- Page 1 MPEG-4 Network Camera UNC 7700 User’s Manual Version:1.0 Date: 7/12/2007...
-
Page 2: Table Of Contents
1. Introduction ........................3 1.1. What is the MPEG-4 Network Camera? ..............3 1.2. Advanced Features....................3 2. Physical Characteristics....................4 3. Installation........................5 3.1. Installation Preview....................5 3.2. Hardware Installation .....................6 3.3. Software Installation ....................8 3.4. Network Configuration ...................9 4. Getting to Know the UNC7700 WEB UI.................14 5. - Page 3 10. I/O & COM Port Connectors ..................54 11. Specifications .......................57...
-
Page 4: Introduction
1.1. What is the MPEG-4 Network Camera? The MPEG-4 Network Camera (hereinafter call to UNC7700) is an Internet-based digital video surveillance device with a built-in Web server. It uses TCP/IP to distribute compressed live video over a Local Area Network (LAN) and/or the Internet through an Ethernet connection. -
Page 5: Physical Characteristics
– Product View MPEG-4 Network Camera Rear Panel View Stand Adjust Screw DC Iris Lens Connector Lens Focus Adjustment... -
Page 6: Installation
3.1. Installation Preview There are 3 mains steps required to perform a successful installation: Hardware installation Software installation Network configuration Hardware installation consists of connecting cables to the UNC7700 including network, video, and power cables. Software installation consists of the installation of software that is necessary to properly view the video from the UNC7700 or to configure the UNC7700 itself. -
Page 7: Hardware Installation
3.2. Hardware Installation – Hardware Connection Ensure the UNC7700 is powered off. Connect the UNC7700 to your network using twisted pair (CAT 5) cable terminated with a standard RJ-45 connector. If it is connected to a hub/switch, use a pass-through cable. If it is connected directly to a PC, use a crossover cable. - Page 8 – Description of the Connections 1. Power In Jack Non PoE model: Connects to the AC adapter. PoE model: The AC adapter is not necessary. The camera will get the power from the Ethernet cable. Please follow the below figure for the connection 2.
-
Page 9: Software Installation
3.3. Software Installation With the exception of the Adobe Flash Player all the software that is necessary for the proper display and use of the UNC7700 is available on the included CD or from the Web site. For the following installation procedures it is assumed that all installation media will be taken from the CD. -
Page 10: Network Configuration
3.4. Network Configuration IP Installer is a utility that provides an easier, more efficient way to configure the IP address and network settings of the UNC7700. It even provides a convenient way to set the network settings for multiple devices simultaneously using the batch setting function. - Page 11 The IP Installer window is displayed below. Click Tool > Search Network Device, the available devices will be listed as below. Using IP Installer 1. From the list, select the device with the MAC Address that corresponds to the device that is to be configured. The MAC Address is identical to the unit’s S/N (Serial Number).
- Page 12 3. After filling in the properties, click [Synchronize] button to complete the configuration settings and save in the network camera and PC immediately. 4. If click [OK] button, the configuration is only be saved in the PC. Opening the Web UI To access the Web UI of the selected unit, right-click on an item in the list and select Open Web, or click View >...
- Page 13 The UNC7700 supports video display using either QuickTime (default) or ActiveX. The ActiveX control is only supported in Microsoft Internet Explorer for Windows operating systems.
- Page 14 If the device has been configured to display the video using the ActiveX control, when the Web UI opens for the first time through Internet Explorer, the Internet Security settings must be lowered to perform a one-time-only installation of the ActiveX component.
-
Page 15: Getting To Know The Unc7700 Web Ui
The UNC7700 Web UI is basically divided into display and configuration. The home page is the video display page which can be seen below. – Main Menu Menu Language Selection Click a language name to change the language display for the complete Web UI. There are three kinds of languages can be selected, they are English, Traditional Chinese and Simplified Chinese. - Page 16 Video Status Display the status for the selected channel on the tab: Video IP, RTSP Port, Resolution, PTZ, Video Type (Mpeg4 or Mjpeg) and Audio. Audio Audio ON Voice is currently ON; select which channel should be the one for broadcasting the audio.
- Page 17 Video Conference Click “Configuration” to open the configuration pages. Location Define the settings for the local device. Remote Define the settings for the remote device, either IP Camera or Network Camera.
- Page 18 Record Setting Video Conference Reserve Space: Set the total file space for the recording. The unit is in MB. Max File Length: Set the file space that a single will be using. The unit is in MB. Save File Path: Indicate which folder should be the file saved to.
- Page 19 Record Setting Video Conference IP Address: Enter a valid IP address from a remote IP Camera or Network Camera. HTTP Port: Enter the port number used for the remote IP address to display the video. User Name / Password: Enter the respective Username and Password if applicable. If no user has been set for the device, the default value should be “root”...
- Page 20 Name: Enter a name for the remote device. PTZ Model: Support some kinds of PTZ models to control remote devices. Note: If your PTZ devices don’t support these models on the menu list, please contact with your distributor. Product Type: Select from MJPEG or MPEG4 Network Cameras or IP Cameras.
-
Page 21: Nc Configuration
The UNC7700 Configuration is currently divided into 4 sections, “Live” and “Reboot”: – A/V Settings Set A/V settings and they include “General”, “PTZ Setting”, “External Source” and “On Screen Display”. – Network Settings Set the network settings and they include “General”, “Wireless” and”DDNS”. Note: “Wireless”... -
Page 22: A/V Settings
5.1. A/V Settings – General Basic: Audio Enables and Disables the Audio stream. Resolution There are 3 different resolutions to choose from: D1: 720x480 NTSC/720x576 PAL SIF: 352x240 NTSC/352x288 PAL QSIF: 176x112 NTSC/176x144 PAL Frame Rate The frame rate can be set between 1-30fps. Encoder Format Format can be selected for MPEG4 or MJPEG. - Page 23 If you are planning on using the device on an Internet connection It is recommended that you select a constant bitrate that corresponds to your actual upload speed. It is also recommended that you modify the frame rate and resolution as well, otherwise the video stream may become blocky or otherwise distorted.
- Page 24 Advanced: Interlacing There are two modes available: Interlaced or Progressive. Interlaced mode is a storage mode. An interlaced video stream contains fields rather than frames, with each field containing half of the lines of a frame. A progressive video stream consists of only full frames. Interlaced video streams can bring a lower bitrate but may cause lower quality.
- Page 25 I-frame only mode has very little compression resulting in large file sizes. I-frame and P-frame mode offers relatively good compression with medium file sizes. Although this requires more work on the host PC to decode the video. GOP Size GOP stands for Group of Pictures. It defines the number of frames from one I-frame to the next.
- Page 26 Image Adjustment: Contrast, Brightness, Hue and Saturation can be adjusted. Values run from -100 through 100. Rotation Select the Digital Rotation for the camera: 0 – 0 or 360 Degrees; 1- 90 Degrees; 2- 180 Degrees; 3- 270 Degrees. Auto Electronic Shutter Click On/Off to adjust the auto electronic shutter Backlight Compensation Click On/Off to adjust the backlight compensation.
-
Page 27: Ptz Settings
– PTZ Settings PTZ Model: Support some kinds of PTZ models to control remote devices. Note: If your PTZ devices don’t support these models on the menu list, please contact with your distributor. Camera ID: Define camera ID to connect Network Cameras when using multi PTZ devices. -
Page 28: External Sources
– External Sources The “External Sources” feature allows user to set additional network cameras for the device. Video select: NC support four sources to do video control and monitor; the first one is internal source for analog camera connection, so the “Video select” is from 2 to 4. IP Address: Enter a valid IP address from an IP Camera or Network Camera. - Page 29 PTZ Model: Select the PTZ model if it is an IP speed dome. Name: Enter the name for the device. RTSP Port: Enter the port for the streaming. Product Type: Select the product type.
-
Page 30: On Screen Display
– On Screen Display Display a text on top of the video 1. Select “0: Disable” or “1: Enable” on screen display item. 2. Enter into the OSD text that should be displayed. 3. Select Coordinates X, Y for the location of the text. 4. -
Page 31: Network Settings
5.2. Network Settings – General Please select the appropriate option to connect. MAC Address: It’s read-only to displays the MAC address of the device. IP Address: Enter the IP address of the device. Subnet Mask: The subnet mask for the network segment to which the device is connected. - Page 32 Wireless Setting: This is the optional function for the particular NC models. Wireless Mode: Disabled: Disable wireless function to use physical Ethernet cable to connect to network. Wireless Client: Select this item to enable wireless function and this device is a client under wireless infrastructure. Network Name (ESSID): When users would like to use wireless function, a wireless access point (AP) must be assigned to connect to the wireless network.
-
Page 33: Ddns
– DDNS The DDNS (Dynamic Domain Name Service) is used when users want to access the UNC7700 with an easy memorized name such as “http://demo.ddns.company.com” instead of “http://<IP address>. This service could be useful when the UNC7700 is located behind Dial-up ADSL or IP sharing devices, which don’t not have fix IP addresses, then it's impossible to reach the UNC7700 from Internet. - Page 34 Internet HTTP (port 80) request to Intranet port 8000, then, in this case, we must configure the "Router Incoming Port" to 80, and inside the NC Network settings should set HTTP port with 8000. Update Time: Specify the NC updated frequency in seconds, and the default is 600 (10 minutes), this is interval that NC will automatically send an updated packet to DDNS server.
- Page 35 change your register name by changing server name. Note: the user must verify on its own the full functionality of the DDNS service provider. Utilization of such service on any provider is dependant upon the user’s choice and responsibility.
-
Page 36: System
5.3. System – System Information MAC Address: This is the read-only information to Display the device's MAC address. Language: Select the language to be used. English, Traditional and Simplified Chinese can be chosen. Description: Useful as an administrative identifier. It does not affect the operation of the device. Location: Useful for identifying the position of the device. -
Page 37: Time Configuration
– Time Configuration Server Time Setting: The UNC7700 provides two kinds of time settings. Server Time: This is read-only information to display UNC7700 system time. Time Mode: Synchronize with NTP server: Auto synchronizes the time with NTP server by the time zone and the NTP server 1~3 settings. Set Manually: Manually enter the system date and time or synchronize with computer time. -
Page 38: User
– User Note: The first added user must have administrative right, and must be the last one to be removed. To add a user, first enter the user name and password in the respective fields, and then click on “Add User”. To remove a user, first select the user from the list, and then click “Delete User”. -
Page 39: Event
5.4. Event – General Trigger: System provides “GPIN” and “Motion Detection” to trigger events. GPIN & GPIO Input Status: They are auto detected to display the status. Motion Detection: When Users would like to use “Motion Area” function and this icon must be enabled. Action: Functions to record events. -
Page 40: Motion Area
– Motion Area Motion Area: The “Motion Detection” icon (Configuration>Event>General>Trigger) must be enabled when use this function. Use Mouse to drag out a detection area on the video. Left-click the area and drag the corner to change the size. Right-click the area and select “Property”. Check “Enable”, click “OK”... - Page 41 Box Property: Motion vector threshold (default value: 4000): Motion vectors are typically used to compress video by storing the changes to an image from one frame to the next. We use these vectors creatively to detect and track motion and to find an alternative to traditional video decoding using phase shifting.
-
Page 42: E-Mail / Ftp
– E-Mail / FTP E-mail Setting: The “E-Mail Image” icon (Configuration>Event>General>Active) must be enabled when use this function. Mail From: Enter the mail address of the mail sender. Receipt To: Enter the mail address of the mail receiver. Mail Server: Enter the mail server name or IP address. Authorization: Disable or enable the security for mail authorization. -
Page 43: Broadband Connections Q&A
& & & – How can I configure my Network Camera with my ADSL connection? When using an ADSL connection you have to know if your ISP assigned you a Static Public IP or Dynamic Public IP. Consult with your ISP for more information. –... - Page 44 – Once I set this up, how can I view my camera through a remote location? You can register your camera or Network Camera at a DDNS Service, and even if your Public IP changes, you can access it from a remote location*. Refer to Network Camera Manual at Network Configurations, DDNS settings in order to set it up.
- Page 45 assigned to specific services. So when you consider choosing your own ports, select those starting from 1025 to 65535. – Configuration Examples: You are a user with a network camera who wants to access it from a remote location through the Internet. The following equipment is available: E 1 Network Camera Sever.
-
Page 46: Case 1 Using Default Settings
6.1. Case 1 Using default settings In this case what we have here is: 1 Public IP Address 210.20.35.163, assigned by the Internet Service Provider (ISP). 1 Camera Server, with a local IP of 192.168.1.21. 1 Broadband router. Since we are sharing only one single Internet connection through our Local Network, the Port Forwarding configuration in our Broadband Router for the camera will be as follows: Private IP... -
Page 47: Assigning Ports Manually
6.2. Assigning ports manually In this case what we have here is: 1 Public IP Address 210.20.35.163, assigned by the Internet Service Provider (ISP), but we will be using Port 9999 for accessing the camera from the Internet. 1 Network Camera, with a local IP of 192.168.1.21, using port 9999 to get access to the camera through the Local Network 1 Broadband router Since we are sharing only one single Internet connection through our Local... -
Page 48: Using 2 Or More Public Ips
6.3. Using 2 or more Public IPs The following figure is just an illustration on how the camera can be connected when 2 or more Public IPs is involved in a network infrastructure. In this case, the network configurations for the camera such as IP address, Gateway, DNS will be assigned by the ISP. -
Page 49: Troubleshooting
Symptom: The UNC7700 can not be accessed from a Web Browser. Possible Causes Remedial Actions The IP address is already used by Disconnect your UNC7700 from the another device. network. Run the PING utility and follow the appropriate recommendations. Note: The assigned IP number can be assumed valid if the PING utility returns "request timed out"... - Page 50 In Windows 95/98, the ARP table was In Windows 95/98, the ARP command empty when you tried to set the IP can't be used if your have an empty ARP address. table. Type arp Va to view the ARP table. If it is empty, you must ping an existing unit on your network before you can download the IP address to the...
-
Page 51: Upgrading The Firmware
UNC7700 software is contained in Flash Memory, a silicon chip allowed to be erased and re-written. It provides an easy way to update the software without change any parts; just simply load the newest software from network. 8.1. The following procedures are for updating the software: –... - Page 52 4. Set FTP to binary mode using the command "bin". In FTP session window, enter "bin" 5. Upload the firmware into the network camera by FTP "put" command. In FTP session window, enter "put flash.bin" In FTP session window, enter "bye" to quit FTP session. 6.
- Page 53 For example, the UNC7700 IP address is 192.168.0.200, then C:\Documents and Settings\Administrator>cd \temp Key in the path stores the “flash.bin” C:\temp>ftp 192.168.0.200 Connected to 192.168.0.200. Key in this command, change the IP to yours 220 192.168.0.200 Network camera FTP server ready. Input the account, default is “root”...
-
Page 54: Restore Factory Default
To restore the factory default for UNC7700, please follow the steps: 1. Plug out the power jack to turn off the UNC7700. 2. Use a needle about 5cm long insert into the "Factory Default Hole" and push the button in the hole, keeping push it and don't release. 3. - Page 55 & & & The GPIO & COM provides control signal input and output, which including one GPIO input, GPIO output as Relay connection and one RS-485 port multiplex with COM port. The GPIO & COM port provide connection of PTZ devices and external console to control the device.
- Page 56 GPIN: Input high when opening the connection; input low when sinking more than 10mA or shorting to pin 5 (GND). RXD (COM Port Receive Data) TXD (COM Port Transmit Data) RS485A / RS485B: To connect with external PTZ devices, please contact your dealer/distributor to get the information of the supported PTZ models.
- Page 57 – Specifications of the Solid state Relay: Features: Normally Open, Single Pole Single Throw Control 350VAC or DC Voltage Switch 130mA Loads LED control Current, 5mA Low ON-Resistance dv/dt, >500 V/ms IsolationTest Voltage, 3750VACrms Ω Absolute Maximum Ratings: (TA=25℃) Emitter (Input) Detector (Output) Output Breakdown Voltage: ±350V Reverse Voltage: 5.0V...
- Page 58 Hardware System CPU: 32-Bit RISC Processor ROM: 4MB Flash ROM RAM 32MB SDRAM Watchdog: Chip to monitor system voltage tolerance and abnormal program execution Connectors One RJ-45 connector for Ethernet (built-in Power-over-Ethernet (PoE) for optional model) One mini-DIN for RS-485/RS-232/GPIO/Video out -- RS-485: for external Pan/Tilt (PT) device control -- RS-232: for console connection -- GPIO: for one fully opto-isolated alarm input...
- Page 59 Management Installation IP Installer (Win32 Application) Firmware Upgrade Remote upgrade via FTP Customized Web UI is upgradeable via FTP and Telnet Client PC Requirements Pentium 4 2.0GHz or equivalent 512MB RAM Microsoft Windows 98se/Me/2000/XP Microsoft Internet Explorer 5.x or above Microsoft DirectX 9.0c Macromedia Flash 6 MPEG-4 Codec...
