MusicMan MA Soundstation User Manual

MusicMan
Mobile Speaker / Soundsystem with built-in MP3 player + FM radio
The Declaration of Conformity: www.technaxx.de/ (in bottom bar "Konformitätserkärung")
 Mobile stereo wide range speaker system for MP3/4, CD/DVD, iPhone, iPad, iPod, PSP,
mobile phones, PC/Notebook, with integrated MP3 player for USB flash disk and
MicroSD card (up to 32GB)
 Built-in FM radio and Line-IN/AUX
 Housing out of aluminium, lightweight, durable, available in 5 different metallic colours
 Protection grille for the speaker cone
 Several power supply options: built-in rechargeable battery, computer USB or AC
adapter* DC 5V (*not included)
 Ideal for traveling, easiest installation, excellent sound quality

Key functions

No. Key Line-IN mode
Play / Pause
1
VOL –
2 Volume down
Volume up
3 VOL +
4 invalid
5 invalid
USB/SD/FM Switches between USB / MicroSD / FM / Line-IN
6
Notice: USB / MicroSD / Line-IN  the last inserted has priority.

Play Music

 MP3 files are played in the same order, like they are stored on the USB flash disk or
MicroSD card.
 If you stored music files in different folders, the files are played folder by folder. Neither
you cannot jump between the folders, nor you can select a folder.
 If new MP3 files are stored, the row of music files will change. The device will mix the files
itself. You have no influence on that.
 If the USB flash disk or MicroSD card is removed from the device, and inserted again
later, playback will start with the last MP3 file you heard.
®
MA Soundstation
User Manual
USB/MicroSD mode
Play / Pause
Volume down
Volume up
One back (keep pressing for
fast reverse)
Next one (keep pressing for
fast forward)
FM mode
Play / Pause
Volume down
Volume up
FM search back
(back to previous station)
FM search forward
(forward to next station)
