OUTDOOR LP HOT WATER HEATER CARE, USE AND
Model HWD5
• To the installer or person assembling this appliance: Leave this manual
with this appliance for future reference.
• To consumer: Keep this manual for future reference. This instruction
manual contains important information necessary for the proper
assembly and safe use of this product.
Read and follow all warnings and instructions before assembling and using
the appliance.
Follow all warnings and instructions when using the appliance.
DO NOT DISCARD THIS INSTRUCTION MANUAL.
For outdoor use only.
FREEZE WARNING
If the outside temperature is
near or below freezing 32F (0C)
ensure that the system is properly
drained. See instructions inside.
0711-HWD5-INSTRUCTIONS
3985 N. 75 W. • Logan, UT 84321 • 1.800.650.2433 • www.campchef.com
SAFETY INSTRUCTIONS
CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals known
to the State of California to cause cancer,
birth defects, or other reproductive harm.
WARNING
Use two wrenches when
connecting the gas regulator
hose to the appliance or damage
to the gas valve may occur.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HWD5 and is the answer not in the manual?

Questions and answers

Related Manuals for Camp Chef HWD5

Summary of Contents for Camp Chef HWD5

  • Page 1 OUTDOOR LP HOT WATER HEATER CARE, USE AND SAFETY INSTRUCTIONS Model HWD5 • To the installer or person assembling this appliance: Leave this manual with this appliance for future reference. • To consumer: Keep this manual for future reference. This instruction manual contains important information necessary for the proper assembly and safe use of this product.
  • Page 2 or non-perscription drugs may DANGER impair your ability to properly Install and properly vent the water assemble or safely operate this appliance. heater. Failure to properly install 4. For OUTDOOR use only. Do NOT the water heater in this manual use in a building, garage or any can result in unsafe operation of other enclosed area.
  • Page 3 Stay clear from flames. • Never use LP tank if visibly rusted, 12. This product is not intended for damaged, or out of date. commercial use. • The regulator may make a 13. Should overheating occur or the humming or whistling noise during gas supply fails to shut off turn operation.
  • Page 4 cause a fire resulting in death or (tall) with 20 lb. (9 kg.) capacity serious injury. maximum. • If you see, • LP tank must be constructed smell, or hear and marked in accordance with escaping gas, specifications for LP tank of the immediately U.S.
  • Page 5 overfill. Immediately close LP tank Damage to gas train components valve and call local LP gas dealer can result. Brush soapy solution for assistance. onto all weld seams and entire • Do not release liquid propane (LP) valve area. gas into the atmosphere. This is a WARNING hazardous practice.

  • Page 6: Head Assembly

    the bottom of the shown and install the connector appliance labeled fitting to one end of the stand. water output. Hand B. Connect the tighten only. Attach two sides the garden hose to this of the stand RUBBER GASKET connection. Make sure together as the garden hose has a rubber gasket shown.
  • Page 7 the end of the hose. check feature in LP tank valve, • Use two adjustable wrenches resulting in some resistance. or 3/4” and 7/8” wrenches for An additional one-half to three tightening the hose to the brass quarters turn is required to valve of the appliance.
  • Page 8 proceeding. 4. Brush soapy HOSE CHECK solution onto • Before each use, check to see if indicated hoses are cut or worn. Replace connections damaged hose assembly before shown at right. using appliance. Use only valve/ 5. If “growing bubbles appear, hose / regulator specified by there is a leak.
  • Page 9 Adjust the temperature of the DRAINING THE SYSTEM water by first increasing the heat The appliance must be properly valve. If a hotter temperature is drained if exposed to freezing desired decrease the water flow temperature. To drain first by adjusting the water valve. disconnect the water inlet and the shower hose WARNING...
  • Page 10 requires a minimum of 1 quart of the front cover. This is the only water per minute flowing through screw you need to remove. All the system at a minimum pressure of the wiring is done with push of 25 psi before it will ignite the together plastic connectors.

  • Page 11: Limited Warranty

    Warranty does not cover normal wear of parts or damage caused by misuse, abuse, overheating and alteration. Repairs or alterations made by anyone other than Camp Chef are not covered in this Warranty. Manufacturer will not be held liable for any losses due to neglectful operation. Furthermore, this...

  • Page 12: Maximum Flow

    • Uses 2 D batteries for ignition (not included) • 1 standard LP tank is good for approx. 18 hrs. of continuous use, depending on set temperature MAXIMUM FLOW 1 ½ Gallons/Min (Raises water temperature 38°F MINIMUM FLOW ½ Gallon/Min (Raises water temperature 102°F 1210-HWD5-Instructions...
