L V1
Vehicle Kit LV1
QUICK START GUIDE
Listen to your Lynx Radio
through your vehicle's stereo

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vehicle Kit LV1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sirius XM RAdio Vehicle Kit LV1

Summary of Contents for Sirius XM RAdio Vehicle Kit LV1

  • Page 1 L V1 Vehicle Kit LV1 QUICK START GUIDE Listen to your Lynx Radio through your vehicle’s stereo...

  • Page 2: What's In The Box

    What’s in the Box? ch - ch + Dash Mount PowerConnect Vehicle Dock Remote Control Vent Mount & Extended Vent Mount Clips Antenna Cable Routing Adapter Alcohol Alcohol Prep Pad Prep Pad Magnetic Mount Aux In Cable PowerConnect Alcohol Pads AMPS Screws Antenna Power Adapter...
  • Page 3 PowerConnect Vehicle Dock Controls & Connectors PowerConnect Vehicle Dock Front View Lock Tab Knob (PowerConnect Only) Secures Lynx in the Vehicle When at the Now Playing Dock. Push back to release screen, press and hold for Lynx from the dock. two seconds to display the FM Settings screen.
  • Page 4 Remote Control Button Functions and Battery Pause and Replay Buttons: Power Button Press for 3 seconds to turn Pause/Play button Radio On; press and hold to Pauses or resumes playing of turn Radio Off. the currently tuned channel. Rewind button Tune Up/Down Channels Immediately tunes up or Rewinds through content so...
  • Page 5 Find a Location for Lynx and Mount It For mounting the PowerConnect™ Vehicle Dock, you can select either the Dash Mount method or the Vent Mount method. For the Vent Mount, wait until after you have connected all the cables to the Vehicle Dock before you attach it to the mount.
  • Page 6 Find a Location for Lynx and Mount It (continued) Clean the surface where you are installing the Dash Mount with the alcohol preparation pad. Once the surface is dry, remove the adhesive liner. Press and hold the Dash Mount in place for 30 seconds.
  • Page 7 Find a Location for Lynx and Mount It (continued) Install the Vent Mount onto the vehicle vent: Dash Insert the Vent Mount into Vent the vent opening. Foot Louver Dash Push until hooked on the rear HOOKED PUSH of the vent louver. Rest the foot against the bottom of Vent the vent.
  • Page 8 Install the Magnetic Mount Antenna... Mount the Magnetic Mount Antenna outside your vehicle, on a clean and dry horizontal surface that will always face the sky. Choose the location for the antenna according to your type of vehicle. Center it between the left and right sides, and away from other antennas.
  • Page 9 ...and PowerConnect Power Adapter TIP: Include enough slack in your cable routing to accommodate open doors or the hood lid. Coil any excess cable in a hidden location and keep it away from any vehicle pedals or controls. Run the cable under the dash, or under a floor mat, bringing it out at the Radio location.

  • Page 10: Connect The Audio

    Connect the Audio You’ll need to decide how you will connect Audio Quality GOOD BETTER BEST the audio so you can hear it in your vehicle. Aux In Cable (AUX) The chart to the right shows the Bluetooth (A2DP Profile) possible audio connection options and FM Direct Adapter (FMDA)* their quality.
  • Page 11 Connect the Audio (continued) Aux In Cable (or Cassette Adapter) Audio Setup: If your vehicle radio has an AUX jack, the Aux In Cable connects Lynx to your vehicle radio for the audio. If your vehicle has a cassette player, you can also use an optional Cassette Adapter (sold separately) for the audio.
  • Page 12 Subscribe To be able to tune the channels, you will need to subscribe to SiriusXM satellite radio. Once you have successfully connected the audio, keep your vehicle parked where it has a clear view of the sky throughout the activation process.

  • Page 13: Specifications

    Specifications System Power Requirements: 9-16 V DC, 1.5 A (max) Operating Temperature: -4°F to +122°F (-20°C to +50°C) Audio Output: 1.0 V rms (max) PowerConnect Vehicle Dock Dimensions: 4.4 in (width) x 3.4 in (height) x 1.6 in (depth) 112 mm (width) x 87 mm (height) x 41 mm (depth) Weight: 2.0 oz (57 g) Audio Connector:...
  • Page 14 The user is cautioned that changes or modifications not expressly approved by Sirius XM Radio Inc. can void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.

  • Page 15: Copyrights And Trademarks

    Copyrights and Trademarks ©2011 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sirius XM Radio Inc is under license.
  • Page 16 SiriusXM product warranties do not cover the installation, removal, or reinstallation of any product. Sirius XM Radio Inc. 1221 Avenue of the Americas siriusxm.com New York, NY 10020 1.866.635.2349 © 2011 Sirius XM Radio Inc. Lynx VK QSG 111209a...
