Instruction Manual
Gigabit 850nm Multi Mode LC Fiber Optic Transceiver(SFP) - 550m
SFPSXMM
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x SFPSXMM transceiver module
• 1 x Installation Guide
Installation
1. Remove the fiber cover and unhook the retention bar from the
SFP module.
2. Insert the SFP module into the SFP receptacle on your
networking device.
3. Secure the SFP module in place by locking in the retention bar.
4. Insert the fiber cable into the fiber connector.
5. To remove the SFP module, unhook the retention bar and pull out
the module.
For the most up-to-date information, please visit: www.startech.com
Specifications
Interface
Transmission Standard
Fiber Connector
Fiber Type
Maximum Distance
Hot Pluggable
Warranty
*actual product may vary from photos
Small Form-factor Pluggable
MSA
1.25Gbps IEEE802.3z 1000BASE-
SX
Duplex LC
Multi-Mode
550m (50/125um)
300m (62.5/125um)
Yes
1 Year
Manual Revision: 08/21/2012
