Indoor Dual-Streaming
CCD Network Camera
UNC7702-Series User's Manual
Version: 1.0
Date: 05/030/2008
Copyright EUSSO Technologies, Inc. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNC7702 and is the answer not in the manual?

Questions and answers

Related Manuals for Eusso UNC7702

Summary of Contents for Eusso UNC7702

  • Page 1 Indoor Dual-Streaming CCD Network Camera UNC7702-Series User’s Manual Version: 1.0 Date: 05/030/2008 Copyright EUSSO Technologies, Inc. All rights reserved...

  • Page 2: Table Of Contents

    CHAPTER 1 INTRODUCTION............................. 2 ? ..............2 HAT IS TREAMING ETWORK AMERA IDEO ERVER ................................. 3 EATURES CHAPTER 2 PHYSICAL IMAGES ..........................4 UNC7702 N ............................4 ETWORK AMERA CHAPTER 3 INSTALLATION............................5 ..........................5 ARDWARE CONNECTION ..........................6 OFTWARE NSTALLATION ..........................7...

  • Page 3: Chapter 1 Introduction

    Intranet/Internet as the result of capable being recorded. UNC7702 has 2 USB 2.0 host ports; with external storage connected the video/audio can be recorded locally. For power solution, while normal adapter is applied for both devices the UNC7702 also comes with an optional PoE model.

  • Page 4: Features

    2. Features Self-Contained Web Server providing Internet capability for remote access MPEG-4/MJPEG dual compression formats Simultaneous MPEG-4 and MJPEG stream for multiple clients Supports up to 30/25 FPS at Full D1 resolution More than 540 TV lines resolution Built-in internal microphone Event handling trigger by alarm/motion and action to send video clip by Email / FTP Two USB 2.0 Host ports support external storage connection for local recording Wireless USB dongle (IEEE 802.11b/g) compliant (to be upgraded)

  • Page 5: Chapter 2 Physical Images

    Chapter 2 Physical Images UNC7702 Network Camera...

  • Page 6: Chapter 3 Installation

    Installation 1. Hardware connection Prepare a PC with Ethernet link to the network Connect UNC7702 device to the network hub/switch with standard pass through (CAT5) cable, or connect directly to PC with a cross over cable. Connect power jack Ensure the power adapter specification matches the power system (110V or 220V). Connect the adapter to the outlet.

  • Page 7: Software Installation

    2. Software Installation The following software is necessary for the proper display and use of the UNC7702 from the Web site. The software will be taken from the Software Package CD. IP Installer The IP Installer is used to locate and configure network cameras and video servers on the LAN. This utility is useful for conveniently configuring the network settings of the device, or for finding a device once the network settings have been modified.

  • Page 8: Network Configuration

    *0004290000 Although the IP Installer is able to find and configure any UNC7702 on the LAN except those that are behind a router, it is a good idea to set the host PC to the same subnet. In order to connect to the Web-based user interface of UNC7702, the host PC must be in the same subnet.
  • Page 9 Click the menu bar Tool > Search Net work Device to search the device in the LAN. From the list, select the device with the MAC Address that corresponds to the UNC7702 that is to be configure d. The MAC Address is identica l to the unit’s S/N (Serial Number).
  • Page 10 After filling in the properties, click [Synchronize] button to complete the configuration settings in the remote UNC7702 while saving configuration in the PC. If click [OK] button, the configuration is only be saved in the PC. Open the Web-based UI of the Selected UNC7702 To access the Web-based UI of the selected unit, run the View >...
  • Page 11 Set the security level to Low and click [OK]. Type the URL or IP address of your UNC7702 into the Address field. A dialog box will pop up asking if the ActiveX control should be installed. Click [Yes] to start the installation.

  • Page 12: Chapter 4 Using The Web Ui

    Chapter 4 Using the Web Start your Web browser and enter the URL or IP address in the Address field. The Home page of the UNC7702 is now displayed. The status of the video stream The display of channel information can be...

  • Page 13: Live View

    1. Live View Functions in live view page The following are the available keys in the Live View mod Button Description Select the display language for web user interface Check “Actual Size” to display the video stream at the actual resolution Check “Audio”...
  • Page 14 Go to the Configuration page for setup Note: The user that log in with user account* won’t have an access to this page UNC7702 user setting can be categorized in three groups, the Admin, operator and user. Detail description can be found in Co...
  • Page 15 P/T/Z Control for Dome Camera The following are the available key s to control the PTZ dome camera: Button Description Select the preset point for quick view or setup Click on the arrow buttons to move the camera to that direction Click on the rectangle button to stop the movement Zoom out the video Zoom...

  • Page 16: Playback

    2. Playback To play back the recorded file, click the button in Home page. Button Description This will be displaying playback status include the speed of playing, playing mode and name of the controlling user. Select “Record HDD” or “Backup HDD” to search for the recorded file.
  • Page 17 Close this panel The start and end time of the all video recording Status of control playback The start time of the recordi ng you can manual input or click calendar to play You can click this to change play time You can click this to increase of number or press button of “Shift”...
  • Page 18 Playback Screen Controller ’s View...
  • Page 19 PC while viewing. This is a handy function for that hen a user is far away from UNC7702 but needs an actual copy of recorded video file. . Set a path to store the video. Click on [Record setting] button. A setting panel will be expanded and shown.
  • Page 20 2. Press on the red button [Record], the playback video will be saving to the path set previously. 3. Besides save playback video, user can also snapshot an image from the video. The operation is identical to operating in the live page.
  • Page 21 The following are the available keys to control the playback: Button Description Rotation: Rotate the playback images. Record: Record the playback video while viewing. Same operation as in live page. Snapshot the playback video. Play / Pause / Resume the playback Back to 1X speed for playback Stop the playback and exit the Playback function Fast forward / Rewind the playback.

  • Page 22: Configuration Page

    3. Configur ation page Click “Config” icon to open the Co nfigure Page Video: Set up the resolution and quality for recording and live view, and the schedule recording Camera: Setup video parameters, PTZ settings for cameras Event: Setup for event trigger System: Setup for system including date/time, user, COM port and commands etc.

  • Page 23: Chapter 5 Configure The Settings With Web Ui

    Chapter 5 Configure the Settings with W eb UI 1. Sub items Video: Camera: Event: System: Network: Storage: Log List:...

  • Page 24: Video Setup (Available For Administrator Only)

    2. Video Setup (Available for Administrator only) Video Setup Total IPS: Set Total IPS in the daytime, nighttime and on weekends, up to 30 for each time period. When stream 2 is e nabled, the IPS for stream 1 and 2 can be configured. Stream 1 IPS: Set IPS for Stream 1 out of 30.
  • Page 25 choosing lower number.. Video Bitrate: When choosing CBR for the video mode, video bi trate can be selected among 64 Kbps, 128 Kbps, 256 Kbps, 512 Kbps, 768 Kbps, 1 Mbps, 1.5 Mbps, 2 Mbps, 3 Mbps and 4 Mbps. Event action: Choose Motion (motion detection), Sensor (sensor triggering) or Both (enable both types) for the event action.

  • Page 26: Camera Setup

    3. Camera Setup General Setup Brightness: Adjust the brightness for each channel from -100 to +100. Contrast: Adjust the contrast for each channel from -100 to +100. Saturation: Adjust the saturation for each channel from -100 to +100. HUE: Adjust the hue for each channel from -100 to +100. BLC: Enable/disable BLC (Back Light Compensation) function.

  • Page 27: Ptz Setup

    PTZ Setup PTZ Setting: Remove: No dome camera is connected to this channel. Add: A dome camera is connected to this channel. PTZ Protocol: Various protocols can be selected, including PELCO P, PELCO D, LI-LIN and Dynacolor. PTZ ID: The ID number must match the ID address set by the dome camera. Speed: Select the control speed from 1 ~ 10.
  • Page 28 OSD Setup OSD Display: Check the check box to display the following messages on the video of each channel. Note: The settings work with this client PC only; it w on’t affect the other PC and the video device. Status Display: Display the video status (Live or Playback video). Channel Di splay: Display the channel number of each channel.

  • Page 29: Event Setup

    Alarm IN is triggered. The event icon will be displayed on the video output of UNC7702; it won ’t be displayed on the web UI. Event Duration: Set the duration time for recording after the event goes a way.

  • Page 30: Motion Setup

    Motion Setup Motion config: Define parameters for actions responding to detected motion. Motion Detect: Set the Motion Detect feature for each channel to “ON” or “OFF”. Pass Alarm: Adjust this option to determine the ending time of video clip after the event goes away. The unit is in seco Email Notice: Enable or disa ble the Email notice when motion detection is triggered.
  • Page 31 Sensor config: Apply the sensor relays as trigger. Define the actions/parameters responding to sensed event. Alarm in: select one of the four GPINs as a sensor for the event triggering. Normal state: set the relays’ initial status. Pass alarm: as described in motion config. Email notice: send email responding to a sensed event Email attachment: se nd email with attached video file.
  • Page 32 Video loss confi Set actions responding to the event that video is missing, such as line has been cut or camera has been crashed. Video loss detect: on/off this function. Email notice: as described in previous two items. CGI alert: as described in previous two items.

  • Page 33: Motion Area Setup

    Motion Area Setup Select All: Clear all areas for motion detection. Clear All: Select all areas for motion detection. Set: Confirm the settings. ove mouse to point the area, left-click mouse to set the area for motion detection; left-click the selected rea again will clear the area for detection.
  • Page 34 GPIO Setup Displays the GPIO input/output statues. Can manually adjust the statues of GPIO output by clicking on the check box.

  • Page 35: System Setup

    5. System Setup General Setup Unit Name: Assign a name for the device. Model: The model name of the device. Hardware Version: The version of the hardware. Software Version: The version of the software. Firmware Version: The version of the firmware. Apply: Confirm the settings.
  • Page 36 Date/Time Setup et the year, date and time for the device. DST Enable: If your region use daylight sav ing time, set the item to “ON”. Bias: Set the amount of time to move fo rward from the standard time for daylight saving time. Start: Set the beginning date/time of the daylight s aving.
  • Page 37 User Setup (Available for Administrator onl Enable Authentication: S elect “YES” to enable the password authentication. User name / Password: Up to 15 accounts can be ad ded for accessing this device. The account name and password can be flexible (but restricted in 8 characters long of any com bination of 0-9 and A-Z).
  • Page 38 COM Port Setup COM Status: Set COM port for PTZ, RS-232 or RS-485. PTZ ID: The number must match the ID address set by the dome camera. Baud Rate: Set the value if necessary. Data Bit: Set the value if necessary. Stop Bit: Set the value if necessary.

  • Page 39: System Information

    System Information Display the information of this device. Information includes video port, resolution video type, bit rate, PTZ model/status, motion status, sensor status and Active X version. System Audio System audio enable and adjustment; Mute check box to silencing, V olume r the sound volume adjustment.

  • Page 40: Network Setup

    6. Network Setup General Setup Ethernet Mode: If using static IP, set to “Static” and then setup the following settings. If there is a DHCP server on the netw ork, set to “D HCP”, the device will get the following settings from the server automatically.

  • Page 41: Ddns Setup

    DDNS Setup Dynamic DNS Settings 1: DDNS Enable: DDNS allows the dynamic IP address to be registered so others can connect to it by a domain name. If you wish to use DDNS service and set to “ON”. Host Name: As sign a host name for the device, this name will be the domain name.

  • Page 42: Email Setup

    DDNS Enable: As in settings 1 mentioned. Host Name: As in settings 1 mentioned. Account ID: For rver needs an account to log in, the field here is then for the account identification. Password: password fo r the account to log in. Update Time: As in settings 1 mentioned.

  • Page 43: Ftp Setup

    FTP Setup FTP enable: Set to “ON” if use a FTP server to receive the event notification. Server IP: Enter the IP address of the FTP server. User Name / Password: The account name and password to login the FTP server. Storage Path: Path of the FTP site to put the file.

  • Page 44: Storage Setup

    7. Storage Setup Storage USB Setup Display the information and status of the storage devices that connected to UNC7702. Active: represents the disk will act as a “Record” or “Backup”, or “Off” as taking no action. Action: shows the disk’s mount status.
  • Page 45 Weekend Schedule: W hen set to “ON”, the weekend schedule will be enabled. Weekend Start Week / Time: Set the beginning day and time of the weekend. Weekend End Week / Time: Set the ending day and time of the weekend. Overwrite Recording: W t to “ON”, if the record HDD is full, the recording will overwrite the earliest recorded file in the HDD.

  • Page 46: Log List

    Log List List...

  • Page 47: Appendix A Specifications

    Appendix A Specifications UNC7702 System Embedded Linux, 32-Bit RISC Processor, 8MB Flash ROM, 64MB SDRAM Video Compression MPEG-4 / MJPEG, Dual streaming Full D1: NTSC = 720 x 480; PAL = 720 x 576 Video Resolution Half D1: NTSC = 720 x 240; PAL = 720 x 288 CIF: NTSC = 352 x 240;...

  • Page 48: Appendix B The Mini-Din Connector

    Appendix B The Mini-din Connector The mini-din connector provides control signal input and output, which includin g GPIO input, GPIO output as Relay connection and one RS-485 port multiplex with COM port . It also provid es connection of PTZ device and external console to control the devi COM / GPIO MINI-DIN FUNCTION...
  • Page 49 GND (System Ground): System Ground is also connected to chassis as frame ground. GPOUT-Automatic Relay: When enable to use the GPIN or motion detection to trigger some alarm 　 devices, the “Relay” must be turned on. Video Out: Use the especial cable in the product pac kage to connect this pin that it can output the video to the monitor.

  • Page 50: Appendix C Faq

    Insert a pin into the reset hole as circled with red in the below figures. Sense a button and keep it pressed until instructed to release. Plug in the power jack to turn on UNC7702, count 25 seconds (at least 20 seconds) and release the button (remove the pin from the reset hole).

  • Page 51: How To Upgrade Firmware For The Device

    Caution: You must reboot the device before doing the following procedures; otherwise, some occa ional internal conflicts may endanger the Flash devices. art the FTP session and log in to the UNC7702. For exampl e, in our case for Windows XP: Enter DOS by "...
  • Page 52 Note: Flash products can become damaged if the updating operation is not performed correctly. So please follow up above procedures carefully.

  • Page 53: Why Active Xremains In Old Version After Upgrading To New Version Firmware

    3. Why ActiveX remains in old version after upgrading to new version firmware? ANS: Launch an IE browser and click on “Tools” -> “Internet Options”. The Internet Options window then shows up.
  • Page 54 In Temporary Internet files, click on Delete Files. Press “OK” to confirm deletion. Re-open IE browser and access to the device. You will this time be prompt to install newer version of ActiveX ontrol. After installation, you should see the new version installed.
