User Manual
PS6MC300UE Parts List
1- PS6SMC3000UE USB & Ethernet Charging Cradle
1 - USB Type-A to Mini-B Cable (1 meter)
1 - Quick Connect Guide (this document)
MC3000
Charge the MC3000
PS6SMC3000UE
Front
For Local Communication:
Connect the USB Type-A connector to a Type-A
connector on the Host Computer.
Connect the USB Mini-B connector to the USB
connector on the cradle.
Local
Host
Computer
Connect MC3000
Place the MC3000 into the cradle
Problems?
Download the User's Guide and
Troubleshooting Tips from the
CradlePoint website at:
www.cradlepoint.com
Still having problems?
Contact Technical Support at:
support@cradlepoint.com
Slide Selector Switch to
choose Network or USB
communication.
USB Type-A
to
Mini-B Cable
PS6SMC3000UE
Ethernet
Charging
Cradles
Front side
Quick Connect Guide
Plug the Standard 115V
Power Cord into the Power
Adapter
For Network Communication:
Connect one end of a standard Ethernet
cable to the cradle's RJ45 connector and
the other end to your hub, router, switch,
or wall data outlet
PS6SMC70UE
USB &
Back side
Connect Power
Plug the barrel connector
into the Cradle's Power
Connector
Part Number: 190131-002 Rev B
