- Page 1 OWNER’S MANUAL FRIDGE- FREEZER Please read this owner’s manual thoroughly before operating and keep it handy for reference at all times. www.lg.com P/No. : 3828JD8636T...
-
Page 3: Table Of Contents
Table of Contents Registration Introduction Important Safety Instruction Identification of Parts Temperature Control Operation Super Freezer Self Test Door Alarm Miracle Zone Ice Making Defrosting Suggestion On Storing Food Food storage Care and General Information Maintenance Lamp Replacement To Reverse the Doors Cleaning Trouble Shooting Trouble Shooting... -
Page 4: Introduction
Introduction Registration Introduction The model and serial number are found on the rear of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 5 Introduction Important Safety Instruction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power A dedicated outlet should be used.
- Page 6 Introduction Important Safety Instruction Do not extend or modify the length of the power plug. This may become the cause of fire or electric shock. Unplug the power plug when cleaning, handling or replacing the interior lamp of the fridge-freezer. •...
- Page 7 Introduction Important Safety Instruction Make sure of grounding. Consult a qualified electrician or service person if the grounding instructions are not completely Ground understood, or if you have doubts Wire More than Copper on whether the appliance is properly 30 inches Flat grounded or not.
- Page 8 Introduction Important Safety Instruction Prevent children from entering the product. It may endanger the life of a child if the child enters the refrigerator. Take care when opening and closing the refrigerator doors. Vigorous opening or closing may cause the contents to topple out resulting in injury or damage.
- Page 9 Introduction Important Safety Instruction Do not store medicine or academic materials in the fridge-freezer. If materials with strict temperature restrictions, such as medicines, are stored, they may deteriorate or react undesirably resulting in possible harm or risk. Do not use any combustible spray near the fridge- freezer.
- Page 10 Introduction Important Safety Instruction DO NOT use a water damaged unit until it has been certified safe by a licensed electrician or similarly qualified person. It may be the cause of an electric shock or fire. When gas is leaked, do not touch the fridgefreezer or the outlet and ventilate the room immediately.
- Page 11 Introduction Important Safety Instruction Do not allow any person except a qualified engineer to disassemble, repair or alter the fridge- freezer. It may cause injury, electric shock or fire. Do not use the fridge-freezer for non-domestic puposes (storing medicine or testing material, or use in a mobile application.) It may cause an unexpected risk such as fire, electric shock, deterioration of...
- Page 12 Introduction Important Safety Instruction Install the fridge-freezer on a solid and level floor. Installing it in an unstable place may cause death by the refrigerator falling down when opening or closing the door. Do not insert hands or a metal object into the exit of cool air, the cover, the bottom of the fridge- freezer, the heatproof grill (exhaust hole) at the back.
- Page 13 Introduction Important Safety Instruction Do not insert hands into the bottom of the fridge- freezer. The iron plate at the bottom may cause injury. Carry the fridge-freezer with the handles at the bottom of the front and the top of the rear. Otherwise, your hands may slip possibly resulting in injury or product damage.
- Page 14 Introduction Important Safety Instruction WARNING • This fridge-freezer must be properly installed and Precaution located in accordance with the Installation Instruction before it is used. • Before you install this fridge-freezer refer to installation manual. • Never unplug your fridge-freezer by pulling on the power cord.
- Page 15 Introduction Important Safety Instruction • Do not disassemble, repair or alter the appliance. It may cause fire or abnormal operations, which may lead to injury. • Pull the power plug out of the socket before replacing the interior light in the refrigerator. Otherwise, there is a risk of electric shock.
- Page 16 Introduction Important Safety Instruction Keep ventilation openings, in the appliance enclosure WARNING or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit.
- Page 17 Introduction Important Safety Instruction CAUTION • If the wall socket is loose, do not insert the power plug. It may cause an electric shock or fire. • Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull it straight out from the outlet.
-
Page 18: Identification Of Parts
Introduction Identification of Parts Dairy Corner Lamp Egg Tray Removable Door Basket Glass Shelf Bottle Guide Multi-Air Flow Duct Vegetable Drawer Bottle Used to keep fruits Door Basket and vegetables crisp Miracle Zone Ice Tray Ice Bank Freezer Compartment Leveling Screw... -
Page 19: Operation
Operation Temperature Control Your fridge-freezer has controls that lets you regulate the temperature in the fridge and freezer compartments. Display Panel For Temperature Control Adjusting the temperatures and functions Display Panel Super Freezer Power Temperature Adjustment Button Temperature Adjustment Button for Freezer Compartment for Miracle Zone Compartment Temperature Adjustment Button... - Page 20 Operation Power • If you push button more than 3 seconds you can switch on or off the Refrigerator. How to adjust the • The initial Temperature of the Freezer and Refrigerator Compartment is -18°C and 2°C respectively. temperature in the You can now adjust the temperature of the refrigerator and compartments as you want.
-
Page 21: Super Freezer
Operation Super Freezer • Please select this function for faster freezing. • This function is used when you want to freeze the foods quickly. Press the SUPER FRZ (Super Freezer) button once, and then the quick freeze operation starts with the lamp lit. •... -
Page 22: Miracle Zone
Operation Miracle Zone • By pressing the button, store vegetables, fruits (at Temperature relatively low conservation temperature) or other types of food such as meat to be defrosted, raw fish, etc. Transition Corner Method to Use • You can select optimum temperature range depending on types of food stored. -
Page 23: Ice Making
Operation Ice Making • Fill water in ice making box of the ice making corner. Only fill with enough water to maintain individual ice cubes. If over filled, the cubes will not separate when harvested resulting clumps. Water may also spill over causing cubes in ice bin to clump. -
Page 24: Storing Food
Suggestions on food storage Storing Food • Do not store food which goes bad easily at low CAUTION temperature, such as banana, and melon. • Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills. - Page 25 Suggestions on food storage • To ensure good air circulation in the appliance, insert the freezer drawers all the way. • If large quantities of food are to be stored in the freezer, a middle drawer of freezer compartment can be taken out of the appliance and the food can be stored directly right over the food stacked from the lower drawer.
-
Page 26: Care And
Care and Maintenance General Information Power Failure • 1~2 hour power failure does no harm to the foods stores. Try to avoid opening and closing the door too frequently. If You Move • Take out foods from the fridge-freezer and firmly fix the loose items with tape. -
Page 27: Lamp Replacement
Care and Maintenance Lamp Replacement Unplug the power cord from the outlet or shutdown the main switch in your house. Remove the room lamp lid by pulling on the back of the lamp cover then pivot down on front edge. Remove the lamp by turning it counterclockwise and replace new one. -
Page 28: Cleaning
Care and Maintenance Cleaning Before Cleaning Be sure to unplug the power or shutdown the main switch in your house. Clean the outside of the fridge-freezer with a hot damp Exterior cloth with or without cleaning detergent. If you use a detergent, be sure to wipe it with a clean wet cloth. -
Page 29: Trouble Shooting
Trouble Shooting Before calling for service, check this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Problem Possible Causes • Power plug may be unplugged from the electric Fridge-Freezer outlet. - Page 30 Trouble Shooting Problem Possible Causes • Door opened too frequently or for to long a period. Moisture collects • In humid weather, air carries moisture into fridge when inside doors are opened. • Foods with strong odors should be tightly covered or Fridge has door wrapped.
- Page 31 LG Customer Information Center LG Twin Tower, 20, Yoido-Dong, Printed in Korea Youngdungpo-Gu, Seoul, 150-721, Korea.
- Page 32 Model: Built-in Refrigerator GR-N309/319 Installation Manual Встроенный холодильник Руководство по монтажу Вбудований холодильник Посiбник зi встановлення Ò Ò î î ’ ’ à à ç ç û û ò ò ” ” û û ø ø Î Î ð ð í í à à ò ò ó ó æ æ ‡ ‡ í í ³ ³ í í ä ä å å ã ã ³ ³ í í ‰ ‰ ñ ñ ” ” à à ó ó ë ë û û ” ”...
- Page 34 Contents 1. Caution Before Installation ............3 2. Installation Parts................. 4 3. Block Diagram and Assembly ........... 5 4. Dimensions of Refrigerator and Cabinet ........6 5. Installation Environment for Built-in Refrigerator ......7 6. Order of Installation 1) Preparation Work Before Installation of Refrigerator....8 2) Case-related Work After Inserting Refrigerator ......
-
Page 35: Caution Before Installation
1. Caution Before Installation CAUTION Product must be installed in a location away from heat sources such as heaters and hot-water systems. Must also be installed in a location away from direct sunlight. Installation location must have adequate ventilation. Prepare cabinetwork in accordance with the instructions to assure adequate ventilation. -
Page 36: Installation Parts
2. Installation Parts Parts prepared Top cover Hinge stand Depth adjust Bracket Depth adjust Bracket before installing (hole size = 5.5mm) (hole size = 8mm) cabinet case 1 unit units units units Hinge cover Bracket case cover Bracket case Case cover Parts related with case after inserting product... -
Page 37: Block Diagram And Assembly
3. Block Diagram and Assembly... -
Page 38: Dimensions Of Refrigerator And Cabinet
4. Dimensions of Refrigerator and Cabinet The overall thickness of this figure is based on m i n 15mm. m i n 4 0 0 5 0 m The dimension of cabinet must correspond to that of figure. m i n m i n 4 0 0 5 0 m... -
Page 39: Installation Environment For Built-In Refrigerator
5. Installation Environment for Built-in Refrigerator Construct the cabinet work in accordance with these dimensions to guarantee adequate ventilation for reliable heat exchange for product. 1. There must be unobstructed pathways for air circulation to enter through bottom inlet and escape through upper outlet. -
Page 40: Order Of Installation
6. Order of Installation 1) Preparation Work Before Installation of Refrigerator 1. Installation of refrigerator top cover 1). Pre-fold the top cover of refrigerator, refer to the drawing to the right. 2). Fix the refrigerator top cover with the wood bolting screw (3 places) at a point 45mm in from interior edge of cabinet at each end and also in the... - Page 41 6. Order of Installation 1) Preparation Work Before Installation of Refrigerator 1. Assembly bracket (Fig. 1) Tilt to back Tighten the screw 2. Assembly cover (Fig. 2) Tighten the screw After separating the double firmly. sided tape, tighten the screw firmly. There is no hole for screw on the outer cabinet.
-
Page 42: Case-Related Work After Inserting Refrigerator
6. Order of Installation 1) Preparation Work Before Installation of Refrigerator 2. Insert the hinge stand into the hinge (4places) as in the below figure (See figure 3) (Don’t insert the hinge stand when thickness of the cabinet material is 20mm.) 3. - Page 43 6. Order of Installation 2) Cabinet-related Work After Inserting Refrigerator 6. Adjust both verticality and horizontality by turning the horizontal adjusting leg ( of refrigerator. When the unit tilts backwards. Adjust by turning the horizontal adjusting leg anti-clockwise since the refrigerator leans backward.
- Page 44 6. Order of Installation 2) Case-related Work After Inserting Refrigerator 7. Check that the end of the hinge stand corresponds to the right front side of the cabinet. 8. Fix the hinge with the wood bolting (Fig. 5) screw (8places) (See Figure 5). Be careful when working on hinges as you may be injured by the hinge operation if the door moves.
-
Page 45: Work Related With Integrated Door Panel
6. Order of Installation 3) Work Related with Integrated Door Panel. 10. Place the paper jig on the standard line (see reference) on the back of the integrated door panel (See Fig. 7). Reference For the door of the fridge: Place the paper jig at the point away 912 mm from the underside of the fridge integrated door panel. - Page 46 6. Order of Installation 4) Work Related with the Freezer Door 13. Hang the top bracket of the integrated door panel on the height adjusting screw of the door top part after inserting the height adjusting nut (2 places) on to the height adjusting screw.
- Page 47 6. Order of Installation 4) Work Related with the Freezer Door 17. After positioning the depth adjust bracket as in Figure 13, fix it with the hinge adjust screw (2 places) and then fix it with the top bracket bolting screw (4 places) (See Figure 13).
- Page 48 6. Order of Installation 5) Work Related with the Fridge Door 20. After inserting the height adjust nut (2 places) into the height adjust screw, hang the top bracket of the integrated door panel on the height adjust screw on the top part of the refrigerator door.Loosely tighten the height adjust nut (2 places) (See Figure 16).
- Page 49 6. Order of Installation 5) Work Related with the Fridge Door 25. After positioning the depth adjust bracket as in Figure 19, fix it with the hinge bolting screw (2 places) and then fix it with the top bracket bolting screw (4 places) (See Figure 19).
-
Page 50: Installation Check And Finishing Work
6. Order of Installation 6) Installation Check and Finishing Work 28. Insert the hinge front cover into the front part inside the hinge (4places). 29. Insert the air path cover into the square cloth support. 30. After cutting the gasket suit the interval, attach it as in Figure 22, use the gasket the hinge side, the gasket... -
Page 51: Change Of Door Open Direction Of Refrigerator
6. Order of Installation 7) Change of Door Open Direction of Refrigerator Perform work for changing the door before installation. 1. Loosely release the screws of the hinge on the case part of the freezer and then separate the door by pushing it to the right (See Figure 23). - Page 52 P/No.: 3828JD8684N...
