- Page 1 User’s Manual CoolCopyD1AL(DVD-Backup) CoolCopyD 3 CoolCopyD 7...
-
Page 2: Table Of Contents
1.3 Specifications ...4 Chapter 2 Installation Procedure 2.1 Controller only ...….…...5 2.2 Whole duplicator without writer installed ..…...5 2.3 Completed duplication system ...…...5 Chapter 3 Key Functions and Operating Instruction Chapter 4 Function ...…...…9 4.1 Copy ...…...9 4.2 Test ...…..…9 4.3 Test&Copy ...…...…...10... - Page 3 4.11.15 Quick Erase ...23 4.11.16 Full Erase ...23 4.12 Adv Setup...24 4.12.1 UnderRun Protect ...…...24 4.12.2 Overburn ...…...24 4.12.3 Read Error Skip..…..…..24 4.12.4 Format Hard Disk ...…...24 4.12.5 Verify HDD ...…...…...25 4.12.6 Burn-in...…...…...25 4.12.7 Update Firmware...…...25 4.12.8 Compare Firmware ...…...26 4.12.9 H/W Diagnostic ...…..26...
-
Page 4: Chapter 1 Introduction
DVD-ROM (Mode1 & Mode2), DVD-ROM/XA (Mode2 form1 & form2), DVD-DA, Mixed-Mode, Video DVD, DVD-I, Karaoke CD, Photo CD (Single & Multi- session), CD-Extra, HFS, CD Bridge, ISO9660, CD-R, and DVD+RW Copyright©2005 ILY Enterprise, Inc. All rights reserved. 5VB+/- 5% 0.5A Max. 0˚ C to 70˚ C -20˚... -
Page 5: Chapter 2 Installation Procedure
Check the entire unit to see if there are any problems. • Make sure that the voltage setting is correct. • The hard drive is optional. Hardware Connection of CoolCopyD1AL (DVD-Backup) without a HDD CoolCopy1AL (CD-Backup) Copyright©2005 ILY Enterprise, Inc. All rights reserved. DVD+/-RW DVD-ROM Power... - Page 6 When the system connects with the hard drive, the hard drive must connect on the IDE 0 port with the “Master” setting and the DVD-ROM must set at “Slave”. Hardware Connection without Hard Drive for CoolCopyD3 Coolcopy 3 Copyright©2005 ILY Enterprise, Inc. All rights reserved. IDE 3 DVD+/-RW IDE 2...
- Page 7 When the system has a hard drive connected, the hard drive must connect on IDE 0 port with “Master” setting and the DVD-ROM must set at “Slave.” Hardware Connection without Hard Drive for CoolCopyD7 Coolcopy 7 Copyright©2005 ILY Enterprise, Inc. All rights reserved. IDE 4 DVD+/- IDE 3...
-
Page 8: Chapter 3 Key Functions And Operating Instruction
Detect Drives... 1. Copy Two main operation procedures If you install a 3.5” hard disc, the operation procedures is as the following screen shows: 1. With hard drive installed • Once duplicator detects a hard disc, it will ask if you want to format or not. A 10GB hard disc can be divided into 10 partitions. -
Page 9: Chapter 4 Function
During the duplication process do not press any button because interruption will harm the device. DVDs will be damaged. 2. Without a hard drive installed If you don’t install a 3.5” hard disc, the operation procedures will be as follows: • Place the master disc in the DVD-ROM. -
Page 10: Test&Copy
Stopping the test halfway does not affect the DVD discs. However, if the DVD rewriteable discs contain important data, the information may be erased. 4.3 Test&Copy Function 3 Test & Copy is to test first and then actually copy. Select Function 3. Put a source DVD into DVD-ROM and blank DVD discs into the writers. -
Page 11: Compare
If the master disc can be read correctly, the source DVD will have no problems. The LCD will show the following screen: Copyright©2005 ILY Enterprise, Inc. All rights reserved. 5. Compare Compare-24X 0% 650.0MB 74:00... -
Page 12: Disc Info
4.9 Image Function 9, Image, is only valid when you have installed a hard drive. Select function 9. Press ENT. Copyright©2005 ILY Enterprise, Inc. All rights reserved. PreScan Fail! 7. Disc Info Total 02 Sessions Total 10 Tracks... -
Page 13: Load
The LCD will show the total sessions and tracks in the partition. Press ENT again. The LCD will show the total time and capacity in the hard drive of partition. Copyright©2005 ILY Enterprise, Inc. All rights reserved. 9-01.Image P: A Load Load- A -24X 0% 650.0MB 74:00... -
Page 14: Compare Image
After installing a hard disc, the duplicator will format it automatically. Each partition occupies 1GB. The number of partitions is dependent on the hard disc’s capacity. The partitions are alphabetically arranged. Copyright©2005 ILY Enterprise, Inc. All rights reserved. Session 01 Track 01 - 01 Track 01 DATA 650.0MB... -
Page 15: Select Src Drive
“+” will appear beside 1/10 as shown. Pressing ENT again will cancel the track. When the track selection is made, use the arrow button to move to the End menu. Copyright©2005 ILY Enterprise, Inc. All rights reserved. Select Working Partition - A Set Partition to 9-06. - Page 16 The system will ask to close the disc session. Use the arrow button to make “Yes” or “No” selection. The LCD will show the closing session as such: Copyright©2005 ILY Enterprise, Inc. All rights reserved. End edit disc and burn?Yes Copying- 24X Edit 1/10 - >...
-
Page 17: Cd To Hd
Follow the LCD to select the track that you want to edit. Here 1/10 means the number one of 10 tracks and 3:25 means the playing time. Press ENT button to select the track. After the track is selected, the “+” will appear. Pressing ENT again will cancel the track. -
Page 18: Play Audio Track
4.10.4 Close Session Select “Close Session” will close the disc and restrict data writing. This function allows discs to be read on any normal player. Copyright©2005 ILY Enterprise, Inc. All rights reserved. Burn or Move to Partition?Burn Copy- P0 -24X 0%... -
Page 19: Setup
This function lets you control the reading speeds of target CDs. Press ENT to enter the setting. Use the arrow button to change the reading Copyright©2005 ILY Enterprise, Inc. All rights reserved. 10-04. Edit Track Close Session Close all disc’s... -
Page 20: Auto Start Drive
DVDs after copying. Press ESC button and arrow to enter the setting. Use the arrow button to change the “On” or “Off” setting. Then press ENT to go back to the 11-07 menu. Copyright©2005 ILY Enterprise, Inc. All rights reserved. 11-04. Setup Auto Start Drive... -
Page 21: Auto Prescan
Track At Once (TAO). Default setting is DAO. Some DVD writers may support different writing methods. If the method selected is not supported, duplicator will automatically switch to the other one. Copyright©2005 ILY Enterprise, Inc. All rights reserved. 11-08. Setup Auto Prescan Auto Prescan 11-09. -
Page 22: Button Sound
ESC to return to the 11-13 menu. Press the ENT button to see the device information and ESC to return to the 11-13 menu. Use the arrow button to select another device or Copyright©2005 ILY Enterprise, Inc. All rights reserved. 11-11. Setup Burn Mode Burn Mode 11-12. -
Page 23: System Info
Press ENT to enter the Full Erase. Use the arrow button to select “Yes” or “No.” Then press ENT or ESC to return to the 11-16 menu. Copyright©2005 ILY Enterprise, Inc. All rights reserved. 03 IDE2 Master DVD+RW : PLEXTOR CD-R PX-W2410A 1.01... -
Page 24: Adv Setup
Use the arrow button to change the setting. Then press ENT or ESC to go back to the 12-03 menu. 4.12.4 Format Hard Disk This function allows you to partition the hard drive. Copyright©2005 ILY Enterprise, Inc. All rights reserved. Erasing disc 03:24 (Full) Full Erase OK:01 Fail:00 12-01. -
Page 25: Verify Hdd
This function will update your firmware to the latest version. Place the DVD disc, which contains the latest firmware data (firmware DVD disc), into the DVD-ROM drive and the duplicator will find Copyright©2005 ILY Enterprise, Inc. All rights reserved. All data will be... -
Page 26: Compare Firmware
12-09 menu. 4.12.10 Load Default This function will reset any previous settings back to the factory’s default setting. Different settings will cause duplicator to react differently. Copyright©2005 ILY Enterprise, Inc. All rights reserved. 12-07. Adv Setup Update Firmware Searching F/W--- XXX/XXXXX 12-08. -
Page 27: Chapter 5 Trouble Shooting
If there is no device connected and detected by duplicator during power-on, the duplicator will show an error message on the LCD before entering the main menu. 3. The DVD-ROM cannot read disc and shows error message. • Check the format of the master DVD or master DVD itself for damage. - Page 28 Press the ESC button for 2 seconds to enter the Adv Setup. 9. To cancel the duplicator working process. • Press the ESC button for 2 seconds to cancel any Copy, Test, or Verify etc. function while the job in progress. Copyright©2005 ILY Enterprise, Inc. All rights reserved.
