Hotpoint HNXRP070 Owner's Manual

Hotpoint HNXRP070 Owner's Manual

Hide thumbs Also See for HNXRP070:
Table of Contents

Advertisement

Quick Links

Settings . . . . . . . . . . . .4-6
Features . . . . . . . . . . . . . .7
the Washer . . . . . . . . .8-11
Stain Guide . . . . . . .10, 11
For Service . . . . . . . .12-14
Deleted web
address
. . . . .3
Numbers . . . . . . . . . . . .16
Warranty . . . . . . . . . . . .15
Washers
Owner's Manual
HNXRP070
HNSR2120
HNSRP080
175D1807P457 39-90190
08-03 JR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HNXRP070 and is the answer not in the manual?

Questions and answers

Related Manuals for Hotpoint HNXRP070

Summary of Contents for Hotpoint HNXRP070

  • Page 1: Table Of Contents

    Safety Information Customer Service ..3 Owner’s Manual Service Telephone HNXRP070 Operating Instructions Numbers ... .16 Control Panels and HNSR2120 Warranty ... .15 Settings .
  • Page 2 A Service Partnership. IMPORTANT! Staple sales slip or cancelled check here. Proof of the original purchase date is needed to obtain service under the warranty. FOR YOUR RECORDS Write the model and serial numbers here: You can find them in the upper right corner on the back of your washer. READ THIS MANUAL Inside you will find many helpful hints on how to use and maintain your washer properly.

  • Page 3: Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more.

  • Page 4: Operating Instructions Control Panels And Settings

    Find your washer control panel (models HNSRP080 and HNSR2120). You can locate your model number behind the top edge of the control panel. Model HNSRP080 Model HNSR2120...

  • Page 5: Settings

    About the control settings (models HNSRP080 and HNSR2120). Load Size Loosely load clothes no higher than the top row of holes in the washer basket. The water level should just cover the clothes. Adjust the load size accordingly. Wash/Spin Speed (on some models) The agitator moves clothes around for a cleaner wash;...

  • Page 6: Settings

    Find your washer control panel (models HNXRP070). You can locate your model number behind the top edge of the control panel. Model HNXRP070 About the control settings (model HNXRP070). Load Size Loosely load clothes no higher than the top row of holes in the washer basket. The water level should just cover the clothes.

  • Page 7: Features

    About washer features. NOTE: Not all features are available on all washer models. Liquid Bleach Dispenser (on some models) The dispenser dilutes liquid chlorine bleach before it reaches your wash load. Check clothing care labels for special instructions. Measure liquid bleach carefully, following instructions on the bottle. Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.

  • Page 8: Loading And Using The Washer

    Loading and using the washer. Always follow fabric manufacturer’s care label when laundering. Sorting Wash Loads Sort by color (whites, lights, colors), soil level, fabric type (sturdy cottons, easy care, delicates), and whether the fabric produces lint (terry cloth, chenille), or collects lint (velveteen, corduroy). Proper Use of Detergent Add detergent as the wash basket fills with water, before you load clothes.

  • Page 9: The Washer

    Care and Cleaning of the Washer Wash Basket: Leave the lid open after washing to Exterior: Immediately wipe off any spills. Wipe with allow moisture to evaporate. If you want to clean the damp cloth. Try not to hit surface with sharp objects. basket use a clean soft cloth dampened with liquid Moving and Storage: Ask the service technician detergent, then rinse.

  • Page 10: Stain Guide

    Loading and using the washer. Always follow fabric manufacturer’s care label when laundering. Removing Specific Stains Bleach Solution: To remove stains on white or bleachable fabrics, try soaking the stained area in a container for five minutes in the following solution and then launder in the washer: I 1 US gallon (3.8 liters) cool water I 1/4 cup (60 ml) chlorine bleach...
  • Page 11 STAIN White and Bleachable Fabrics Other Washable Fabrics Grass, mildew, scorch Apply undiluted liquid detergent; • Sponge with warm water. Apply undiluted liquid launder. (Treat mildew spots detergent; launder. Bleach with non-chlorine bleach; while they are fresh, before mold launder. Old mildew cannot be removed. Scorch can seldom be removed.

  • Page 12: Troubleshooting Tips

    Before you call for service… Troubleshooting Tips Save time and money! Review the charts on the following pages first and you may not need to call for service. WATER Possible Causes What To Do Too many suds • Switch to a lower sudsing detergent brand and follow Type of detergent instructions on package.
  • Page 13 OPERATION Possible Causes What To Do Washer pauses during The washer normally pauses wash cycle between washing steps Washer pauses during • The washer may pause during the spin cycle to remove This is normal spin cycle soapy water more efficiently. Washer won’t operate •...

  • Page 14: Before You Call

    Before you call for service… PERFORMANCE (cont.) Possible Causes What To Do Pilling • While this is not caused by the washer, you can slow the Result of normal wear on poly-cotton blends and pilling process by washing garments inside out. fuzzy fabrics Snags, holes, tears, rips •...

  • Page 15: Warranty

    Washer Warranty. All warranty service provided by our Factory Service Centers or an authorized technician. For service, call 1.800.361.3400. For The Period Of: We Will Replace: One Year Any part of the washer which fails due to a defect in materials or workmanship. During this full From the date of the one-year warranty, we will also provide, free of charge, all labor and in-home service to replace the original purchase...

  • Page 16: Customer Service Service Telephone Numbers

    1.800.361.3400 Repair service is close to you. To arrange service for your Hotpoint appliance, all you have to do is call. Parts and Accessories Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA, MasterCard and Discover cards are accepted).

This manual is also suitable for:

Hnsrp080Hnsr2120
