Summary of Contents for JedMark Acorn Ltl-5210M
- Page 1 Ltl Acorn Remote Cellular Scouting Camera Ltl-5210M Series USER’S MANUAL http://www.jedmark.co.uk...
-
Page 2: Table Of Contents
5.7 FAQs on MMS Function ....................23 Firmware Upgrades ........................24 6.1 Firmware Upgrades ......................24 Warranty Information ........................25 Appendix I Technical Specifications .................... 26 Appendix II Package Contents ....................28 Appendix III Instruction on Installing Battery Box ..............29 - 1 - http://www.jedmark.co.uk... -
Page 3: General Information
Cellular model with MMS function. Advanced Remote Cellular Technology transmits images to your cell phone and email account constantly at lower battery consumption and shorter transmission time, compared to products of its kind on the market. - 2 - http://www.jedmark.co.uk... -
Page 4: Application
Figure 1.2 shows the bottom view of the camera (Part # Ltl-5210M) Figure 1.3 shows the back view of the camera (Part # Ltl-5210M) and front view of the battery box (Part # LTL-BM1 or LTL-MM1) - 3 - http://www.jedmark.co.uk... - Page 5 General Information Figure 1.1: Front View of Ltl-5210M Figure 1.2: Bottom View of Ltl-5210M - 4 - http://www.jedmark.co.uk...
- Page 6 CAUTION: If you are not using the camera for an extended period of time, it is highly recommended that you remove the batteries from the camera to avoid possible acid leak that may damage the camera which would void the warranty. - 5 - http://www.jedmark.co.uk...
-
Page 7: Quick Start
2.3 Insert SD Card The camera does not come with internal memory. So it will not work without a SD (Secure Digital) memory card or SDHC (High Capacity) card. Before inserting the SD card into the card - 6 - http://www.jedmark.co.uk... -
Page 8: Enter Test Mode
TV monitor. Use key to navigate. The MENU on the keypad allows you to program the camera to work the way you want. Please make reference to 3.1 Parameter Settings in the Advanced Operation section. - 7 - http://www.jedmark.co.uk... -
Page 9: Enter Live Mode
PIR area of the prep sensor, the camera is activated and ready to shoot after 1 second. If the game continually enters into the PIR area of the main sensor, the camera takes pictures immediately, therefore catching the whole body of the game. This split-second process could be as short as 0.2 second. - 8 - http://www.jedmark.co.uk... - Page 10 So later on when the game enters the PIR area of the main sensor eventually, since it is not in fast movement, the picture will by all means capture the whole body of the game based on our standard 1.2 second response time. - 9 - http://www.jedmark.co.uk...
-
Page 11: Advanced Settings
Press Enter to set up date and time. Set Clock Enter Internal capacitor will retain the clock time for up to 7 minutes when changing batteries. Picture No. (affects 01 Photo, 02 Photos, Select the number of photos taken in - 10 - http://www.jedmark.co.uk... - Page 12 You can use the combination of 4 digits and/or alphabets to record the location in the photos (e.g. YSP1 for Yellow Stone Park). This helps multi-camera users identify the location when reviewing the photos. - 11 - http://www.jedmark.co.uk...
- Page 13 QVGA format to save transmission time and power consumption. Default Set Press OK Enter to return all your camera settings back to the manufacturer default. However, all the MMS function settings will remain except for MMS Phone No. and MMS Status. - 12 - http://www.jedmark.co.uk...
-
Page 14: File Format
You can set up your camera and/or MMS function on your home PC. Run the Setup.exe file on the enclosed CD. You can also visit the national distributor’s website to download the program, or ask your retailer for direction. The following window prompts: Click on Camera Setup, and you will see the following interface: - 13 - http://www.jedmark.co.uk... - Page 15 Retrieve the SD card from the computer and insert it in the camera. Switch to the TEST position to enter the TEST mode. A message will show up on the TFT display, indicating the Camera has been successfully set up. You are set with the camera. - 14 - http://www.jedmark.co.uk...
-
Page 16: Set Up Mms Function On Pc
ATTENTION: THE PASSWORD CAN ONLY BE SET UP ON THE CAMERA, NOT ON THE PC. 3.4 Set up MMS Function on PC After you click on Exit on the Camera Setup interface, the following window prompts again: Click on MMS Setup, and you will see the following interface: - 15 - http://www.jedmark.co.uk... -
Page 17: Camera Working With Mms
When you have the Model Ltl-5210MM, or you have upgraded your Model Ltl-5210MC by purchasing the MMS-module battery box (Part # LTL-MM1), not only will your camera work as a standard trail camera, but also send pictures to your cell phone and/or email account, when it - 16 - http://www.jedmark.co.uk... -
Page 18: View Local Mnop Name And Signal Strength On Tft Display
MPNO name and the signal strength on the TV. If you don’t have an access to a TV, wait for one minute and detach the battery box. Then you can view the information on the TFT display. - 17 - http://www.jedmark.co.uk... - Page 19 MNPO signal by following the aforementioned steps. Attention：The camera MUST be set in OFF position when attaching the MMS-module battery box to it. Secure the battery box by locking up the buckle. Otherwise, the MMS - 18 - http://www.jedmark.co.uk...
- Page 20 You need to switch the camera to OFF position, install the battery box securely, wait for one minute, and then try it again. - 19 - http://www.jedmark.co.uk...
-
Page 21: Ltl-5210M Series Products
4.2 Models for Purchase: Ltl-5210MM = Ltl-5210M Camera + LTL-MM1 MMS-module battery box Ltl-5210MC = Ltl-5210M Camera + LTL-BM1 Battery box LTL-MM1 ----- MMS-module battery box Ltl-5210M Camera LTL-MM1 LTL-BM1 Standard MMS-module battery battery box - 20 - http://www.jedmark.co.uk... -
Page 22: Important Information
Video mode or Cam+Video mode. Compared to products of its kind on the market, our camera takes thirty percent more full-length video clips. Besides that, when battery power gets low, our camera automatically shortens the video length so as to - 21 - http://www.jedmark.co.uk... -
Page 23: 850Nm And 940Nm Ir Led
940nm IR LED, however, is it emits very low-glow flash that is almost invisible from 5 feet away. 5.6 Mount on Tripod The camera can be mounted on a 1/4" tripod. CAUTION: To avoid breakage, always turn the knob in position to secure the bottom cover. - 22 - http://www.jedmark.co.uk... -
Page 24: Faqs On Mms Function
Yes. After you upgrade the camera, all previous settings of the camera and the MMS are gone. You need to run the setup.exe file on the enclosed CD to set up the camera again. Refer to 3.3 Setup Camera on PC and 3.4 Setup MMS on PC. - 23 - http://www.jedmark.co.uk... -
Page 25: Firmware Upgrades
In other word, an upgrade for Model Ltl-5210M only applies to that model. If a camera is falsely upgraded by running a non-compatible program, it will quit working and needs to be sent back for repair. This issue is not covered under warranty. - 24 - http://www.jedmark.co.uk... -
Page 26: Warranty Information
It does not cover normal wear of the product. Please contact our tech support department to determine the nature of the problem before you return a Ltl Acorn product under this warranty for repair or exchange. - 25 - http://www.jedmark.co.uk... -
Page 27: Appendix I Technical Specifications
On/Off; 1 Second ~ 24 Hours Programmable VGA = 640x480; QVGA = 320x240; OFF Upgradable MMS Status Programmable “0” = Unlimited; 0 ~ 99/Day MMS Numbers Upgradable MMS Phone No. 1 ~ 3 Phone Numbers Upgradable - 26 - http://www.jedmark.co.uk... - Page 28 Consumption Low Battery Alert 4.2~4.3V Interface TV out (NTSC); USB; SD Card Slot; 6V DC External Strap; Tripod Mounting Waterproof IP54 Operation -22~+158°F/-30 ~+70°C Temperature Operation 5% ~ 95% Humidity FCC & CE & ROHS Certificate - 27 - http://www.jedmark.co.uk...
-
Page 29: Appendix Ii Package Contents
Quantity LTL-MM1 （Ltl-5210MM） (Ltl-5210MC) MMS-module battery box Digital Camera Additional Battery 1 (Standard) 1 (With MMS 1 (With MMS module) module) TV AV IN Cable USB Cable Strap External DC Cable (optional) Installation CD Warranty Card - 28 - http://www.jedmark.co.uk... -
Page 30: Appendix Iii Instruction On Installing Battery Box
Appendix III: Instruction on Installing Battery Box Appendix III: INSTRUCTION ON INSTALLING BATTERY BOX - 29 - http://www.jedmark.co.uk...
