Oxford
Oxford
/Hoyer
Elevate
®
®
User Instruction Manual & Warranty
To avoid injury, read user manual prior to use.
Oxford
/Hoyer
Elevate
®
®
Manuel de l'utilisateur et garantie
Afin d'éviter tout accident, veuillez lire attentivement la notice avant utilisation.
Oxford
/Hoyer
Elevate
®
®
Manual de Instrucciones y Garantia para el Usuario
Para evitar posibles daños, lea previamente el manual de usuario.
Oxford
/Hoyer
Elevate
®
®
Benutzerhandbuch und Garantie
Um Verletzungen zu vermeiden, lesen Sie bitte die Gebrauchsanweisung vor
der ersten Benutzung.
Hoyer
/
®
Redefining patient handling
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oxford and is the answer not in the manual?

Questions and answers

Related Manuals for Joerns Healthcare Oxford

Summary of Contents for Joerns Healthcare Oxford

  • Page 1 Oxford Hoyer ® ® Oxford /Hoyer Elevate ® ® User Instruction Manual & Warranty To avoid injury, read user manual prior to use. Oxford /Hoyer Elevate ® ® Manuel de l’utilisateur et garantie Afin d’éviter tout accident, veuillez lire attentivement la notice avant utilisation.

  • Page 2: Table Of Contents

    1. Oxford/Hoyer Elevate Patient Lift ..................2. Introduction: About Your Lift ..................... 3. Assembly and Commissioning Instructions ..............4. Sling Guide ........................5. Lifting with the Oxford/Hoyer Elevate ................11 6. Safety Precautions......................12 7. Operating instructions ....................... 13 8. Charging instructions ......................16 9.

  • Page 3: Oxford/Hoyer Elevate Patient Lift

    Oxford /Hoyer ® ® E ngli sh Elevate 1. The Oxford/Hoyer Elevate Patient Lift Push Handle Digital Weigh Spreader Bar Scale (optional) (Cow horns) Battery/ Control Pack Sling Attachment Electric Actuator Points Mast Extrusion Adjustable Knee Pad Rear Castor (braked)

  • Page 4: Introduction: About Your Lift

    Elevate 2. Introduction: About Your Lift The Oxford/Hoyer Elevate is an electrically operated patient lift. Each Elevate lift is fully assembled, load tested and certified before being packed/shipped. The packing consists of a strong, purpose built carton that is used for both export and domestic markets to ensure the safe arrival of the lift.

  • Page 5: Assembly And Commissioning Instructions

    DESK TOP CHARGER/STAND • WArnIng the oxford/Hoyer Elevate is heavy and will need to be lifted with care. You may need assistance to lift the oxford/Hoyer Elevate from the carton. ASSEMBLY Remove the Elevate from the carton and place on the floor.
  • Page 6 Oxford /Hoyer ® ® E ng lish Elevate Tighten the mast assembly with the mast-locking device, which is located at the front of the chassis. Turn the locking knob until hand tight. Line the handle assembly up to the mast, and attach using the fasteners provided (these can be found in the mast).
  • Page 7 Oxford /Hoyer ® ® E ngli sh Elevate Fit power pack to the lift and make sure the latch holding the pack in place is fully engaged. “Click” in place. Fit the hand control to the lift as shown. Once complete, check the hand control is functioning correctly by referring to page 8.
  • Page 8 Oxford /Hoyer ® ® E ng lish Elevate ALWAYS CHECK tHE FoLLoWIng BEForE opErAtIon • The mast is fully locked into position. • The red emergency stop button, located on the rear of the control box, is in the OFF (out) position.

  • Page 9: Sling Guide

    ® E ngli sh Elevate 4. Sling Guide The Oxford/Hoyer Elevate is suitable for patients in the SITTING position. The slings suitable for this device are listed as follows: * Oxford/Hoyer Transport sling * Oxford/Hoyer Standing sling uSEr guIDE For StAnDAID SLIngS The Transport and Standing sling is an easy fit sling, suitable for standing and supporting.
  • Page 10 Ensure that the patient’s arms are outside the sling. WArnIng! oxford/Hoyer slings and lifters are not interchangeable with other manufactures products. using other manufacturers products on oxford/Hoyer products is unsafe and may result in serious injury to patient / or caregiver. WArnIng! Joerns Healthcare recommends slings are checked regularly and before use for fraying or damage.

  • Page 11: Lifting With The Oxford/Hoyer Elevate

    E ngli sh Elevate 5. Lifting with the Oxford/Hoyer Elevate Position the Elevate so that the patient’s feet fit in the foot tray and knees rest against the knee pad. Attach the loops of the sling to the hooks at the end of the Elevate hand grips. The patient’s hands should be placed on the handgrips (see Fig.

  • Page 12: Safety Precautions

    Elevate 6. Safety Precautions Please read and follow the safety precautions listed below. The operation and use of Oxford/ Hoyer patient lifts is simple and straightforward. Following these few basic safety precautions will make lifting operations easy and trouble free.

  • Page 13: Operating Instructions

    Oxford /Hoyer ® ® E ngli sh Elevate • Do not push the lift over uneven or rough ground. Particularly if loaded. • Do not attempt to push/pull a loaded lift over a floor obstruction. • n EVEr force an operating/safety control. All controls are easy to use and do not require excessive force.
  • Page 14 Elevate 1. Leg adjustment The legs on the Oxford/Hoyer Elevate are electrically adjustable for width. The legs can be opened to enable access around armchairs or wheelchairs. For transferring and negotiating narrow door- ways and passages the lift legs should be in the closed position.
  • Page 15 E ngli sh Elevate . Slings The Oxford/Hoyer Elevate is suitable for patients in the SITTING position. The slings suitable for this device are the Oxford/Hoyer Standing sling and Transport sling as detailed in section 4 (Sling Guide). . Knee pad adjustment The Elevate has an adjustable kneepad.

  • Page 16: Charging Instructions

    Fit the power pack to the lift and make sure the latch holding the pack in place is fully engaged. “Click” in place. The charging of Oxford/Hoyer electric lifts is simple and straightfor ward, but it is important to follow the charging instructions closely. Please pay particular attention to the following warnings, they will help you avoid problems with discharged batteries.
  • Page 17 Oxford /Hoyer ® ® E ngli sh Elevate WArnIng Battery or charger is not to be opened by unauthorized personnel. (Contact your distributor for warranty and repairs). WArnIng Do not touch battery/charger terminals. WArnIng KEEp the batteries fully charged. place the battery on charge whenever it is not in use. If it is more convenient to do so, place on charge every night.

  • Page 18: Digital Weigh Scale

    - NAWI Directive (90/384/EEC) opErAtIng InStruCtIonS: The Oxford/Hoyer scale has been designed and certified to weigh up to 00kg or 0lbs in 0. increments. notE: For customers or users in North America, your scale will measure in either Lbs or Kgs.
  • Page 19 Oxford /Hoyer ® ® E ngli sh Elevate to weigh a patient follow the instructions below: 1. Assemble the sling to the cow horn and press the ON/ZERO pad. The display will show 0.0 and the word HOLD will appear in the lower left hand corner. This step prepares the scale for weighing.
  • Page 20 Outside the UK please check your local requirements. Important note (Europe requirement only) The Oxford/Hoyer Weigh scale is a class 3 compliant weighing device and conforms to the NAWI Directive 90/384/EEC and has been certified by the National Weights and Measures Laboratory.
  • Page 21 Oxford /Hoyer ® ® E ngli sh Elevate *tHESE CHECKS SHouLD InCLuDE: 1. BooM: Check the attachment of the boom to the mast. Make sure there is only minimal side movement of the boom and the boom ü ü ü...

  • Page 22: Maintenance Schedule & Daily Check List

    If the alarm sounds, Do not use and place on charge immediately. MAIntEnAnCE, InSpECtIon AnD tESt Joerns Healthcare recommend a thorough inspection and test of the Oxford/Hoyer Elevate lift and lifting accessories, slings, scales etc is carried out on a regular basis. Inspection frequency varies from country to country so you must check with your dealer or local government agency as appropriate regarding how often an inspection is required.

  • Page 23: Technical Specifications

    Oxford /Hoyer ® ® E ngli sh Elevate 11. Techinical Specifications Safe Working Load ............440 lbs 200 kg Maximum Overall Length ..........43.3 inches 1100 mm Minimum Overall Length ..........41.0 inches 1040 mm Maximum Overall Height ..........65.5 inches 1665 mm Minimum Overall Height ..........48.4 inches 1230 mm Maximum Height to attachment point ......64.7 inches...

  • Page 24: Environmental Conditions

    Oxford /Hoyer ® ® E ng lish Elevate ELECtrICAL SpECIFICAtIonS: BATTERIES ..............24 volt Rechargeable sealed lead acid type BATTERY CAPACITY .............3.2 Ampere hours CHARGER RATED INPUT ..........100 - 240 V AC// 24 VDC 50/60 Hz CHARGER RATED OUTPUT .........29.5 VDC, Max. 19 W Electric Shock protection CHARGER ...............CLASS II...
  • Page 25 Oxford /Hoyer ® ® E ngli sh Elevate KEY SYMBoLS: The following symbols are used on the charger, control unit and battery: Type B equipment, as per EN 60601-1 Class 2 equipment The disposal of the charging and control unit should not be mixed with general household waste The disposal of batteries should not be mixed with general household waste.

  • Page 26: Warranty

    Failure to comply to the lift’s servicing schedule may result in your warranty being invalid. If you are in doubt where your lift was purchased, Joerns Healthcare can trace the supplier if you quote the serial number of the lift.
  • Page 27 Oxford /Hoyer ® ® E ngli sh Elevate 294000.10046 Rev. A...
  • Page 28 Joerns Healthcare Inc Joerns Healthcare Ltd 5001 Joerns Drive High Street, Wollaston Stevens Point, WI 54481-5040 Stourbridge, West Midlands DY8 4PS 715-341-3600 ENGLAND 800-826-0270 +44 (0)1384 44 66 22 Fax: 715-341-3962 © 2008, Joerns Healthcare 294000.10046 Rev A...
