Fig. Win98-E1 E2. Tick “Search for the best driver for your device” and press “Next” to continue. (Ref.
  • Page 16 E4. Press “Next” to start the installation process. (Windows might ask you to insert the “Windows 98” CD during the installation process). Fig. Win98-E4 E5. Press “Finish” to complete the installation of Ethernet Port. (Restart Windows might necessary). Fig. Win98-E5...

  • Page 17: Usb Hid Device For Ps/2 Keyboard & Mouse

    2.1.6 F. USB HID Device for PS/2 keyboard & mouse (This step might repeat once due to two different devices, mouse and keyboard) F1. Please insert the “Windows 98” CD into your CD-ROM drive and press “Next” to continue. (Ref. Fig. Win98-F1) Fig.
  • Page 18 F4. Press “Next” to start the installation process. (Ref. Fig. Win98-F4) Fig. Win98-F4 F5. Press “Finish” to complete the installation of HID. (Ref. Fig. Win98-F5) Fig. Win98-F5...

  • Page 19: Win Me

    2.2 For WinME The driver installation for WinME is divided into A to C three-steps. Please install USB 2.0 Docking Station under WinME step by step by the following instructions: 2.2.1 A. USB-to-Parallel Port Installation A1 Please insert the “USB 2.0 VGA LAN DOCK”...

  • Page 20: Ethernet Port Installation

    B2. Press “Finish” to complete the installation of USB-to-Serial Port. (Ref. Fig. WinME-B2) Fig. WinME-B2 2.2.3 C. Ethernet Port Installation C1. Tick “Specify the location for a better driver” and press “Next” to continue. (Ref. Fig. WinME-C1) Fig. WinME-C1 C2. Tick “Search for the best driver for your device”...
  • Page 21 C3. Press “Next” to start the installation process. (Ref. Fig. WinME-C3) Fig. WinME-C3 C4. Press “Finish” to complete the installation of Ethernet Port. (Ref. Fig. WinME-C4) Fig. WinME-C4...

  • Page 22: Win 2000

    2.3 For Win2000 The driver installation for Win2000 is divided into A, B two-steps. Please install USB 2.0 Docking Station under Win2000 step by step by the following instructions: 2.3.1 A. USB-to-Serial Port Installation A1. Please insert the “USB 2.0 VGA LAN DOCK”...
  • Page 23 A4. Press “Next” to start the installation process. (Ref Fig. Win2k-A4) Fig. Win2k-A4 A5. Press “Finish” to complete the installation of USB-to-Serial Port. (Ref Fig. Win2k-A5) Fig. Win2k-A5...

  • Page 24: Ethernet Port Installation

    2.3.2 B. Ethernet Port Installation B1. Press “ Next” to continue. (Ref Fig. Win2k-B1) Fig. Win2k-B1 B2. Tick “Search for a suitable driver for my device” and press “Next” to continue. (Ref Fig. Win2k-B2) Fig. Win2k-B2 B3. Tick “CD-ROM drives” and press “Next”...
  • Page 25 B4. Press “Next” to start the installation process. (Ref Fig. Win2k-B4) Fig. Win2k-B4 B5. You will receive a message stating that the software you are installing has not passed Windows Logo testing. But this driver is fully compatible with Windows 2000, so just Fig.

  • Page 26: For Winxp

    2.4 For WinXP Please install USB 2.0 Docking Station under Win2000 step by step by the following instructions: 2.4.1 A. Serial Port Installation A1. Please insert the “USB 2.0 VGA LAN DOCK” CD into your CD-ROM drive. Tick “Install the software automatically”...

  • Page 27: Ethernet Port Installation

    2.4.2 B. Ethernet Port Installation B1. Tick “Install the software automatically” and press “Next” to continue (Ref Fig. WinXP-B1) Fig. WinXP-B1 B2. Press “Finish” to complete the installation of Ethernet Port. (Ref Fig. WinXP-B2) Fig. WinXP-B2...

  • Page 28: Important Notice

    3 Important Notice Before connecting the printer to the parallel port of USB 2.0 Docking Station, the printer driver must be installed on your computer in advance, otherwise it might print unknown format of characters. Please refer to "Setting Up the Printer Device" section to connect your printer to the USB 2.0 Docking Station.

  • Page 29: System Properties Status

    3.2 System Properties Status Please click on Start, Settings, Control Panel, double-click System, and Device Manager. Please double check “Human Interface Devices”, “Keyboard”, “Mouse”, “Network adapters”, “Ports”, and “Universal serial bus controller” on the dialog box and see if they are working properly. (Ref.

  • Page 30: Set Up The Printer Device

    4 Set UP the Printer Device Follow the steps below to connect your printer to the USB 2.0 Docking Station with your PC: 4.1 For Windows 98/98SE/ME: Connect the USB 2.0 Docking Station to your printer with the parallel cable and then turn on the printer.
  • Page 31 Click Details folder tab and change the printer port to LPT2: USB-to- Parallel Port. (Ref. Fig.7) Fig.7 If you do not have a printer installed yet, go to Start, Settings, Printers, and choose Add Printer. The Add Printer Wizard will start and assist you to install a new printer device.

  • Page 32: For Windows 2000/Xp

    4.2 For Windows 2000/XP Connect the USB 2.0 Docking Station to your printer with the parallel cable and then turn on the printer. Connect the USB 2.0 Docking Station to the USB port on your computer with the USB 2.0 transfer cable provided. If you have installed a printer device before, go to Start, Settings, and Printers.
  • Page 33 Windows will ask you which port the printer will be used, choose USB001: (Virtual printer port to USB). (Ref. Fig.10) Fig.10...

  • Page 34: Set Up The Hyperterminal With Serial Port

    5 Set Up the HyperTerminal with Serial Port Make sure that HyperTerminal is installed in your system. If not, please go to Start, Settings, and Control Panel. Double click Add/Remove Programs, choose Windows Setup page, Communications, click Details button and enable HyperTerminal to install the program to your Windows system.
  • Page 35 Fig.12 Click the Connect using item to indicate the proper COM port, which appeared in step 1. Follow the instructions to complete the setup.

  • Page 36: Uninstalling Usb 2.0 Docking Station

    6 Uninstalling USB 2.0 Docking Station If you want to remove USB 2.0 Docking Station and its driver, you can uninstall it by the following steps: Remove the device Please Unplug the USB cable. Uninstall the driver For the Window 2000/XP users: since the system has build in the USB Printer Class driver already, so you do not need to remove the printer driver.
  • Page 37 5. Run DRemover98_2k.exe from the driver folder in CD. 6. Please Press OK to remove Serial Converter. (Ref. Fig.15) Fig.15 7. Press “Yes” to reboot your Windows system to complete. (Ref. Fig.16) Fig.16...

  • Page 38: For Windows 2000/Xp

    6.2 For Windows 2000/XP 1. Run remove_xp2k.exe from the driver folder in USB 2.0 Docking Station CD to remove the LAN driver, this program will not show any message on the screen. 2. Run DRemover98_2k.exe from the driver folder in CD. 3.

  • Page 39: Trouble Shooting

    7 Trouble Shooting Q: Installed the driver for USB 2.0 Docking Station under Windows XP operation system, there is no Pinter Port available in the device manager , but the other Ports ( Serial ,Mouse, Keyboard and USB) are OK . A: The driver for USB to Printer converter on Windows 2000 and XP is not required.

  • Page 40: Application Note

    8 Application Note USB 2.0 Docking Station normally derives its own power from PC Host. When only the Host power is supplied, the Power LED will turn RED, and the serial, parallel, keyboard, mouse, Ethernet and 3 downstream ports can operate without the external power adapter.

  • Page 41: Fcc Statement

    Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages.
