Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-05630A...
Page 2: Table Of Contents
Choose from the options below: ◊ Visit us on the web at www.cubcadet.com ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write to Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019...
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING! This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
Page 4 A missing or damaged discharge cover can cause blade Slope Operation contact or thrown object injuries. Slopes are a major factor related to loss of control and tip-over Stop the blade(s) when crossing gravel drives, walks, or accidents which can result in severe injury or death. All slopes roads and while not cutting grass.
Page 5 Service Children Tragic accidents can occur if the operator is not alert to the Safe Handling of Gasoline: presence of children. Children are often attracted to the machine and the mowing activity. They do not understand To avoid personal injury or property damage use extreme the dangers.
Page 6: Spark Arrestor
Do not modify engine Periodically check to make sure the blades come to complete stop within approximately (5) five seconds after To avoid serious injury or death, do not modify engine in any operating the blade disengagement control. If the blades way.
Page 7: Safety Symbols
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate DANGER—...
Page 8 2 — i ectiOn MpOrtant peratiOn ractices...
Page 9: Assembly & Set-Up
Assembly & Set-Up Contents of Crate • One Lawn Tractor • One Oil Drain Tube • One Deck Wash Hose Coupler • One Lawn Tractor Operator’s Manual • One Kohler Engine Operator’s Manual Tractor Set-Up Shipping Brace Removal WARNING! Make sure the lawn tractor’s engine is Moving The Tractor Manually off, set the parking brake and remove the ignition Your tractor’s transmission is equipped with a hydrostatic...
Page 10 Connecting the Battery Cables Checking Tire Pressure WARNING! CALIFORNIA PROPOSITION 65 WARNING! Do not overinflate tires. Check sidewall of tires for maximum psi. Equal tire pressure should Battery posts, terminals, and related accessories be maintained at all times. contain lead and lead compounds, chemicals known to the State of California to cause cancer and The tires on your tractor may be over inflated for shipping reproductive harm.
Page 11 Adjusting the Seat To adjust the position of the seat, pull up and hold the seat adjustment lever. Slide the seat forward or rearward to the desired position; then release the adjustment lever. Make sure seat is locked into position before operating the tractor. See Fig.
Page 12: Controls & Features
Controls and Features Systems Indicator Monitor Fuel Tank Cap Ignition Switch Module Throttle/Choke Control Fuel Level Indicator Drive Pedal Brake Pedal Reverse Pedal Parking Brake/ Cargo Net Cruise Control Lever Deck Lift Lever Seat Adjustment Lever PTO (Blade Engage) Handle Storage Bin Cup Holder Figure 4-1...
Page 13 Charge the battery as instructed in the Service section of this manual or have the charging system checked by your Cub Cadet dealer. Cargo Net The cargo net is located on the lower half of the dash and can be used for storage.
Page 14 Fuel Level Indicator The Fuel Level Indicator is located on the left side of the tractor’s dash and indicates the amount of fuel in the gas tank. PTO/Blade Engage Handle Activating the PTO engages power to the cutting deck or other (separately available) attachments.
Page 15: Operation
If the interlock system should ever WARNING! If you strike a foreign object, stop the malfunction, do not operate the tractor. Contact your Cub Cadet engine and disconnect the spark plug wire(s). dealer. Thoroughly inspect the machine for any damage.
Page 16: Driving The Tractor
Driving The Tractor Reverse Caution Mode WARNING! The REVERSE CAUTION MODE position of the key switch module Avoid sudden starts, excessive speed allows the tractor to be operated in reverse with the blades (PTO) and sudden stops. engaged. NOTE: Mowing in reverse is not recommended. Lightly press the brake pedal to release the parking brake.
Page 17: Engaging The Parking Brake
Driving On Slopes Cruise Control WARNING! Never engage the cruise control lever Refer to the SLOPE GAUGE on page 7 to help determine slopes while traveling in reverse. where you may operate the tractor safely. WARNING! Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1⁄2 To set the cruise control: feet every 10 feet).
Page 18 Engaging the PTO Engaging the PTO transfers power to the cutting deck or other (separately available) attachments. To engage the PTO: Move the Throttle/Choke control lever to the FAST (rabbit) position. Push the PTO/Blade Engage lever forward into the engaged (ON) position.
Page 19: Maintenance & Adjustment
Maintenance & Adjustments Maintenance Schedule Before Every Every Every Every Prior Each use 10 Hours 25 Hours 50 Hours 100 Hours to Storing Clean Hood/Dash Louvers Check Engine Oil Level Check Air Filter for Dirty, Loose or Damaged Parts Clean and Re-oil Air Filter’s Foam Precleaner Replace Air Filter Element Change Engine Oil and Replace Oil Filter Clean Battery Terminals...
Page 20: Spark Plug
Pop open the protective cap on the end of the oil drain Spark Plug valve to expose the drain port. See Fig 6-1. The spark plug should be cleaned and the gap reset once a season. Refer to the Kohler Owner’s Manual for correct plug type and gap specifications.
Page 21 Lubrication Attach the hose coupler to the water port on your decks surface. See Fig. 6-2. WARNING! Before lubricating, repairing, or inspecting, always disengage PTO, set parking brake, stop engine and remove key to prevent unintended starting. Front Wheels Each of the front wheel axles and rims is equipped with a grease fitting.
Page 22 Deck Spindle Determine the approximate distance necessary for proper adjustment and proceed, if necessary. Grease fittings can be found on each deck spindle. See Fig. 6-4. raise the front of the deck, tighten (thread inward) the Lubricate with 251H EP grease or an equivalent No. 2 multi- lock nut against the front hanger bracket.
Page 23: Dealer
Leveling the Deck (Side to Side) Steering Adjustment If the cutting deck appears to be mowing unevenly, a side to side If the tractor turns tighter in one direction than the other, or if adjustment can be performed. Adjust if necessary as follows: the ball joints are being replaced due to damage or wear, the steering drag links may need to be adjusted.
Page 24: Service
Service Cutting Deck Removal NOTE: If there is too much tension on the belt for it to be easily removed from the engine pulley, carefully insert a Place the PTO/Blade Engage knob in the disengaged (OFF) 3⁄8” drive ratchet wrench (set to loosen) into the square hole position and engage the parking brake.
Page 25: Changing Deck Belt
Pull the deck support pin outward to release the deck from Remove the cotter pin from the end of the stabilizer rod the deck lift arm. See Fig. 7-3. and slide the stabilizer out of the hanger bracket on the deck.
Page 26: Cutting Blades
It may also be necessary to loosen the hex nut on the left Place the belt into the engine pulley. See Fig. 7-8. idler pulley to get the belt off the pulley and around the belt guard. Carefully remove the deck belt from around the two spindle pulleys and the two deck idler pulleys.
Page 27: Battery
Place a block of wood between the center deck housing Test the blade’s balance using a blade balancer. Grind baffle and the cutting blade to act as a stabilizer. metal from the heavy side until it balances evenly. See Fig. 7-9. NOTE: When replacing the blade, be sure to install the blade with the side of the blade marked ‘‘Bottom’’...
Page 28: Charging/Fuse/Tires
Changing the Transmission Drive Belt Several components must be removed and special tools used in order to change the tractor’s transmission drive belt. See your Cub Cadet dealer to have the transmission drive belt replaced. 7— s ectiOn ervice...
Page 29: Troubleshooting
Troubleshooting Problem Cause Remedy Engine fails to start PTO/Blade Engage lever engaged. Place lever in disengaged (OFF) position. Parking brake not engaged. Engage parking brake. Spark plug wire disconnected. Connect wire to spark plug. Throttle/Choke control lever not in correct Place Throttle/Choke lever to FAST position.
Page 30: Replacement Parts
Replacement Parts Component Part Number and Description 759-3336 Spark Plug (Champion RC12YC) KH-20-883-02-S1 Air Cleaner Element with Pre-cleaner KH-12-050-01-S Oil Filter KH-25-050-21-S Fuel Filter 942-04312 2-in-1 Deck Blade 918-04889A Drive Spindle Assembly Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
Page 31 Component Part Number and Description 734-04155 Deck Wheel (Front) 734-0973 Deck Wheel (Rear) 925-1707D Battery 751-0603A Fuel Tank Cap 946-04617 Throttle/Choke Control and Cable 925-2054A Ignition Key (Plastic) 631-04344 Discharge Chute Assembly 954-04060B Deck Drive Belt Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
Page 32: Attachments & Accessories
Attachments & Accessories The following attachments and accessories are compatible for Cub Cadet LTX1042. See your Cub Cadet dealer or the retailer from which you purchased your tractor for information regarding price and availability. CAUTION: Cub Cadet Series 1000 lawn tractors are NOT designed for use with any type of ground-engaging attachments (e.g.
Page 33 Notes...
Page 34 FEDERAL and/or CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS MTD Consumer Group Inc, the United States Environmental Protection Agency (EPA), and, for those products certified for sale in the state of California, the California Air Resources Board (CARB) are pleased to explain the emission (evaporative and/or exhaust) control system (ECS) warranty on your outdoor 2006 and later small off-road spark-ignited engine and equipment (outdoor equipment engine) In California, new outdoor equipment engines must be designed, built and equipped to meet the State’s stringent anti-smog standards (in other states, 1997 and later model year equipment must be designed, built, and equipped to meet the U.S.
Page 35 WARRANTED PARTS: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the outdoor equipment engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper mainte- nance was the direct cause of the need for repair or replacement of the part.
Page 36 Frame and Front Axle — Cub Cadet warrants the frame, and front cast iron dealer or retailer, with respect to any product, shall bind Cub Cadet.
